The Angle-Ease ﬁts

motors from these routers:

Router Model FITS 3.5”

ANGLE-EASE

FITS 4.2”

ANGLE-EASE

Porter Cable 7518 No Yes

Milwaukee 5625 No W/ Shim

Porter Cable 892 Yes W/ Adapter R1

Porter Cable 690 Yes W/ Adapter R1

DeWalt 616/618 Yes W/ Adapter R1

Bosch 1617/1618 Yes W/ Adapter R1

1470 & 1472 Angle-Ease™

6002 & 6004 Angle-Ease

Owners Manual

Please Read Carefully!

Additional Parts List:

Parts listed below are not shown in the hardware

drawings. Refer to photos in the instructions:

Part Description Quantity

1470AS Side/Arm Assembly, pair . . . . . . . . . . . . . . . . 1

1470C 7-1/2” Double Track . . . . . . . . . . . . . . . . . . . . . 2

1475A1 Adjuster Arm .......................... 1

1475A2 Arm Plate ............................. 1

1475B Height Adjuster . . . . . . . . . . . . . . . . . . . . . . . . 1

Ringpin1 Pin .................................... 2

5863 1-1/8” Knob ............................ 2

5864 1-5/8” Knob ............................ 2

In addition, you will get ONE of the motor

blocks and plates below, depending on the

Angle-Ease model you purchased:

1470B 3.5” Motor Block . . . . . . . . . . . . . . . . . . . . . . . . 1

1472B 4.2” Motor Block. . . . . . . . . . . . . . . . . . . . . . . . 1

1470P Angle Ease Router Table Plate . . . . . . . . . . . 1

6000PA Horizontal Table Angle-Ease Plate . . . . . . . . 1

Part# Description Qty.

MF015 1” Screw 6

Part# Description Qty.

WN001 Nylon washer 4

Part# Description Qty.

WB002 Washer 4

Part# Description Qty.

5791B Barrel Nut 3

Part# Description Qty.

5760B Oval Nut 12

Part# Description Qty.

MF010 3/4" Screw 8

Part# Description Qty.

BUSH002 1/4" Spacer 4

BEFORE BEGINNING

 Identifyandverifythatyouhaveallthepartslisted.

Readtheinstructionsatleastonce,familiarizingyourselfwith

theparts,beforebeginningassembly.You’llneedtwo7/16”

wrenches,a#3Phillipsscrewdriverandaflatbladescrewdriver.

Part# Description Qty.

5771B 3/4" Screw 2

ATTACH HARDWARE

 Alignthepointerinthearmonbothside/armassemblieswiththe10ºmark

onthescale. Insertapin (Ringpin1) throughthe10ºholeinthesideandintothe

holeinthearm.Installawasher(WB002)andanylonwasher(WN001)onthe

studoftheknobs(5863).Laytheside/armassemblyflatonthearmandslide

anothernylonwasher(WN001)betweenthearmandtheside.Useacreditcard

orputtyknifetoalignthewasherwiththecurvedslotinthesideandthethreaded

holeinthearm.Insertthestudoftheknobthruthecurvedslotintheside,

screwingitintothearm,thentightentheknob.



 Insert1”screws(MF015)thruthethreecountersunkholesineachsideand

startanovalnut(5760B - flat side first)oneachscrew.Slidea7-1/2”double

track(1470C) ontotheovalnutsoneachside.Centerthedoubletrackend-to-end

ontheside,checkthesideforsquareonaflatsurfaceandtightenthescrews.



 Removethepinfromeacharm,loosenthehandleandrotatethearm

tothe0ºmarkontheside,thenreinstallthepinandtightentheknob.

ATTACH ROUTER BLOCK

 Settherouterblock (1470B or 1472B) onend,

withtheclampingknobintherouterblockatthe

bottom.Insertabarrelnut(5791B)intheholein

thefaceoftherouterblocknearthetop.Useaflat

bladescrewdrivertoalignthethreadedholeinthe

barrelnutwiththecrossholeintherouterblock.

 Installawasher(WB002)andtwo1/4”spacers

(BUSH002)ontheknobs(5864). Settheside/armassembly

withtheadjusterarmattachedtoit,withthearminthe

grooveintherouterblock.Installtheratchethandlethru

theslotinthearm,screwingitintothebarrelnut.Slidethe

routerblockasfardownonthearmaspossible(towards

the double track)andtightentheknob.Fliptheassembly

overandconnecttheremainingside/armassemblytothe

oppositesideoftherouterblockinthesamemanner.

Ringpin1

WN001

MF015 x3

5760B x3

5863

WB002

WN001

5864

WB002

BUSH002 x2

5791B x2

INSTALL HEIGHT

ADJUSTER ARM

 Selecttheside/arm

assembly(1470AS) thathas

thearmwiththesquared-off

cornerandattachtheadjuster

arm(1475A1)toitusing

two3/4”screws(MF010).

 Pivotthearmas

necessarytoaccessthelower

mountingholeinthearm.

MF010 x2

1470AS

1475A1

1470C

ATTACH ASSEMBLY TO PLATE

 Insert3/4”screws(MF010)thruthesix

countersunkholesintherouterplate (1470P or

6000PA)andstartovalnuts(5760B - flat side

first)ontheendsofthescrews.Linetheoval

nutsupwiththeT-slotinthedoubletracks

andslidetheassemblyontotheovalnuts.

 Ifyouhavethe1470Pplate,positiontheassembly

sothefrontedgeofthesidesare15/16”fromthefront

edgeoftheplateandtightenthescrews.Theopeninginthe

routerblockshouldbeoverthebitopeningintherouterplate.

 Ifyouhavethe6000PAplate(not shown),positionthe

assemblysothebackedgeofthesidesareflushwiththeback

edgeoftheplateandtightenthescrews.Theopeninginthe

routerblockshouldbeoverthebitopeningintherouterplate.

INSTALL REMAINDER OF HEIGHT ADJUSTER

 Installabarrelnut(5791B)intheholeinthefrontof

therouterblock.Useaflatbladescrewdrivertoalignthethreaded

holeinthebarrelnutwiththecrossholeintherouterblock.



Spreadapartthetwonylonwashersonthethreadedrodoftheheightadjuster(1475B) sotherod

slipsinthegrooveintheadjusterarmandthewashersareoneachsideofit.Screwthethreadedrod

intothebarrelnutuntilthenylonwasheronthetopoftheadjusterarmissnugagainstthetopofthe

adjusterarm.

 Placethearmplate (1475A2)withit’sgroovecoveringthethreadedrodandfastenitto

theadjusterarmusingthetwo3/4”screws(5771B).Alignthetopandbottomedgesofthe

armplatetothecorrespondingedgesoftheadjusterarm(1475A1) andtightenthescrews.

 Adjustthetwonutsonthethreadedrod,alongwiththewashers,against

theundersideoftheadjusterarm.Tightenthenutsagainsteachotherwhen

youhaveadjustedtheup/downslopoutoftheheightadjuster.

ROUTER INSTALLATION

 Loosentheclamphandleintherouterblockandinsert

yourrouterintherouterblocksotheendof

themotorisflushwiththerouterblock,or

protrudingoutpastit..



The router motor should always be

fully inserted in the router block! Never

insert a router motor partially in the

router block! 



Theroutermotorcanberepositioned

anywhereinthemotorblockaslong

asitiscompletelyinthemotor

blockatalltimes.Tightenthe

clamphandlejustenoughto

holdtheroutermotor.Donotover-

tightenoryoumaydamageyourrouter.

5771B x2

5791B

1475B

MF010 x6

5760B x6

15/16” from

Front Edge

1475A2

ANGLE SETTINGS

 Therearepinsettingsat0,5,

10,15,20,22-1/2,25,30,35,40

&45degrees,oryoucansetyour

desiredangleusingthescaleontop

ofthesidesasaguide.Tosetan

angle,removethetwopins(ifused),

loosenthetwoangleadjustment

knobsandpivottheroutertothe

desiredangle.Replacethepins(if

theangleisoneofthepinsettings

above)andtightentheknobs.

 Anglesettingsotherthan

thoseprovidedcanbesetusing

adraftingsquareorbevelgauge

placedbetweentheplateand

thefaceoftherouterblock.

HEIGHT ADJUSTMENT

IMPORTANT!! Loosen the

height knob nearest the Height

Adjuster just 1/4 to 1/2 of a turn

and loosen the opposite height

knob 2 full turns. Retighten the

knob nearest the Height Adjuster

first, then retighten opposite knob.

Turnthecrankhandleon

theHeightAdjustertomovethe

routerupordown.Ifyoucannot

achievethedesiredheight,you

mayhavetorepositiontherouter

intherouterblock(seerouter

installationsectionabove).

USING THE ANGLE EASE

 Therearetworatchetknobsforlockingtheheightandtwoforlockingtheangle.

Performoneoftheseadjustmentsatatimeinsteadofattemptingbothadjustments

atthesametime.Makesureyourbitislockedsecurelyintherouter

colletandthatallknobsaretightenedsecurelybeforeusing.

 Dependingonyourtableopeningsize,

youmayhavetosettheAngle-Easeat0º

degreestoinsertitinyourroutertable.

 Toreducetheriskofinjurywerecommend

thatyoutiltthecutterintothefence(or

table)hidingmoreofthecuttercompared

totiltingthecutterawayfromthefence(or

table)andexposingmoreofthecutter.

©Copyright WOODHAVEN INC. 5/15/15

(800) 344-6657 or WWW.WOODHAVEN.COM

A: Remove Pins,

B: Loosen Knobs

C: Adjust Angle

A: Loosen

Knobs

B: Adjust

Height
