Wisecomm Observation System Manuel utilisateur
For Your Business or Home Use
Model # TW7002
Package Includes
www.wisecomm.com
No Wires
to Install
• 7" LCD Monitor with Built-In Digital
Wireless Receiver and Recorder
• Recording Resolution: VGA (640x480),
QVGA (320x240)
• Ability to Record onto an SD Memory
Card up to 32GB (2GB SD Card
Included)
• Transmits Video and Audio Signals up to
400ft in Line of Sight
• Ability to Zoom In/Out
• Minimizes Frequency Interference with
Cordless Phones, Wireless Routers, and
other Wireless Devices
• Up to 4 Wireless Cameras can be
Displayed on the Sequential or Quad
Mode
• 2-Way Audio to Communicate Between
LCD Monitor and Wireless Cameras
• Digital Wireless Cameras
• 24 Infrared LEDs for Night Vision with a
45ft Infrared Range
• Monitor Automatically Turn on if Motion is
Detected and off During Inactivity
• A/V Output for the Option of Viewing on a
Large Screen
Up to
Extended Range
400ft
Up to
Extended Range
400ft
Built-In CDS Sensor
Automatically Turns the
LEDs On and Off
PIR Motion Sensor
Infrared LED Lights Produce
an Illumination for the Camera,
Invisible to the Human Eye,
Creating 45 feet of Night Vision
with 2 Wireless, Night Vision Color Cameras
7" Digital Wireless LCD Monitor
Observation System
Observation System
LCD Monitor Quadrant Display
Remote
Controller
2GB SD
Card
Included
Records
Night Vision
Quadrant Display
Features
Security with Reliability
1 - 7” Digital Wireless Monitor/Receiver
2 - Digital Wireless IR Camera
3 - UL Approved AC Adapter
1 - Mounting Bracket for Monitor
2 - Mounting Bracket for Cameras
1 - 2GB SD Card
1 - Warranty Registration Card
1 - Manual
Specifications
Display Screen
Receiver Frequency
Receiver Sensitivity
Resolution (W x H)
Video Format
Video Compression
Memory Compatibility
Recording Resolution
Frame Rate
Up to Switching Dwell Time
Power Supply
Power Consumption
Size (W x H x D)
Weight
Operating Temperature
7 inch TFT LCD Monitor
2,400 to 2,483MHz
-81dBm
480 x 234 Pixels (RGB)
AVI
MJPEG
SD Card up to 32GB
VGA/QVGA
30fps at QVGA and 15fps at QVGA
2 to 60 Seconds
12V DC, 1.25A
<10W
180 x 135 x 30mm
450g (Main Body)
0
o
C to 40
o
C Degrees Celsius
Monitor
Imaging Sensor
CMOS Total Resolution
Transmission Power
Automatic Electronic Shutter
IR LED (D x L)
IR View Distance
Environment Rating
Dimension (D x L)
Operating Temperature
Weight
Power Supply
Lens
1/4-inch Color CMOS
640 x 480 Pixels
14dBm
1/60 to 1/15,000 Seconds
Φ70 x 60mm
About 15m
IP64
Φ70 x 60mm
0 to 40 Degrees Celsius
420g (main body)
12V DC, 500mA
f = 4.3mm
Cameras
Remote
Controller
Up to
Extended Range
400ft
Up to
Extended Range
400ft
LCD Monitor Quadrant Display
2GB SD
Card
Included
No Wires
to Install
with 2 Wireless, Night Vision Color Cameras
7" Digital Wireless LCD Monitor
Observation System
Observation System
www.wisecomm.com
