X-Vision X2C4000BP Manuel utilisateur

Professional HD IP Camera

User Guide

Version 1

Thank you purchasing the XRN HD IP Camera from Xvision Pro HD.

Please ensure that you read and understand this User Guide before operating the camera.

Please store this User Guide in an easily accessible location.

PRO

XHD

Table of Contents

Functional Descriptions and Features.................................................................................4

Introduction............................................................................................................................2

Pre-requisites .........................................................................................................................2

IPC Description and Device Connection..............................................................................3

Appearance Description...........................................................................................................3

SchematicDiagram（X2C4000BVP）......................................................................................4

SchematicDiagram（X2C4000DVP）.....................................................................................6

SchematicDiagram（X2C4000VP）........................................................................................7

Installation of Indoor Dome Cameras.....................................................................................10

Device Connection.................................................................................................................13

Device Search Tool...............................................................................................................14

Active X Setup......................................................................................................................17

Web Browser Interface ........................................................................................................19

Live View................................................................................................................................19

Remote Setting.....................................................................................................................21

Display ...................................................................................................................................21

Live.........................................................................................................................................21

Image Control.........................................................................................................................22

Privacy Zone..........................................................................................................................23

ROI.........................................................................................................................................21

Record....................................................................................................................................22

Schedule................................................................................................................................23

Network..................................................................................................................................24

Video Streaming.....................................................................................................................25

Email......................................................................................................................................26

DDNS.....................................................................................................................................27

IP Filter...................................................................................................................................28

RTSP......................................................................................................................................29

FTP ........................................................................................................................................30

Alarm......................................................................................................................................31

Motion ....................................................................................................................................31

Alarm......................................................................................................................................32

Lens Shade............................................................................................................................33

Device....................................................................................................................................34

SD Card .................................................................................................................................34

Log.........................................................................................................................................35

Audio......................................................................................................................................36

System...................................................................................................................................37

Date/Time...............................................................................................................................37

Users......................................................................................................................................38

Info.........................................................................................................................................39

Advanced...............................................................................................................................40

Firmware Update....................................................................................................................40

Load Default...........................................................................................................................41

Maintain..................................................................................................................................42

PEA (Perimeter Alarm)...........................................................................................................43

OSC –Object Care.................................................................................................................46

X2C4000 Specification’s ......................................................................................................49

FAQ........................................................................................................................................55

Functional Descriptions and Features

Note：

•IPC refers to Internet Protocol Camera.

•Default IP address of IPCamera：192.168.1.168

•IP Camera default Username: admin (lower case）, Password:

admin (lowercase）

•Default web port：80，Default mediaport：9988

•LAN refers to Local Area Network (Inside your router)

•WAN refers to Wide Area Network (outside your

Router/Home/Office)

Features

Brief Description

Real time

monitoring

OptimizedH.265/H.264/MJPEG video compression algorithms; Multi-

stream transmission ensures high definition image transmission on both

narrowband and wideband.

Recording

Support simultaneous connection of up to 5video streams.

Onvif

Support ONVIF protocol, please check with www.xvision.comfor latest

supported version.

Network

protocols

Support multiple network protocols, such as TCP/UDP

,IP,HTTP,DHCP,RTP,RTSP,FTP,SMTP,DNS,DDNS,NTP,ICMP,IGMP

,ARP, GB28181

Record backup

Backup via Browser and some IPC support MSD card.

POE

POE Power over Ethernet support on allIPC-12 VDC±10%, PoE

Network

operation

Authorized access in go for remote client to ensure the system security.

APP Support

Smartphone video monitoring XIQCMS

Operating

Temperature/IP

Rating

-10 °C ~ 60 °C(14 °F ~140°F–IP66-below90%RH

SAFETY INSTRUCTION

Do not install the equipment in an environment with too much

moisture, dust or smoke dust as this may result in fire or electric

shock.

In the unlikely event that the equipment should malfunction and emit

an abnormal smell of smoke, please immediately stop it, shut off the

power and contact your supplier.

Please do not place this equipment near a heat source to avoid risk of

fire.

Please do not store, install and use this product in danger areas with

inflammable or explosive substances.

Please make sure the power is turned off when installing the product.

Please do not use the IPC in an environment where temperatures that

exceed either -20°C to+55°C.

Introduction

This guide is for the Xvision Pro HD X2C4000 Range of IP Cameras.

It is recommended that the units are setup and tested before being mounted or installed.

These instructions are for guidance only detailed information is in accordance with the

product.

The instructions may include some technical inaccuracies or typographical errors, these

will be corrected in future updates.

The product or procedures described in the instructions may be changed or updated at

any time without prior notice. Screenshots used in the instruction are only for indications

and explanations.

Screenshots used in the instruction are only for indications and explanations.

This Manual will cover the following:

•Schematic Diagram of XC Cameras

•Basic setting setup

•Setting an IP address

•Active X Controls

•Viewing on IE

•Specifications

Pre-requisites

Note before you begin installation:

•Connect only one X2C4000 range IPC at a time to your LAN, as

all cameras share the same default IP192.168.1.168

•Screw Drivers

•Router/Switch/Hub for your LAN, this is needed to connect all Network

IP equipment together.

•A Windows PC/Laptop on site connected to the same LAN

(Router/Switch) as your equipment.

•Cat 5 Patch cables to connect your X2C4000 and Router/Switch all

together

IPC Description and Device Connection

Appearance Description

The X2C4000 cameras can be wall or ceiling mounted, so to install the camera you will need

toadjustittothedesiredangle.Belowyouwillseehowtoinstalleachcameratype

SchematicDiagram（X2C4000BP）

Items

Descriptions

①Front cover

Helps protect the IPC from sunlight and rain.

②Rear cover

Fixed with the front cover.

③Lens

Lens of IPC

④Infrared IR’s

Infrared IR’s behind glass cover

⑤Ball and sleeve

Rotatable, used to adjust the angle of view of the IPC.

⑥Locknut

Fix the ball sleeve and the base.

⑦Base

Base to be secured against wall.

⑧Fixing hole

Screw holes to secure IPC to wall.

SchematicDiagram（X2C4000BVP）

Items

Descriptions

① Front cover

Helps protect the IPC from sunlight and rain.

② Rear cover

Fixed with the front cover.

③Focusing lever

Adjust the focal length of the IPC.

④Lens

Lens of IPC

⑤ Infrared IR’s

Infrared IR’s behind glass cover

⑥ Ball and sleeve

Rotatable, used to adjust the angle of view of the IPC.

⑦Base

Base to be secured against wall.

⑧ Fixing hole

Screw holes to secure IPC to wall.

SchematicDiagram（X2C4000DVP）

Items

Descriptions

① Transparent cover

Protects the IPC lens and IR’s.

② Infrared IR’s

Infrared IRLED’s

③ Main housing

Rotatable and used to adjust the installation angle

④Lens

Lens of IPC

⑤ Base

Secures the IPC to the wall

SchematicDiagram（X2C4000VP）

Items

Descriptions

①Lens

Lens of IPC

② Infrared lamp

Infrared LED lamp

③ Main housing

Rotatable and used to adjust the installation angle

④ Fixed guard

Secure the position of the Main housing.

⑤Base

Secures the IPC to the wall.
