X-Micro XMP3E-20F Manuel utilisateur

MusePod

User Manual

publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or

by any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of X-Micro Technology Corp.

Disclaimer

X-Micro Technology Corp. makes no representations or warranties, either

expressed or implied, with respect to the contents hereof and specifically

disclaims any warranties, merchantability or fitness for any particular purpose.

Any software described in this manual is sold or licensed "as is". Should the

programs prove defective following their purchase, the buyer (and not this

company, its distributor, or its dealer) assumes the entire cost of all necessary

servicing, repair, and any incidental or consequential damages resulting from

any defect in the software. Further, X-Micro Technology Corp., reserves the

right to revise this publication and to make changes from time to time in the

contents hereof without obligation to notify any person of such revision or

change.

All brand and product names mentioned in this manual are trademarks and/or

registered trademarks of their respective holders.

MusePod

Unique Features

Mass Portable Storage Player

1.This player can be used as the portable hard disk (the

capacity is 20G). No driver is necessary under

WinMe/2000/XP.

2.Unique USB Host Functions

Hard disk player can read the file from the other

standard USB Device

3.High speed transfer, USB2.0 standard interface,

compatible with USB1.1

Hard disk player supports USB2.0 with the highest

rate of transmission up to 20Mbyte/s.

4.Large screen LCD with high resolution - 128 X 128

Dot Matrix 4 Gray With Backlight

5.Support multi music formats:

including MP3 (MP3 of VBR format supported)

and WMA

6.Convenient firmware upgrade

The latest functions can be acquired through the

firmware upgrade.

New formats will be supported through the simple

upgrading; meanwhile, the other functions will be

provided constantly.

7.Support multi-languages display of ID3

Support various languages of ID3, including

English Manual

simplified Chinese, traditional Chinese, Japanese,

Korean and English

8.FM radio (87.5MHz~108.0MHz)

Auto-scan and memorize desired channels are more

convenient to listen to the FM radio.

9.Provide five types of equalizer (EQ):

Normal, Classic, Jazz, Rock and user EQ, making

music more abundant.

10.Supporting 3D effect, 15-level Bass Boost and

15-level Treble Boost, making music more colorful

11.Easy to use file navigation

12.Treeview navigation menu enables you to find the

music conveniently

13.Up to 2000 folders and 9999 files can be recognized

14.Graphical User Interface

15.Recording by Mic or Line_In

16.Supporting Bookmark Function

17.Supporting PlayList Function

18.Supporting TXT file navigation, namely, the e-book

function

MusePod

Contents

Front Part and Side Part........................................4-5

Top/Bottom Part and LCD ........................................ 6

Using the AC adapter ..........................................7-11

Charging................................................................7-8

Software Installation .............................................. 8-9

Connecting to the computer ..............................10-11

Disconnecting to the Computer .............................. 11

Operations......................................................... 12-13

Playing Music.....................................................14-16

Section Repeat.................................................. 16-17

Browsing................................................................. 18

Mode Switch...................................................... 18-21

Receive FM Radio............................................. 22-23

Record...............................................................24-25

Menu Function...................................................26-35

USB Host Function............................................ 36-38

Cautions.................................................................. 39

Troubleshooting.................................................40-43

Accessory............................................................... 44

Specification........................................................... 45

English Manual

Front Part

LCD

Stop/Power Off

Right

Play/Pause/

Power On

Left

Volume+

Volume-

MusePod

SidePart

LCD

A-B/Rec

SRS/Mode

Hold

CHARGE LED

MIC Hole

Line-In

USB Port

Reset Hole

USB Host Portne

DC-IN

Earpho

English Manual

Current Mode

EQ Re

eat Mode Hold

Batter

Indicato

Current Folde

File Name

ID3 Artist Track Playing

Progress

Sam

lin

Rate Bitrate Volume

MusePod

Using the AC adapter

1. The AC adapter supplied with the player can be

used only.

Working voltage of the AC adapter of the player is

100/240V, 50/60Hz.

2. Connect the adapter to the DC jacks of the AC

power and the player

Charging

1. When the player is powered on, the status of the

battery indicator shows the battery capacity of the

player. When the battery is low, the icon will be

twinkling. After twinkling for a while the system will

be shutdown automatically. The battery must be

charged immediately, otherwise the player cannot

continue to work. Before connecting the player to

the computer, please make sure that it is in low

voltage, or the connection to the PC will fail.

2. Charging will start automatically after the adapter is

connected to the power. In the power-on status, the

power-connecting icon is shown in the position of

the original battery indicator icon. It shows that the

battery is being charged and the red LED is always

on. When charging in the power-off status, the red

LED is always on.

English Manual

3. When the battery is fully charged, the battery

indicator is fully filled in and the red LED will be off.

Charging time: about 3 hours (after the battery is

fully discharged)

Discharging time (playing time): about 12 hours

(the longest playing time after the battery is fully

charged)

Playing time is measured during playing 128Kbps

Mp3 files in the fully charged status. (It is practically

measured without any operations)

Software Installation

Windows 2000 and Windows XP themselves can

support USB2.0 storage device (PC must be with

USB2.0 port, otherwise it will be transmitted by the

USB1.1 standard), but Windows 98 requires the

driver to be installed. We supply you with the

manager software of the hard-disk player and the

driver. After the installation is completed, you can

now operate the player.

Please plug CD to CD-ROM, then it will install

software automatically if you did not close

CD-ROM Auto function. Then execute Next step

one by one, you can finish installing. During

installing, if you use Win98 operation system, it
