Woan Technology SwitchBot W1101500 Manuel utilisateur
SwitchBot Motion Sensor User Manual
1.In the Box
Note: The visuals used in this manual are for reference only. Due to the future updates and
improvements of the product, the actual product images may differ.
2.Device Instruction
3.Preparation
A smartphone or tablet with Bluetooth 4.2 or above
Download the SwitchBot app
Create a SwitchBot account and sign in
4.Installation
1.Place it on a tabletop.
2.Mount the Base to the back or the bottom of the Motion Sensor. Adjust the sensor angel to
cover the desired space in your home. Place the sensor on a tabletop or stick it to an iron sur-
face.
3.Stick it to a surface using the 3M Sticker.
Installation Tips:
Make sure the sensor is not pointing to appliances or heat source in order to reduce interfer-
ence and to avoid false alarms.
The sensor senses up to 8m away and up to 120°, horizontally.
The sensor senses up to 8m and up to 60°, vertically.
Motion Sensor x 1 AAA batteries x 2 Base x 1 Sticker x 1
Reset Button
LED Indicator Light and Light Sensor
Fresnel Lens
5.Initial Setup
1.Remove the back lid of the sensor. Follow the "+"
and "-" marks, insert two AAA batteries into the
battery box. Put the back lid back.
2. Open the SwitchBot app and sign in.
3. Tap the "+" icon on the top right of the Home page.
4. Choose the Motion Sensor icon to add the device to your account.
6.Battery Replacement, Firmware, and Factory Reset
Battery Replacement
Remove the back lid of the sensor. Follow the "+" and "-" marks, replace the old batteries with
new ones. Put the back lid back.
Firmware
Make sure you have the up to date firmware by upgrading in time.
Factory Reset
Long press the Reset Button for 15 seconds or until the LED Indicator Light is on.
Note: After the device is reset, all settings will be set to the default values and the activity logs
will be erased.
7.Specification
Model Number：W1101500
Size：54*54*34mm
Weight：60g
Power & Battery Life：AAAx2, typically 3 years
Measure Range：-10℃~60℃，20~85%RH
Maximum Detection Distance: 8m
Maximum Detection Angle: 120° horizontally and 60° vertically
8.Return and Refund Policy
This product has one-year warranty (start from the purchasing day). The situations below do not
fit the Return and Refund Policy.
Intended damage or abuse.
Inappropriate storage (drop down or soaking in water).
User modify or repair.
Using loss.
Force majeure damage (Natural disasters).
9.Contact and Support
Setup and Troubleshooting: support.switch-bot.com
Feedback: If you have any concern or problem when using our products, please kindly send feed-
back from the Profile> Feedback page in the SwitchBot app.
10.CE Warning
Manufacturer's Name: Woan Technology (Shenzhen) Co., Ltd.
This product is a fixed location. To comply with RF exposure requirements, a minimum separation
Base
distance of 20cm must be maintained between the user’s body and the device, including the
antenna. Use only the supplied or an approved antenna.
This device in compliance with the essential requirements and other relevant provisions of Direc-
tive 2014/53/EU. All essential radio test suites have been carried out.
1. CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DIS-
POSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
2. The device complies with RF specifications when the device used at 20cm from your body
SwitchBot Motion Sensor User Manual
1.In the Box
Note: The visuals used in this manual are for reference only. Due to the future updates and
improvements of the product, the actual product images may differ.
2.Device Instruction
3.Preparation
A smartphone or tablet with Bluetooth 4.2 or above
Download the SwitchBot app
Create a SwitchBot account and sign in
4.Installation
1.Place it on a tabletop.
2.Mount the Base to the back or the bottom of the Motion Sensor. Adjust the sensor angel to
cover the desired space in your home. Place the sensor on a tabletop or stick it to an iron sur-
face.
3.Stick it to a surface using the 3M Sticker.
Installation Tips:
Make sure the sensor is not pointing to appliances or heat source in order to reduce interfer-
ence and to avoid false alarms.
The sensor senses up to 8m away and up to 120°, horizontally.
The sensor senses up to 8m and up to 60°, vertically.
5.Initial Setup
1.Remove the back lid of the sensor. Follow the "+"
and "-" marks, insert two AAA batteries into the
battery box. Put the back lid back.
2. Open the SwitchBot app and sign in.
3. Tap the "+" icon on the top right of the Home page.
4. Choose the Motion Sensor icon to add the device to your account.
6.Battery Replacement, Firmware, and Factory Reset
Battery Replacement
Remove the back lid of the sensor. Follow the "+" and "-" marks, replace the old batteries with
new ones. Put the back lid back.
Firmware
Make sure you have the up to date firmware by upgrading in time.
Factory Reset
Long press the Reset Button for 15 seconds or until the LED Indicator Light is on.
Note: After the device is reset, all settings will be set to the default values and the activity logs
will be erased.
7.Specification
Model Number：W1101500
Size：54*54*34mm
Weight：60g
Power & Battery Life：AAAx2, typically 3 years
Measure Range：-10℃~60℃，20~85%RH
Maximum Detection Distance: 8m
Maximum Detection Angle: 120° horizontally and 60° vertically
8.Return and Refund Policy
This product has one-year warranty (start from the purchasing day). The situations below do not
fit the Return and Refund Policy.
Intended damage or abuse.
Inappropriate storage (drop down or soaking in water).
User modify or repair.
Using loss.
Force majeure damage (Natural disasters).
9.Contact and Support
Setup and Troubleshooting: support.switch-bot.com
Feedback: If you have any concern or problem when using our products, please kindly send feed-
back from the Profile> Feedback page in the SwitchBot app.
10.CE Warning
Manufacturer's Name: Woan Technology (Shenzhen) Co., Ltd.
This product is a fixed location. To comply with RF exposure requirements, a minimum separation
8
60° 60°
5 5
8
60° 5
distance of 20cm must be maintained between the user’s body and the device, including the
antenna. Use only the supplied or an approved antenna.
This device in compliance with the essential requirements and other relevant provisions of Direc-
tive 2014/53/EU. All essential radio test suites have been carried out.
1. CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DIS-
POSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
2. The device complies with RF specifications when the device used at 20cm from your body
SwitchBot Motion Sensor User Manual
1.In the Box
Note: The visuals used in this manual are for reference only. Due to the future updates and
improvements of the product, the actual product images may differ.
2.Device Instruction
3.Preparation
A smartphone or tablet with Bluetooth 4.2 or above
Download the SwitchBot app
Create a SwitchBot account and sign in
4.Installation
1.Place it on a tabletop.
2.Mount the Base to the back or the bottom of the Motion Sensor. Adjust the sensor angel to
cover the desired space in your home. Place the sensor on a tabletop or stick it to an iron sur-
face.
3.Stick it to a surface using the 3M Sticker.
Installation Tips:
Make sure the sensor is not pointing to appliances or heat source in order to reduce interfer-
ence and to avoid false alarms.
The sensor senses up to 8m away and up to 120°, horizontally.
The sensor senses up to 8m and up to 60°, vertically.
5.Initial Setup
1.Remove the back lid of the sensor. Follow the "+"
and "-" marks, insert two AAA batteries into the
battery box. Put the back lid back.
2. Open the SwitchBot app and sign in.
3. Tap the "+" icon on the top right of the Home page.
4. Choose the Motion Sensor icon to add the device to your account.
6.Battery Replacement, Firmware, and Factory Reset
Battery Replacement
Remove the back lid of the sensor. Follow the "+" and "-" marks, replace the old batteries with
new ones. Put the back lid back.
Firmware
Make sure you have the up to date firmware by upgrading in time.
Factory Reset
Long press the Reset Button for 15 seconds or until the LED Indicator Light is on.
Note: After the device is reset, all settings will be set to the default values and the activity logs
will be erased.
7.Specification
Model Number：W1101500
Size：54*54*34mm
Weight：60g
Power & Battery Life：AAAx2, typically 3 years
Measure Range：-10℃~60℃，20~85%RH
Maximum Detection Distance: 8m
Maximum Detection Angle: 120° horizontally and 60° vertically
8.Return and Refund Policy
This product has one-year warranty (start from the purchasing day). The situations below do not
fit the Return and Refund Policy.
Intended damage or abuse.
Inappropriate storage (drop down or soaking in water).
User modify or repair.
Using loss.
Force majeure damage (Natural disasters).
9.Contact and Support
Setup and Troubleshooting: support.switch-bot.com
Support Email: [email protected]
Feedback: If you have any concern or problem when using our products, please kindly send feed-
back from the Profile> Feedback page in the SwitchBot app.
10.CE Warning
Manufacturer's Name: Woan Technology (Shenzhen) Co., Ltd.
This product is a fixed location. To comply with RF exposure requirements, a minimum separation
distance of 20cm must be maintained between the user’s body and the device, including the
antenna. Use only the supplied or an approved antenna.
This device in compliance with the essential requirements and other relevant provisions of Direc-
tive 2014/53/EU. All essential radio test suites have been carried out.
1. CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DIS-
POSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
2. The device complies with RF specifications when the device used at 20cm from your body
SwitchBot Motion Sensor User Manual
1.In the Box
Note: The visuals used in this manual are for reference only. Due to the future updates and
improvements of the product, the actual product images may differ.
2.Device Instruction
3.Preparation
A smartphone or tablet with Bluetooth 4.2 or above
Download the SwitchBot app
Create a SwitchBot account and sign in
4.Installation
1.Place it on a tabletop.
2.Mount the Base to the back or the bottom of the Motion Sensor. Adjust the sensor angel to
cover the desired space in your home. Place the sensor on a tabletop or stick it to an iron sur-
face.
3.Stick it to a surface using the 3M Sticker.
Installation Tips:
Make sure the sensor is not pointing to appliances or heat source in order to reduce interfer-
ence and to avoid false alarms.
The sensor senses up to 8m away and up to 120°, horizontally.
The sensor senses up to 8m and up to 60°, vertically.
5.Initial Setup
1.Remove the back lid of the sensor. Follow the "+"
and "-" marks, insert two AAA batteries into the
battery box. Put the back lid back.
2. Open the SwitchBot app and sign in.
3. Tap the "+" icon on the top right of the Home page.
4. Choose the Motion Sensor icon to add the device to your account.
6.Battery Replacement, Firmware, and Factory Reset
Battery Replacement
Remove the back lid of the sensor. Follow the "+" and "-" marks, replace the old batteries with
new ones. Put the back lid back.
Firmware
Make sure you have the up to date firmware by upgrading in time.
Factory Reset
Long press the Reset Button for 15 seconds or until the LED Indicator Light is on.
Note: After the device is reset, all settings will be set to the default values and the activity logs
will be erased.
7.Specification
Model Number：W1101500
Size：54*54*34mm
Weight：60g
Power & Battery Life：AAAx2, typically 3 years
Measure Range：-10℃~60℃，20~85%RH
Maximum Detection Distance: 8m
Maximum Detection Angle: 120° horizontally and 60° vertically
8.Return and Refund Policy
This product has one-year warranty (start from the purchasing day). The situations below do not
fit the Return and Refund Policy.
Intended damage or abuse.
Inappropriate storage (drop down or soaking in water).
User modify or repair.
Using loss.
Force majeure damage (Natural disasters).
9.Contact and Support
Setup and Troubleshooting: support.switch-bot.com
Support Email: [email protected]
Feedback: If you have any concern or problem when using our products, please kindly send feed-
back from the Profile> Feedback page in the SwitchBot app.
10.CE Warning
Manufacturer's Name: Woan Technology (Shenzhen) Co., Ltd.
This product is a fixed location. To comply with RF exposure requirements, a minimum separation
distance of 20cm must be maintained between the user’s body and the device, including the
antenna. Use only the supplied or an approved antenna.
This device in compliance with the essential requirements and other relevant provisions of Direc-
tive 2014/53/EU. All essential radio test suites have been carried out.
1. CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DIS-
POSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
2. The device complies with RF specifications when the device used at 20cm from your body
11.UKCA Warning
This product complies with the radio interference requirements of the United Kingdom
Declaration of Conformity
Hereby, Woan Technology (Shenzhen) Co., Ltd. declares that the product type SwitchBot Motion Sensor
is in compliance with Radio Equipment Regulations 2017. The full text of the UK declaration of
conformity is available at the following internet address: https://uk.anker.com
The adapter shall be installed near the equipment and shall be easily accessible. Do not use the Device in
the environment at too high or too low temperature, never expose the Device under strong sunshine or too
wet environment. The suitable temperature for the product and accessories is 32°F to 95°F / 0°C to 35°C.
When charging, please place the device in an environment that has a normal room temperature and good
ventilation.
It is recommended to charge the device in an environment with a temperature that ranges from 5℃~25℃.
. The plug considered as disconnect device of adapter.
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE
OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
RF exposure information:
The Maximum Permissible Exposure (MPE) level has been calculated based on a distance of d=20 cm
between the device and the human body. To maintain compliance with RF exposure requirement, use
product that maintain a 20cm distance between the device and human body.
Frequency Range: 2402MHz-2480MHz
Bluetooth Max Output Power:-3.17 dBm(EIRP)
Your product is designed and manufactured with high quality materials and components,
which can be recycled and reused.
This symbol means the product must not be discarded as household waste, and should
be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect
natural resources, human health and the environment. For more information on disposal and recycling of
this product, contact your local municipality, disposal service, or the shop where you bought this product.
Table des matières
Autres manuels Woan Technology Accessoires
