Xerox Wide Format 6030 Guide de démarrage rapide

Xerox 6030/6050/6204 Wide Format

Windows Driver User Guide

701P44732

Version 1.6

November 2005

Xerox Corporation

Global Knowledge & Language Services

800 Phillips Road Bldg. 845-17S

Webster, NY 14580

Printed in the United States of America.

copyrighted material and information now allowed by statutory

or judicial law or hereinafter granted, including without

limitation, material generated from the software programs that

are displayed on the screen such as styles, templates, icons,

screen displays, looks, etc.

Adobe® and the Adobe logo, InDesign®, Illustrator®,

PageMaker®, Photoshop®, Acrobat®, Distiller®, and the

Acrobat logo are either registered trademarks or trademarks of

Adobe Systems Incorporated in the United States and/or other

countries.

The Creo wordmark, Creo logo, and the names of Creo

products and services referred to this document are

trademarks of Creo, Inc.

Macintosh, Power Macintosh, and Mac are registered

trademarks of Apple Computer, Inc.

Microsoft® Windows NT® and Microsoft® Windows are

trademarks of Microsoft Corporation.

PANTONE® is a registered trademark of Pantone, Inc.

Sun Microsystems and Solaris are a trademarks, registered

trademarks, or service marks of Sun Microsystems, Inc. in the

U.S. and other countries.

SWOP® is a registered trademark of SWOP, Inc.

Quark and QuarkXPress are trademarks of Quark, Inc. and all

applicable affiliated companies, Reg. U.S. Pat. & Tm. Off. and

in many other countries.

Macromedia FreeHand® is a trademark of Macromedia, Inc.

This product includes software developed by the Apache

Software Foundation (http://www.apache.org).

This product includes software developed by the JDOM

Project (http://www.jdom.org).

This product includes software developed by the Jaxen

Project (http://www.jaxen.org).

XEROX®, The Document Company®, the digital X®, Xerox

6030/6050/6204 Wide Format Windows Driver are the

trademarks of or licensed to XEROX CORPORATION.

Preface

Thank you for using the 6030/6050/6204 Wide Format Windows Driver (hereinafter

known as Windows Driver).

This User Guide describes the procedures and precautions involved in installing and

setting up Windows Driver. Refer to the user manuals supplied with the Xerox 6030/

6050 Wide Format Copier/Printer or the 6204 Wide Format Solution for details on

relevant operations.

The explanations provided in this User Guide assume that the user has a basic

knowledge of operating the computer and network configuration in use. Refer to the

manuals supplied with the computer, Windows related documentation and the manuals

supplied with the network system for details on computer and network operations.

Using This Guide

Organization

This guide consists of the following chapters.

Chapter 1. Installing Windows Driver

Explains how to install Windows Driver into your computer.

Chapter 2. Printing Setup

Explains how to print using Windows Driver and how to set up the various printing

conditions.

Chapter 3. System-Related Precautions and Limitations

Explains the precautions that must be observed for the system on which Windows Driver

is to be used.

Chapter 4. Uninstalling Windows Driver

Explains how to uninstall (delete) Windows Driver from the system.

Using This Guide

Conventions

This User Guide uses the following symbols and conventions:

< > key Indicates the keys on the keyboard.

Press the <Enter> key.

[ ] Indicates the menus and display items on the screens.

Select either the [On] or [Off] buttons to display [Job

Name], [Owner], and [Reason] in that order.

""Indicates areas of reference within this User Guide.

Also indicates messages.

Refer to "3.2 Print Services".

A message stating "Additional Port Information Required.

The Device could not be identified"appears.

Indicates important information which you should read.

Indicates additional information on operations or features.

Indicates reference sources.

Indicates examples.

Contents

Preface

Using This Guide

Contents

Chapter 1 Installing Windows Driver

1.1 Installing Windows Driver

(Windows XP)............................................................................................................................................2

Setting up Network Printer using an LPR port...........................................................................2

Setting the Printer's Spool ........................................................................................................12

Adding Network Printer (Windows 2000 or Windows XP).....................................................14

Installing Additional Windows Driver .....................................................................................18

1.2 Installing Windows Driver

(Windows 2000) ....................................................................................................................................... 21

Installing a Network Printer using an LPR port .......................................................................21

Changing the Printer's Spool Setting........................................................................................31

Adding Network Printer (Windows 2000 or Windows XP).....................................................32

Installing Additional Windows Driver .....................................................................................36

1.3 Installing Windows Driver

(Windows 98/Windows Me) ....................................................................................................................37

Setting the Printer's Spool ........................................................................................................42

Chapter 2 Printing Setup

2.1 Printing..........................................................................................................................................46

2.2 Windows Driver Settings ..............................................................................................................48

Displaying the Windows Driver Setup Screen.........................................................................48

Windows Driver Settings .........................................................................................................50

[Paper] Tab ...............................................................................................................................50

[Tray/Output] Tab.....................................................................................................................56

[Graphics] Tab..........................................................................................................................59

[Header/Footer] Tab .................................................................................................................61

[Default Settings] Tab ..............................................................................................................63

Contents

Chapter 3 System-Related Precautions and Limitations

3.1 Operating System..........................................................................................................................68

Versions that support printer firmware.....................................................................................68

Computer Configuration...........................................................................................................68

3.2 Network Connections....................................................................................................................69

What are Logical Printers? .......................................................................................................69

3.3 Windows 98/Me Network Connections........................................................................................70

Connection Method ..................................................................................................................70

3.4 Precautions When Setting Up the Printer Parameters...................................................................73

Chapter 4 Uninstalling Windows Driver

4.1 Uninstallation Procedure...............................................................................................................76

Index.................................................................................................................................................................................77

Contents

Chapter

Chapter 0

Installing Windows Driver

Chapter 1

This chapter explains how to install Windows Driver into your computer.

The method of installing Windows Driver is described separately for each operating

system for which there is no installation tool. Refer to the proper section for

installation instructions.

•Windows XP→"1.1 Installing Windows Driver (Windows XP)" (page 2)

•Windows 2000 →"1.2 Installing Windows Driver (Windows 2000)" (page

21)

•Windows 98 →"1.3 Installing Windows Driver (Windows 98/Windows

Me)" (page 37)

•Windows Me →"1.3 Installing Windows Driver (Windows 98/Windows

Me)" (page 37)

When upgrading Windows Driver, ensure that the old version of the

Windows Driver has been uninstalled before attempting to install the

upgraded version of the Windows Driver. Refer to "Chapter 4 Uninstalling

Windows Driver" for details on the procedures for this (page 75).

2Chapter 1 Installing Windows Driver

1.1

Installing Windows Driver

(Windows XP)

This section explains how to install Windows Driver without an installation tool onto

Windows XP computer.

The installation procedure will differ in accordance with the printer's connection status.

Proceed to the section that corresponds with the configuration in use.

•When connected to networks with TCP/IP protocol using LPR: Proceed to the

section on "Setting up Network Printer using an LPR port".

•When using FTP connections: Proceed to the section on "Setting up Network

Printer using an LPR port".

•When connected to networks using Windows 2000 or Windows XP Systems:

Proceed to the section on "Adding Network Printer (Windows XP)" (page 14).

Setting up Network Printer using an LPR port

1Click [Start] on the task bar, then select [Control Panel] > [Printers and Other

Hardware] > [Printers and Faxes].

The [Printers and Faxes] window appears.

2Click [Add a printer].

[Add Printer Wizard] appears.

3Click [Next].

Data is output to a file and then transmitted for printing from the command prompt

with FTP connections.
