Xerox WorkCentre XE88 Manuel utilisateur

User

Guide

701P33173

WorkCentre XE88

USER GUIDE

Xe88qrg.bk Page 1 Thursday, February 17, 2000 4:25 PM

Prepared by:

Xerox Industrial Design Human Interface

Graphic Design

Jefferson Road

Henrietta

New York

material and information now allowed by statutory or judicial law or hereinafter

granted, including without limitation, material generated from the software

programs which are displayed on the screen, such as icons, screen displays,

looks, etc.

Xerox®and all Xerox products mentioned in this publication are registered

trademarks of the Xerox Corporation.

Product names and trademarks of other companies are also acknowledged.

Changes are periodically made to this document. Changes, technical inaccuracies

and typographical errors will be corrected in subsequent editions.

Publication number: 701P33173

Xe88qrg.bk Page 2 Thursday, February 17, 2000 4:25 PM

User Guide iii

USER GUIDE

Table of Contents

Where do I find it? v

1. INTRODUCTION 1-1

WorkCentre Features 1-2

2. COPIER FEATURES 2-1

Paper Specifications 2-1

Loading Media 2-3

Control Panel 2-6

Copy Quality 2-6

Copy Contrast 2-7

Reduction/Enlargement Presets 2-7

Reduction/Enlargement 2-7

Indicators 2-8

On-line/Off-line Button 2-9

Ready Indicator Light Start 2-10

Clear 2-10

Message display 2-10

Programmable Feature Settings 2-11

Settings 0 - 7, 14 and 15 2-11

Xe88qrg.bk Page iii Thursday, February 17, 2000 4:25 PM

User Guide

Setting 10 2-13

Power Reductions 2-18

Power Save 2-18

Power Shut-Off 2-18

Auto Clear 2-19

Two-Sided Copying 2-19

Copying While Printing 2-20

3. PRINTING 3-1

4. SCANNING 4-1

Overview 4-1

TWAIN Scanner Driver 4-2

Starting the TWAIN Scanner 4-3

Scanning with TextBridge Pro 4-4

Scanning with other Software 4-6

5. TROUBLESHOOTING 5-1

E1 Jams at the Paper Tray 5-2

E2 Jams Inside the WorkCentre 5-3

E3 Jams at the Paper Exit Area 5-4

WorkCentre Fault Codes 5-5

Problems and Solutions 5-6

6. CLEANING AND MAINTENANCE 6-1

Cleaning the Outside 6-1

Cleaning the Glass and Cover 6-2

Cleaning the Drum Cartridge 6-3

To clean the drum surface 6-3

Service 6-4

7. CONSUMABLES 7-1

Copy/Print Count 7-2

Toner Cartridge Yield 7-2

Storage 7-3

Replacing the Toner Cartridge 7-4

Drum Cartridge Life 7-6

Replacing the Drum Cartridge 7-6

Xe88qrg.bk Page iv Thursday, February 17, 2000 4:25 PM

User Guide

WHERE DO I FIND IT?

Where do I find it?

CD-ROM

• WorkCentre Installation program

• Print and TWAIN Scan drivers

• TextBridge Pro 8.0 with Tour Guide and Online Help

Warranty Card

• Warranty Information

In addition to this User Guide, your WorkCentre XE88 comes

complete with a Getting Started Guide, CD-ROM, and a Warranty

Card. If you do not see what you are looking for in this User Guide,

check below to find where you can locate the information.

Getting Started

• Getting Started

•Setup

• Installation

• Connections

• Quick Procedures

Xe88qrg.bk Page v Thursday, February 17, 2000 4:25 PM

User Guide

Xe88qrg.bk Page vi Thursday, February 17, 2000 4:25 PM

User Guide 1.1

Chapter One

INTRODUCTION

The WorkCentre is compact and easy to use.

It is specially designed to provide you with

high quality and high performance copying,

printing, and black and white scanning.

This guide tells you how to set up, operate,

maintain, and get the best performance from

your WorkCentre.

Xe88qrg.bk Page 1 Thursday, February 17, 2000 4:25 PM

1.2 User Guide

WORKCENTRE FEATURES

WorkCentre Features

The copy speed for the WorkCentre XE 88

is 8 copies per minute. The maximum

print speed for the Digital WorkCentre is

8 prints per minute. The WorkCentre

features a high-capacity paper tray for

easy loading of paper, envelopes, label

sheets and transparencies.

Some of the other advanced features

which can be selected from the control

panel of this WorkCentre include:

• Copy ratio: two reduction values, two

enlargement values, one customer-

programmable value

• Zoom R/E ratio range: 50 to 200%

• Copy Quality modes: Automatic,

Text, Photo, Toner Saver

• Programmable defaults

• Fault indicators and error message

display

• Scanning in black and white

Xe88qrg.bk Page 2 Thursday, February 17, 2000 4:25 PM

User Guide 2.1

Chapter Two

COPIER FEATURES

Selecting Media

Paper Specifications

For reliable WorkCentre operation and good

copy/print quality, Xerox recommends that

paper be stored appropriately:

• on a flat surface.

• in a closed container.

• in a low humidity area.

• tightly wrapped, if the ream is partially

used.

Note: Paper affected by humidity, and

curled paper can cause jams and copy/

print quality problems.

Xe88qrg.bk Page 1 Thursday, February 17, 2000 4:25 PM

User Guide

2.2

PAPER SPECIFICATIONS

* Use labels and transparencies specifically designed for copiers (high temperatures).

Caution: Do not insert paper with metallic attachments such as staples or paper clips, nor

place anything on top of the WorkCentre. They get stuck in the paper feeding mechanism and

will scratch the drum and damage other parts of the WorkCentre mechanism.

Paper Input Paper Tray

Sizes 3 7/8 x 5 7/8 to 8 ½ x 14 in.

(98 to 216 x 315/330 mm)

Weights: Optimum

Range

20 lb / 80 g/m²

14 - 34 lb

52 - 130 g/m²

Capacities:

Copy, letterhead, and predrilled

20 lb / 80 g/m²

XE86: 200 sheets

XE88: 250 sheets

Labels and Transparencies * Yes (1 at a time)

Envelopes (one at a time) COM-10 (4.1 x 9.5 in. / 216 x 279 mm)

Monarch (3.87 x 7.5 in. / 98.5 x 191 mm)

C5 (6.4 x 9.16 in. / 162 x 229 mm)

DL (4.4 x 8.8 in. / 110 x 220 mm)

Xe88qrg.bk Page 2 Thursday, February 17, 2000 4:25 PM
