WOLF DESIGN GUIDE

Contents

Ovens and Warming Drawers ................... 3

Cooktops and Modules ....................... 37

Ranges and Rangetops ....................... 61

Outdoor Grills and Modules .................... 83

Cooktop Ventilation .......................... 91

Pro Ventilation ............................. 105

Ventilation Recommendations ................. 112

Shipping Weights ........................... 116

Wolf Warranties ............................ 118

IMPORTANT NOTE: Throughout this guide, dimensions may

vary by ± 1/8"(3).

Features and specifications are subject to change at any time

without notice. Visit wolfappliance.com/specs for the most

up-to-date information.

Throughout this guide, dimensions in parentheses are millime-

ters unless otherwise specified.

MODEL SO30U

Wolf Built-In Ovens 3

wolfappliance.com/specs

L Series Ovens. Since their introduction a few short years ago, Wolf L series electric ovens have taken the culinary

world by storm—and not just for their stylish cobalt blue interior and 10 cooking modes. Thanks to a Wolf innovation called

dual convection, the L series delivers faster, more consistent results for baking, roasting, broiling—even drying fruits. Wolf

L series ovens are crafted of stainless steel in framed and unframed door styles with tubular handles.

SO30F

30" (762) SINGLE

FRAMED

SO30U

30" (762) SINGLE

UNFRAMED

SO36U

36" (914) SINGLE

UNFRAMED

DO30F

30" (762) DOUBLE

FRAMED

DO30U

30" (762) DOUBLE

UNFRAMED

KEY FEATURES L SERIES OVENS

•Dual convection: two fans for even heat distribution.

•Ten cooking modes, including the bake stone and

dehydration kits for precise, easy-to-use control.

•Rotating control panel.

•Self-cleaning ovens.

•Full-extension bottom rack for easier access to foods.

•Spring and damper door hinge for quiet, effortless

opening and closing of the door.

Wolf Built-In Ovens 4

24" (610)

BEHIND FRAME

271/2"

(699)

283/16"

(716)

28"

(711)

297/8"

(759)

24"

(610)

(76) 203/4"

(527)

261/16"

(662)

INSIDE

SIDE TRIM

TOP VIEW

OPEN OVEN DOOR

FRONT VIEW RIGHT SIDE VIEW

CONDUIT

CHANNEL

95/8"

(244)

87/8"

(225)

3" (76)

24" (610)

BEHIND FRAME

243/8"

(619)

355/8"

(905)

24"

(610)

23" (584)

INSIDE

SIDE TRIM

341/8"

(867)

3311/16"

(870)

(76)

173/4"

(451)

TOP VIEW

OPEN OVEN DOOR

FRONT VIEW RIGHT SIDE VIEW

CONDUIT

CHANNEL

95/8"

(244)

87/8"

(225)

3" (76)

L Series Ovens

30" (762) SINGLE OVENS

36" (914) SINGLE OVEN

Wolf Built-In Ovens 5

wolfappliance.com/specs

50"

(1270)

297/8"

(759)

24" (610)

BEHIND FRAME

24"

(610)

OPEN OVEN DOOR

283/16"

(716)

28"

(711)

(76)

203/4"

(527)

481/2"

(1232)

INSIDE

SIDE TRIM

CONDUIT

CHANNEL

95/8"

(244)

87/8"

(225)

3" (76)

TOP VIEWFRONT VIEW RIGHT SIDE VIEW

L Series Ovens

30" (762) DOUBLE OVENS

Specifications

INTERIOR CAPACITY CU FT (L)

30" (762) Oven 4.5 (127)

36" (914) Oven 4.4 (125)

INTERIOR DIMENSIONS W H D

30" (762) Oven 25" (635) 161/2"(419) 19" (483)

36" (914) Oven 30" (762) 131/4"(337) 19" (483)

Wolf Built-In Ovens 6

SO30-2F/S-TH

30" (762) SINGLE

FRAMED

SO30-2U/S-TH

30" (762) SINGLE

UNFRAMED

DO30-2F/S-TH

30" (762) DOUBLE

FRAMED

DO30-2U/S-TH

30" (762) DOUBLE

UNFRAMED

KEY FEATURES

•Dual convection: two fans for even heat distribution.

•Ten cooking modes, including the bake stone and

dehydration kits for precise, easy-to-use control.

•Self-cleaning ovens.

•Full-extension bottom rack for easier access to foods.

•Balanced door hinge system for smooth opening and

closing of the door.

E Series Ovens. The newest addition to the Wolf built-in oven family is a true partner, helping to create great meals

with ease, as well as adding a striking design feature to the kitchen. Smart technology gives the E series 10 cooking modes,

with Wolf’s innovative dual convection in single ovens and in the upper unit of double ovens. E series ovens can be installed

flush with cabinets for a contemporary, integrated look. Wolf E series ovens are crafted of stainless steel in framed and

unframed door styles with tubular handles. New black glass models with tubular handles are also available.

E SERIES OVENS

MODEL SO30-2U/S-TH

SO30-2B/G-TH

30" (762) SINGLE

BLACK GLASS

DO30-2B/G-TH

30" (762) DOUBLE

BLACK GLASS

Wolf Built-In Ovens 7

wolfappliance.com/specs

E Series Ovens

233/4"(603)

BEHIND FRAME

277/8"

(708)

297/8"

(759)

CONDUIT

CHANNEL

1" (25)*

271/16"

(687)

25/8"*

(67)

*For black glass model, increase dimension by 1/4"(6).

3" (76)

281/4"

(718)

233/4"

(603)

22"

(559)

95/8"

(244)

87/8"

(225)

297/8"

(759)

TOP VIEW

OPEN OVEN DOOR

FRONT VIEW RIGHT SIDE VIEW

30" (762) SINGLE OVENS

30" (762) DOUBLE OVENS

Specifications

INTERIOR CAPACITY CU FT (L)

30" (762) Oven 4.5 (127)

INTERIOR DIMENSIONS W H D

30" (762) Oven 25" (635) 161/2"(419) 19" (483)

233/4"(603)

BEHIND FRAME

503/8"

(1280)

491/2"

(1257)

297/8"

(759)

25/8"*

(67)

1" (25)*

*For black glass model, increase dimension by 1/4"(6).

CONDUIT

CHANNEL

281/4"

(718)

233/4"

(603)

OPEN OVEN DOOR

22"

(559)

297/8"

(759)

95/8"

(244)

87/8"

(225)

3" (76)

TOP VIEWFRONT VIEW RIGHT SIDE VIEW

Wolf Built-In Ovens 8

ELECTRICAL REQUIREMENTS

Planning Information

STANDARD INSTALLATION

For ease of installation, Wolf recommends using 33" (838)

wide cabinets with 30" (762) ovens and a 39" (991) wide

cabinet with the 36" (914) L series oven. For standard

installations, a minimum 24" (610) of usable cabinet depth

is required. The cabinet must be able to support 250 lbs

(113 kg) for a single oven and 400 lbs (181 kg) for a double

oven.

The oven has a face trim on all four sides and will overlap

stiles and rails. Refer to the chart for overlap dimensions.

FLUSH INSET INSTALLATION (E SERIES ONLY)

For flush inset installations, the E series oven requires a

minimum 25" (635) deep cabinet. A minimum 1/4"(6) reveal

is required on all four sides. The inside edges of the rough

opening must be finished, as they will be exposed when

the oven door is open. These edges should be stained

instead of having a laminated surface, to avoid damage

from high temperatures.

Oven Trim Overlap

OVEN TRIM L SERIES E SERIES

Top Overlap 3/16"(5) 5/8"(16)

Bottom Overlap 1/8"(3) 1/8"(3)

Side Overlap 3/4"(19) 3/4"(19)

Electrical Requirements

SINGLE OVENS

Electrical Supply Grounded 4-wire, 240/208 V AC, 60 Hz

Service 30 amp dedicated circuit

Total Amps 21

Conduit 4' (1.2 m),3'(.9 m) for SO36U

DOUBLE OVENS

Electrical Supply Grounded 4-wire, 240/208 V AC, 60 Hz

Service 50 amp dedicated circuit

Total Amps 37

Conduit 5' (1.5 m)

Wolf Built-In Ovens 9

wolfappliance.com/specs

36" (914)

FLOOR TO

COUNTERTOP

341/2"(876)

OPENING WIDTH

241/16"

(611)

OPENING

HEIGHT

(127)

(102)

73/4"(197)

TYPICAL*

DIMENSION WILL VARY*

24" (610) min

OPENING DEPTH

FRONT VIEWSIDE VIEW

*Dimension must accommodate height of oven trim.

NOTES: Location of electrical supply within oven opening may require additional cabinet depth.

Dashed line represents profile of unit.

36" (914) L Series Single Oven

STANDARD INSTALLATION

DIMENSION WILL VARY*

43/4"(121) TYPICAL*

36" (914)

FLOOR TO

COUNTERTOP

*Dimension must accommodate height of oven trim.

NOTES: Location of electrical supply within opening may require additional cabinet depth.

Dashed line represents profile of unit.

281/2"(724)

OPENING WIDTH

273/16"

(691)

OPENING

HEIGHT

24" (610) min

OPENING DEPTH

(127)

(102)

FRONT VIEWSIDE VIEW

30" (762) L Series and E Series Single Oven

STANDARD INSTALLATION

Wolf Built-In Ovens 10

67" (1702)

TYPICAL*

495/8"

(1260)

OPENING

HEIGHT

281/2"(724)

OPENING WIDTH

(127)

(102)

24" (610) min

OPENING DEPTH

*Dimension must accommodate height of oven trim.

NOTES: Location of electrical supply within opening may require additional cabinet depth.

Dashed line represents profile of unit.

FRONT VIEWSIDE VIEW

30" (762) L Series and E Series Double Oven

STANDARD INSTALLATION
