Xantrex PowerHub PH1800 Manuel

PowerHub 1800

Operator’s Guide

PH1800

PowerHub 1800

Operator’s Guide

About Xantrex

Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls

with products from 50 watt mobile units to 2.5 MW utility-scale systems for wind, solar, batteries,

fuel cells, microturbines, and backup power applications in both grid-connected and stand-alone

systems. Xantrex products include inverters, battery chargers, programmable power supplies, and

variable speed drives that convert, supply, control, clean, and distribute electrical power.

Trademarks

PowerHub 1800 is a trademark of Xantrex International. Xantrex is a registered trademark of

Xantrex International.

Other trademarks, registered trademarks, and product names are the property of their respective

owners and are used herein for identification purposes only.

Notice of Copyright

Exclusion for Documentation

UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)

(A)MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY

TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.

(B)ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES,

WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT

OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT

THE USER’SRISK; AND

(C)REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH

STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE ACCURACY

CANNOT BE GUARANTEED. APPROVED XANTREX CONTENT IS CONTAINED WITH THE ENGLISH

LANGUAGE VERSION WHICH IS POSTED AT WWW.XANTREX.COM.

Date and Revision

June 2006 Revision A

Part Number

975-0288-01-01 Rev B

Product Number

PH1800

Contact Information

Telephone: 1 800 670 0707 (toll free North America)

1 360 925 5097 (direct)

Fax: 1 800 994 7828 (toll free North America)

1 360 925 5143 (direct)

Email: [email protected]

Web: www.xantrex.com

iii

About This Guide

Purpose

The purpose of this Operator’s Guide is to provide procedures for

installing the PowerHub 1800.

Scope

The Guide provides safety guidelines, detailed planning and setup

information, and procedures for installing the inverter. It does not provide

operational or troubleshooting information. It does not provide details

about particular brands of batteries. Consult individual battery

manufacturers for this information.

Audience

The PowerHub is an entry-level inverter system. This Guide is intended

for anyone who needs to plan for and install the PowerHub 1800.

Permanent installations should be done by certified technicians or

electricians. Installers should have adequate knowledge of national and

local electric code to ensure code-compliance by inspection from the local

electric authority.

Organization

This Guide is organized into three chapters and one appendix.

Chapter 1 describes the operational features and functions of the

PowerHub 1800. This section details how the unit functions as an

inverter, provides information on the control panel, and describes

operating limits for inverter operation.

Chapter 2 contains information on operating the PowerHub 1800.

Chapter 3 explains how to troubleshoot the PowerHub 1800 and describes

the error codes that may be displayed on the LCD.

Appendix A provides electrical and physical specifications for the

PowerHub 1800.

About This Guide

iv 975-0288-01-01 Rev B

Conventions Used

The following conventions are used in this guide.

Abbreviations and Acronyms

Related Information

You can find more information about this product by seeing the

PowerHub 1800 Installation Guide (part number 975-0289-01-01). You

can find more information about Xantrex Technology Inc. as well as its

products and services at www.xantrex.com.

A French version of this document is available at www.xantrex.com.

WARNING

Warnings identify conditions or practices that could result in personal injury or

loss of life

CAUTION

Cautions identify conditions or practices that could result in damage to the unit or

other equipment.

Important:

These notes describe things which are important for you to know,

but not as serious as a caution or warning.

Abbreviation or Acronym Definition

AAmps

AC Alternating Current

DC Direct Current

ft-lbs Foot-pounds (a measure of torque)

kW Kilowatts (1000 watts)

LED Light Emitting Diode

Nm Newton-meters (a measurement of torque)

PV Photovoltaic

RE Renewable Energy

Vac Volts AC

Vdc Volts DC

WWatts

Important Safety Instructions

1. Before installing and using the PowerHub 1800, read all

instructions and cautionary markings on the PowerHub, the

batteries, and in both this Installation Guide and the Operator’s

Guide.

2. The PowerHub is intended for indoor use only. Do not expose the

PowerHub to rain, snow, or spray. To reduce risk of fire hazard, do

not cover or obstruct the ventilation openings. Do not install the

PowerHub in a zero-clearance compartment. Overheating may result.

3. The PowerHub may connect to as many as three sources of DC Power

and one source of AC Power. To reduce the risk of electrical shock,

disconnect all sources of AC and DC power from the PowerHub

before attempting any maintenance or cleaning or working on any

circuits connected to the PowerHub. Turning off controls will not

eliminate this risk.

4. Use only attachments that are intended for use with this product.

Doing otherwise may result in a risk of fire, electric shock, or injury

to persons.

5. To avoid a risk of fire and electric shock, make sure that all of the

installation wiring is in good condition and that wire is not

undersized. Do not operate the PowerHub with damaged or

substandard wiring.

6. Do not operate the PowerHub if it has received a sharp blow, been

dropped, or otherwise damaged in any way. If the PowerHub is

damaged, see the “Return Procedure” on page WA–3.

7. Do not disassemble the PowerHub, except where noted to wire it for a

permanent installation or to install batteries. The PowerHub 1800

contains no user-serviceable parts. See “Warranty” on page WA–1 for

instructions on obtaining service. Attempting to service the

WARNING

This chapter contains important safety and operating instructions. Read and keep

this Operator’s Guide for future reference.

WARNING: Limitations on use

The PowerHub 1800 is not intended for use in connection with life support

systems or other medical equipment or devices.

Safety

vi 975-0288-01-01 Rev B

PowerHub yourself may result in a risk of electrical shock or fire and

will void your warranty. Internal capacitors remain charged after all

power is disconnected.

8. The PowerHub must be provided with an equipment-grounding

conductor. Grounding and all other wiring must comply with national

and local codes and regulations.

9. The PowerHub 1800 is not intended for use as an uninterruptible

power supply (UPS).

Figure i

Basic Safety

No! No!

Safety

975-0288-01-01 Rev B vii

Precautions When Working With Batteries

1. Use only SEALED batteries with the PowerHub 1800.

2. Follow all instructions published by the battery manufacturer.

3. Working in the vicinity of batteries may be dangerous. Unsealed

batteries can generate explosive gases during normal operation.

Therefore, you must read this guide and follow the instructions

exactly before installing or using the PowerHub.

4. This equipment contains components which tend to produce arcs or

sparks. To prevent fire or explosion, do not install the PowerHub in

locations that require ignition-protected equipment. This includes any

space containing gasoline-powered machinery, fuel tanks, as well as

joints, fittings, or other connections between components of the fuel

system.

5. To reduce the risk of battery explosion, follow these instructions and

those published by the battery manufacturer.

6. Make sure that nothing is blocking the air vents on the back of the

enclosure.

7. Never smoke or allow a spark or flame near the batteries.

8. Use caution to reduce the risk of dropping a metal tool on the

batteries. It could spark or short circuit the battery or other electrical

parts and could cause an explosion.

9. Remove all personal metal items, like rings, bracelets, and watches

when working with batteries. Batteries can produce a short circuit

current high enough to weld metal, causing a severe burn.

10. Have someone within range of your voice or close enough to come to

your aid when you work near a battery.

11. Wear complete eye protection and clothing protection. Avoid

touching your eyes while working near batteries.

12. Have plenty of fresh water and soap nearby in case battery acid

contacts skin, clothing, or eyes.

WARNING: Fire or Explosion Hazard

Safety

viii 975-0288-01-01 Rev B

13. If battery acid contacts skin or clothing, wash immediately with soap

and water. If acid enters your eye, immediately flood it with running

cold water for at least twenty minutes and get medical attention

immediately.

Precautions for Using Rechargeable Appliances

Most rechargeable battery-operated equipment uses a separate charger or

transformer that is plugged into an AC receptacle and produces a low

voltage charging output.

Some chargers for small rechargeable batteries can be damaged if

connected to the PowerHub. Do not use the following with the PowerHub:

• Small battery-operated appliances like flashlights, razors, and night

lights that can be plugged directly into an AC receptacle to recharge.

• Some chargers for battery packs used in power hand tools. These

affected chargers display a warning label stating that dangerous

voltages are present at the battery terminals.

FCC/ICES 003 Information to the User

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation.

This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

CAUTION: Equipment Damage

This equipment produces a modified sine wave output. Equipment damage may

occur if the rechargeable appliance is not designed to use modified sine wave

output. If you are unsure about using your rechargeable appliance with the

modified sine wave, contact the equipment manufacturer.

Autres manuels pour PowerHub PH1800

Table des matières

Autres manuels Xantrex Onduleur

Xantrex

Xantrex DR1512W Manuel utilisateur

Xantrex

Xantrex XDI2048 Manuel utilisateur

Xantrex

Xantrex XPower 175 PLUS Manuel utilisateur

Xantrex

Xantrex PROwatt 150 Manuel utilisateur

Xantrex

Xantrex PROwatt 3000 Manuel utilisateur

Xantrex

Xantrex XPower 3000 Manuel utilisateur

Xantrex

Xantrex XPower 1000 Plus Manuel utilisateur

Xantrex

Xantrex HI400 Manuel utilisateur

Xantrex

Xantrex DR - REV A Manuel utilisateur

Xantrex

Xantrex XW4024-120/240-60, XW4548-120/240-60,... Manuel utilisateur

Xantrex

Xantrex Trace Series Manuel utilisateur

Xantrex

Xantrex xpower 200W Manuel utilisateur

Xantrex

Xantrex Portawattz 300 Manuel utilisateur

Xantrex

Xantrex XPower 3000 Manuel utilisateur

Xantrex

Xantrex SW Plus 2524 Manuel utilisateur

Xantrex

Xantrex Freedom SW 230V Manuel utilisateur

Xantrex

Xantrex Link 10 Manuel utilisateur

Xantrex

Xantrex FREEDOM HF 1000 Manuel utilisateur

Xantrex

Xantrex RS3000 Manuel utilisateur

Xantrex

Xantrex Xanbus System Manuel utilisateur

Xantrex

Xantrex GT3.0 Manuel utilisateur

Xantrex

Xantrex 817-1000 Manuel utilisateur

Xantrex

Xantrex GT 2.5-DE, GT 3.8-DE, GT 2.8-S Manuel utilisateur

Xantrex

Xantrex XPower Powerpack 400 Plus, 400 R Manuel utilisateur

Manuels Onduleur populaires d'autres marques

Fourgroup

Fourgroup Easy Manuel utilisateur

Velleman

Velleman PI300M Manuel utilisateur

Sungrow

Sungrow SG350HX-US Manuel utilisateur

WilTec

WilTec 61897 Manuel utilisateur

SMA

SMA SUNNY BOY STORAGE 2.5 Manuel utilisateur

Simplicity

Simplicity LANDLORD 316 Manuel utilisateur

Santak

Santak SMAX 3000 Manuel utilisateur

ATON

ATON RA.Store-3 Manuel utilisateur

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manuel utilisateur

Tektronix

Tektronix CFG250 Manuel utilisateur

Champion

Champion 200989 Manuel utilisateur

Vanner

Vanner 20-500 Series Manuel utilisateur

GE GEP Manuel utilisateur

Astrel Group

Astrel Group Power Reducer Guide rapide

MULTIQUIP

MULTIQUIP GDP-5H Mode d’emploi

GoWISE

GoWISE PS1007 Manuel utilisateur

Promate

Promate PM13500D ES Manuel utilisateur

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manuel utilisateur
