Ultrasonic Distance Meter
Operation Manual
X
P
ROTEC
XProTec Ultrasonic Distance Meter - Operation Manual
1
About XProTec Pro-Installer Tools
The XProTec line from XFTP is a comprehensive lineup of professional-
grade technical tools. These full-featured, field-proven, and easy-to-use
tools meet the highest quality standards in the industry, and feature the
dependability you expect for complete installation solutions.
XProTec Ultrasonic Distance Meter - Operation Manual
2
Table of Contents
Safety Instructions & Warnings ................................................................ 3
Care & Handling ......................................................................................... 4
Measurement Features ............................................................................... 4
Functional Overview .................................................................................. 5
Measurement Requirements ...................................................................... 7
Environmental Measurement Requirements ............................................ 7
Physical Measurement Requirements ..................................................... 7
Initial Setup ................................................................................................. 9
Before Operation ...................................................................................... 9
Backlight Operation .................................................................................. 9
Measurement Units .................................................................................. 9
Measurement Start Point .......................................................................... 9
Measurement Instructions ....................................................................... 10
Measuring Length ................................................................................... 10
Measuring Area ........................................................................................ 11
Measuring Volume ................................................................................... 11
Sum of Lengths ...................................................................................... 12
Storing & Deleting Measurement Data ................................................... 12
Recalling Measurement Data ................................................................. 13
Battery Maintenance ................................................................................. 13
Specifications ........................................................................................... 14
Warranty Information ............................................................................... 16
XProTec Ultrasonic Distance Meter - Operation Manual
3
Safety Instructions & Warnings
The Ultrasonic Distance Meter emits a
laser beam from the front side of the unit
which projects a visible red spot on the
target.
Although the emission power of the laser
beam is less than 5 mW (Class llla), DO
NOT point the laser directly at the eye or
indirectly by using a reflective surface
such as a mirror.
Do not remove the laser warning label from
the unit.
!
WARNING: Use of controls or performance of procedures other
than those specified herein and failure to follow warnings may
result in injury.
XProTec Ultrasonic Distance Meter - Operation Manual
4
Care & Handling
This unit is a precision instrument which must be handled with care. Take
note of the following:
• Avoid dust and water, use a soft cloth to clean the unit.
• Avoid shock, vibrations and extreme heat.
• Keep the unit clean and dry.
• Check the battery regularly to avoid deterioration.
• Power off when not in use.
• Remove the battery if unit is to be stored for an extended period of
time.
Measurement Features
This unit includes the following measurement features;
• Measures in both Imperial (Feet) and Metric (Meters)
• Start point selection
• Storage of up to 5 groups of measurement data
• Recall measurement data stored in memory
• Computes areas and volumes
• Sum of lengths
• Auto shut-off
• LCD backlight
• Audible tones for button press, measurement errors, and measure-
ment confirmation.
XProTec Ultrasonic Distance Meter - Operation Manual
5
Functional Overview
The diagram shown on the following page represents the basic controls and
features of the Ultrasonic Distance Meter.
1. Ultrasonic Sensor Aperture
2. Laser Pointer
3. Front Measurement Position
4. LCD Display
5. Fm/Bm - This button changes the measurement start point from the
front of the unit to the base of the unit.
6. Ft/M - This button changes the measurement units between Metric
(Meters) and Imperial (Feet).
7. READ - This button is used to take a measurement and enable the
LCD Display Backlight.
8. VOLUME - This button is used to enter the Volume Measurement
Mode.
9. AREA - This button is used to enter the Area Measurement Mode.
10. +/= - This button is used to sum length measurements
11. ESC CLEAR - This button is used to return to the Length Measure-
ment Mode or delete measurement data stored in memory.
12. RECALL - This button is used to recall stored measurement data.
13. STORE - This button is used to store the current measurement data.
14. POWER - This button is used to turn the unit ON and OFF.
15. Base Measurement Position
16. Belt Clip
17. Battery Cover
XProTec Ultrasonic Distance Meter - Operation Manual
6
XProTec Ultrasonic Distance Meter - Operation Manual
7
Measurement Requirements
The following sections describe the environmental and physical
requirements necessary for an accurate measurement.
Environmental Measurement Requirements
Temperature and humidity in different environments affect the speed of
sound. When accuracy is critical, make sure the ultrasonic distance meter
is used in appropriate environment as follows: indoors or low wind conditions
within 0 to 30 °C, 45 to 90 %RH.
Physical Measurement Requirements
The ultrasonic technology that is used in this unit requires that the unit
should be pointed toward the surface of the object to be measured at a right
angle both horizontally and vertically. The right angle should be controlled to
less than ±5° to obtain the most accurate measurement.
If the surface of the object is very rough, this unit may not be able to
obtain a measurement to the precision that is stated in the Specifications
Section of this Operation Manual.
When the unit is out of range, there is no return signal and no valid
measurement. The LCD Display will show -ERROR- and the unit will beep.
To ensure the accuracy of your measurements, please take note of
following physical measurement requirements;
• For accurate results, choose a target surface that is large, flat and
hard.
• Place sufficiently sized piece of cardboard in front of targets that
are too small.
XProTec Ultrasonic Distance Meter - Operation Manual
8
• Although the laser beam can pass through glass, the unit can not
take measurements through glass.
• Choose the measurement units before taking your first measure-
ment and do not change the units when you are in the measurement
mode.
• When the distance is longer than 12 meters, a strong wind could
adversely effect the accuracy of the unit.
• When the distance to be
measured is more then 5
meters (15 feet), the width of
the area being measured
should be greater than 1.5
meters (4.5 feet).
• When the distance is more
then 10 meters (30 feet), the
width of the area being
measured should be greater
than 2.5 meters (6.5 feet).
