103-2 Quick start guide

Thanks for choose our product. This Quick Start guide tells you how to se

t up your GPS Tracker.

See picture 1 connect antennas in right way and put antennas outside.

See picture 2 inside two SIM cards and TF card.

See picture 3 connect wires in right way.

Unit will turn on automatically when put the SIM card in，the red LED con

verted to one second flashes, SIM card Registration Successful,LED light w

as converted to three seconds blinking GPS positioning success.

Confirm your SIM card have calling, send SMS, GPRS function.

Confirm your SIM card have enough balance (money).

Confirm your SIM card can show caller ID and don not use call forwarding

function.

Now you can operate the function .Begin!

How to connect the antenna.

Wires connection.

⒈Black wire: -12V

⒉Red wire: +12V

⒊Purple wire : ACC

⒋Microphone

⒌Connect relay.

⒍White wire: connect guard

against theft implement.

⒎SOS.

⒏Oil and Power

Two SIM card.

Unit will turn on for another one automatically When no fee with one SIM

card.

TF card*.

Support 2GB TF card, over-the-air update, resume from break point cannot

work without TF card.

Over the air update.

Update can be finished by SMS ,and also the software on our website will

be update occasionally

Breakpoint continuingly.

Date will be saved at SD card when in weak GPRS signal and will be send to

platform automatically again when have GPRS signal.

Password.

We suggest change the password and keep it in mind. Please contact with

franchiser if you forgot it

Authorization.

, Unit only work with correct one.

SMS will be send to Authorized number. Authorized number can send the

command without password.

Traffic Mode

When moved ,the device will send GPS data to monitor platform or mobile

phone automatically; when stay still, the device will go to sleep to save power.

Internet monitor.

Set APN.

APN stands for Access Point Name. For

example picture ,China mobile “CMNET”,

send SMS“123456apn cmnet”to the unit；

if APN have user name and password, For

example picture ,Microcell，APN is

internet., user name：fido , password：

fido

IP and port.

When APN setting succeed, send SMS“123

456adminip 119.147.23.100 2337”，it will

reply“ADMINIP ok!”.“2337”is port number

Data transmission.

Send SMS:“123456t010s***n”to the unit,

will reply”t010s***n ok”.Data will be

transmissionto the platform every 10

seconds. stop send sms“123456tmno”

Internet platform.

Please contact franchiser.

They will supply you

platform website, User

name, Password and help

you to add your unit into

platform.

You can check more inf

ormation about platform i

n CD-ROM.

Remote control oil and circuit.

Send SMS“123456powercar 11”to cut

off oil and circuit；Send

SMS“123456powercar 00”to supply oil and

circuit again.

Warning：Please make sure the vehicle

stay still before using this order.
