C100 Counting Scale
Owners Manual
V2.40
CONTENTS
1. SPECIFICATIONS……………………………………………………………..1
2. PRECAUTIONS………………………………………………………………..2
3. INSTALLATION……...…………..…………………….……………………..…3
Remote Scale Setup………………………..…………………………4
4. KEYS AND FUNCTIONS…………….………………………………………5
Key board………………………………...................................................5
Display………………………………………………………………………6
5. OPERATION………………………………………………………….…………7
Power On/Off…………………….…………………………………………7
Switch to local / Remote Scale….…....………………………………….7
Zero……………………………….…………………………………………7
Tare………………………………………………………………………….7
Accumulation………………………………….………………………….8
Manual Accumulation……………………………………………………..8
Saved Data…………………………………………………………………9
Delete Data…………………………………………………………………9
Automatic Accumulation………………………………………………….9
Parts Counting………………………………………………………..…..9
Weighing a sample to determine the Unit Weight…………………….. 10
Enter a known Weight……………………………………………………..10
Automatic update of Unit Weight…………………………………………10
Check weighing of count pre-set…………………………………………11
Setting the checking limits………………………………………………..11
PLU (Product Look Up)………………………………………………….11
Storing PLU………………………………………………………………...12
Entering Description manually……………………………………………13
Recalling PLU……………………………………………………………...13
6. PARAMETERS…………………………………………………………………14
Keys into the parameter…………………………………………………..14
Parameter settings………………………………………………………...15
7. RS-232 OUT PUT………………………………………………………………16
8. ERROR CODES………………….…………………………………………...17
9. DRAWING……………………...……………………………………………...18
Pa r ts L ist…… …… … ……… … …… … … …… … ……… … …… .19
C100 Series Owners Manual
- 1 -
1. SPECIFICATIONS
DIMENSIONS
Specification
MODEL
C100/6
C100/12
C100/30
C100/60
Part Number 899-300000 899-300001 899-300002 899-300003
Maximum
Capacity
6 lb
12 lb
30 lb
60 lb
3 kg
6
kg
15
kg
30
kg
Readability
.0001 lb
.0002 lb
.0005 lb
.001 lb
.00005
kg
.0001 kg
.0002 kg
.0005
kg
Units of
Measure
lb, kg
Interface
Bi
-
directional RS
-
232 Interface
Stabilization Time
2 Seconds
Operating Temperature
(
32°F
-
104°F
)
Power supply
AC Adaptor 9 V/800 mA / Battery 6V4AH
Calibration
Automatic external
Display
3 x 6
digits LCD digital display with white LED back light
Housing Indicator
ABS Plastic, Stainless Steel p
an
P
latter
size
8.9 x 11.8”
Overall dimensions
12.6 x 13.4 x 4.9”
Net weight
9.5lb
Internal Resolution
Up to
60000
C100 Series Owners Manual
- 2 -
2. PRECAUTIONS
Read this manual before operating or servicing this
equipment.
Follow these instructions carefully.
Disconnect this equipment from the power source
before cleaning of performing maintenance.
Keep the manual for your future reference.
Avoid extremes of temperature. Do not place in
direct sunlight or near air conditioning vents.
Avoid unsuitable tables. The table or floor must be
rigid and not vibrate. Do not place near vibrating
machinery.
Avoid unstable power sources. Do not use near
large users of electricity such as welding equipment
or large motors.
Avoid high humidity that might cause condensation.
Avoid direct contact with water. Do not spray or
immerse the scales in water.
Avoid air movement such as from fans or opening doors. Do not place
near open windows.
Do not stack material on the scales when they are not in use.
Keep the scales clean.
C100 Series Owners Manual
- 3 -
3. INSTALLATION
Unpacking
Carefully take the C100 out of its packaging, making it sure its not damaged and
all accessories are included.
If equipped, remove the shipping safety screw. Indicated by the red label on the
bottom of the C100
Accessories,
1. C100
2. Power Adaptor
3. Stainless steel pan
4. 18’ pre-made remote base cable
5. Product manual
6. User Manual
Keep the packaging material for your future use.
C100 Series Owners Manual
- 4 -
SETUP
Local Scale:
Note: Battery should be charged for 12 hours prior to first use.
Place the scale on a table.
Place the platform in the locating holes on the top cover.
Do not press with excessive force as this could damage the load cell
inside.
Check the water mark. If, bubble is not centered adjust the leveling feet
until centered. Check the level when you change the location.
Attach the power supply cable to the connector on the bottom right side of
the scale base. Plug in the power supply.
Turn on the Scale. The power switch is located at the right side of the
scale base.
The scale will show the model number in the “Weight” display and will be
start self test countdown.
Remote Scale:
The C100 Series can be connected remote base through the Remote
scale port on the left side of the scale case.
Place the remote scale platform in the position where it is to be used.
Level the scale by adjusting the four feet. Making sure it is level.
Press key to change between remote base and local base.
C100 Series Owners Manual
- 5 -
4. KEYS AND FUNCTION
Key Board
Keys
Press this key to
to
Numeric Keys. To enter either individual unit weights or
preset tare
Clear incorrect entries and error conditions
Decimal Point.
Returns the display to zero.
Enter to clear tare weights, Storing the current weight as
tare value. Subtracting the tare value from the total weight
and displays the result as a net weight.
Manually enter the weight of sample, also changes the unit
from lb to kg if they are enabled.
To enter the numbers of items, used as the sample unit
weight.
Add the current count data aggregated. Also Clear the
memory if pressed when balance empty. Can add up to 99
values, or until it reaches the maximum displayable digits
Enter to store and recall the PLU (piece look up)
To set the upper limit of the number of items counted and
back light setting.
To select the local or remote scale.
C100 Series Owners Manual
- 6 -
Display
The arrow “▼” above the symbols
Weight Display
Low Battery
Net
Net Weight Display
ed
Stable
Stable Display
ed
Zero
Zeroing Display
ed
Lb / kg
Current Weighing Mode
Unit Weight Display
Smpl
# of sample
is very low
U.Wt Unit weight is below the minimum
weight
M+
Data entered into the memory
Local /
Remote
Active Scale in use
Count Display
CkPcs
Active in Counting Mode
Wt
Active in Weighing Mode
High
Check Result above the high limit
OK
Check Result with in the limit
Low
Check Result belo
w the low limit
Charge
Status of the battery charging
C100 Series Owners Manual
- 7 -
5. OPERATION
Initial Start-up
Please allow 15 minutes of warm-up time to weight value to stabilizes after
switching on.
1. Power ON/OFF
Power switch is located below the bottom right side of the scale. Switch on
the scale by pressing on/off. The display is switched on and the self test is
started.
If you want to switch off press in the switch in the opposite direction.
2. Switch to Local / Remote Scale
By pressing the display changes from one scale to other scale.
In Local Scale
In Remote Scale
The basic weighing functions are same for both the scales local or
remote.
The number of weighing divisions may be less on the remote scale
dependant on the total capacity of the load cell/s used.
3. Zero
To zero the scale at any time press the key
4. Tare
The weight of any container can be tared by pressing the button so
that with subsequent weighings the net weight of the object being weighed
is always displayed.
Load container to be tared on the pan.
Press the key. Zero is displayed, and tare is subtracted.
Remove weight from the platform. Tared weight is displayed. Only
one tare value can be set. It can be displayed with a minus value.
Once tare is stored, Pressing the key, will clear the tare weight
and Zero the display.
change
Local
change
remote
