Worx WG713E Manuel utilisateur

WG713E

Electric lawn mower

Электрическая газонокосилка

P07

P15

A1 A2

1 — 20mm

2 — 30mm

3 — 40mm

4 — 50mm

5 — 60mm

6 — 70mm

7 — 80mm

100%

M2-1

M2-2

M2-3

M1-1

M1-2

M1-3

Electric lawn mower EN

GENERAL SAFETY WARNINGS

WARNING Read all

safety warnings and

all instructions. Failure to

follow the warnings and

instructions may result in

electric shock, ﬁre and/or

serious injury.

Carefully read the

instructions for the safe

operation of the machine.

Save all warnings and

instructions for future

reference.

- This appliance is not

intended for use by persons

(including children) with

reduced physical, sensory

or mental capabilities,

or lack of experience

and knowledge, unless

they have been given

supervision or instruction

concerning use of the

appliance by a person

responsible for their safety.

- Children should be

supervised to ensure that

they do not play with the

appliance.

- If the supply cord is

damaged, it must

be replaced by the

manufacturer, its service

agent or similarly qualiﬁed

persons in order to avoid a

hazard.

ADDITIONAL SAFETY RULES

FOR LAWN MOWER

Training

a) Read the instructions

carefully. Be familiar with

the controls and the proper

use of the equipment;

b) Never allow children or

people unfamiliar with

these instructions to use

the lawn mower. Local

regulations can restrict the

age of the operator;

c) Never mow while people,

especially children, or pets

are nearby;

d) Keep in mind that the

operator or user is

responsible for accidents

or hazards occurring to

other people or their

property

Preparation

a) While mowing, always

wear substantial footwear

and long trousers. Do not

operate the equipment

when barefoot or wearing

open sandals;

b) thoroughly inspect the

area where the equipment

is to be used and remove

all objects which can be

thrown by the machine;

c) Before using, always

visually inspect to see that

the blades, blade bolts

and cutter assembly are

not worn or damaged.

Replace worn or damaged

blades and bolts in sets to

Electric lawn mower EN

preserve balance;

d) on multi-bladed machines,

take care as rotating one

blade can cause other

blades to rotate.

Operation

a) mow only in daylight or in

good artiﬁcial light;

b) avoid operating the

equipment in wet grass,

where feasible;

c) always be sure of your

footing on slopes;

d) walk, never run;

e) for wheeled rotary

machines, mow across the

face of slopes, never up

and down;

f) exercise extreme caution

when changing direction on

slopes;

g) do not mow excessively

steep slopes;

h) use extreme caution when

reversing or pulling the

lawn mower towards you;

i) stop the blade(s) if the

lawn mower has to be

tilted for transportation

when crossing surfaces

other than grass, and when

transporting the lawn

mower to and from the

area to be mowed;

j) never operate the lawn

mower with defective

guards, or without safety

devices, for example

deﬂectors and/or grass

catchers, in place;

k) switch on the motor

carefully according to

instructions and with

feet well away from the

blade(s);

l) do not tilt the lawn mower

when switching on the

motor, except if the lawn

mower has to be tilted for

starting In this case, do not

tilt it more than absolutely

necessary and lift only the

part which is away from the

operator;

m)do not put hands or feet

near or under rotating

parts. Keep clear of the

discharge opening at all

times;

n) never pick up or carry a

lawn mower while the

motor is running;

o) not to touch the blades

before disconnecting the

plug and the blades have

come to a complete stop;

p) Stop the motor and

disconnect the plug from

the mains:

- whenever you leave the

machine;

- before clearing a blockage;

- before checking, cleaning

or working on the lawn

mower;

- after striking a foreign

object, Inspect the lawn

mower for damage and

make repairs as necessary;

- if the lawn mower starts to

vibrate abnormally (check

immediately);

Electric lawn mower EN

Maintenance and storage

a) keep all nuts, bolts and

screws tight to be sure

the equipment is in safe

working condition;

b) check the grass catcher

frequently for wear or

deterioration;

c) replace worn or damaged

parts for safety;

d) ensure that only

replacrment cutting means

of the right type are used;

WARNING:

- Not to use the lawn mower

if the cords are damaged or

worn.

- Not to connect a damaged

cord to the supply or touch

a damaged cord before it

is disconnected from the

supply. A damaged cord

can lead to contact with live

parts.

- Not to touch the blades

before the machine is

disconnected from the

supply and the blades have

come to a complete stop.

- To keep extension cords

away from the blades.The

blades can cause damage

to the cords and lead to

contact with live parts.

- To disconnect the supply

(i.e, pulling the plug from

the socket)

- whenever leaving the

machine unattended,

- before clearing a blockage,

- before checking, cleaning or

working on the machine,

- after striking a foreign

object,

- Whenever the machine

starts vibrating abnormally.

- To carefully read the

instructions for the safe

operation of the machine;

- Recommendations:

- To connect the machine

only to a supply circuit

protected by a residual

current device (RCD ) with a

tripping current of not more

than 30 mA.

SYMBOLS

Read instruction handbook

before operation this machine

Keep bystanders away.

Beware of sharp blades.

Blades continue to rotate

after the motor is switched

off- Remove plug from mains

before maintenance or if cord is

damaged.

Electric lawn mower EN

Keep the supply ﬂexible cord

away from the blades.

1. SWITCH LEVER

2. HOOK

3. SAFETY KEY

4. CABLE CLIP

5. UPPER HANDLE

6. LOWER HANDLE

7. MOTOR COVER

8. CUTTING HEIGHT ADJUSTMENT KNOB

9. CARRY HANDLE

10. HANDLE KNOB, LOWER

11. SAFETY FLAP

12. GRASS COLLECTION BAG

13. GRASS BAG INDICATOR

14. BAG HANDLE

15. HANDLE KNOB, UPPER

16. BLADE BOLT (SEE FIG. K1)

17. BLADE (SEE FIG. K1)

*Not all the accessories illustrated or de-

scribed are included in standard delivery.

TECHNICAL DATA

Type WG713E (7 - designation of machinery,

representative of Lawn Mower)

WG713E

Rated voltage 220V-50HZ

No load speed 3800/min

Cutting diameter 34cm

Cutting height 25-75mm

Cutting height positions 6

Front wheel diameter 140mm

Rear wheel diameter 160mm

Grass collection

capacity 30L

Machine Weight 10.5kg

ACCESSORIES

WG713E

Grass collection bag 1

Cable clips 2

Handle knobs 4

Shims 4

We recommend that you purchase your accessories

listed in the above list from the same store that sold

you the lawnmower. Use good quality accessories

marked with a well-known brand name. Refer to

the accessory packaging for further details. Store

personnel can assist you and offer advice.

OPERATION INSTRUCTION

NOTE: : Read instruction handbook

before operation this machine.

Intended Use

This product is intended for domestic lawn

mowing.

ASSEMBLY AND OPERATION

ACTION FIGURE

ASSEMBLY

Assembling the handle bar

NOTE: Choose one of the two

holes in the lower handle for

desired handle’s height.

See Fig. A1,

A2, A3, A4
