BIND : First blink after power on indicate the receive mode, ■S-FHSS, ■D16 non-EU, ■D16 EU-LBT.
D16 non-EU and EU-LBT BIND
Turn on the TX, then power on AC2000 while pressing the
key, GREEN LED fast blink meaning bind mode, user can
release the key. Bind procedure is completed and the
receiver working normally when GREEN LED solid.
Power off the TX, Power on AC2000 while pressing the key,
GREEN LED fast blink meaning bind mode. Set TX into D16
bind mode, RED LED solid meaning bind success. TX exit
bind mode, GREEN LED solid meaning working normally.
RECEIVE MODE SWITCH:When AC2000 RED or GREEN LED solid, Press the key and hold LED will go off, after 3 seconds
YELLOW LED will turn on, release the key AC2000 will switch to another receive mode and restart automatic.
FAILSAFE: Please set failsafe in your radio, depend on the radio S-FHSS, D16 non-EU and D16 EU-LBT shoWuld have at
least 2 failsafe settings as follow (different radio may name the setting differently):
1. HOLD, S.BUS sent the value when received last time, we suggest switch channel use this setting.
2. CUSTOM, this setting can custom S.BUS sent value when no signal.
In most cases, user can set AIL, ELE, YAW middle (CUSTOM 1500), THR low (CUSTOM less than 950), other switch channels
use HOLD. In most cases please make sure [ARM] / [DISARM] channel failsafe setting HOLD in [ARM] value. Because if
failsafe setting use [DISARM] value when briefly lost signal, the drone will switch in [DISARM] state, once the signal from radio
received the drone maybe can’t switch to [ARM] state because THR high (more than 1000), this will result crash when briefly
lost signal. So [ARM] / [DISARM] channel failsafe setting should HOLD in [ARM] value or use CUSTOM in [ARM] value, if
signal lost a long time because THR low (less than 950), drone will just crash, not fly away.
Before first flight, we suggest remove propeller then [ARM] the drone, push THR middle make motor rotating, power
off the radio to simulate lost signal, motor should STOP or IDLE rotating, correct failsafe setting is when power on the
radio drone should can control immediately not need do [ARM] / [DISARM].
AC2000 have 2 LEDs correspond to the 2 wireless systems, we call them W1
and W2 for short. By default, receiver read W1 first, so when signal good W1’s
LED should BLUE (preferred signal), W2’s LED should GREEN (backup signal),
Receiver will use W2 when W1 lost signal, W2’s LED will BLUE at this time.
Two antennas should be placed
at 90 degrees to each other.
Suggest distance test befor use, when close to THE FURTHEST DISTANCE：
<a> . Hold W1 antenna, W2’s BLUE LED should turn on.
<b> . Release W1 antenna, hold W2 antenna, W1’s BLUE LED should on.
If hold antenna can not cause BLUE LED switch when colse to THE FURTHEST
DISTANCE，maybe another antenna place unreasonable cause signal bad.
(NOTICE: when signal good, hold antenna will not cause BLUE LED switch)
