WINYCAM LOG Manuel utilisateur
User Manual
L
OG
WINYCAM Vehicle Drive Recorder
www.winycam-eng.com
1
WINYCAM LOG
1. Safety Precautions
2. Before use
2-1. Product Feature
2-2. Package
2-3. Product Parts
3. How to use
3-1. Front Camera Installation
3-2. Rear Camera Installation
3-3. GPS / TV-OUT Cable Installation
3-4. How to record
3-5. LED Operation
3-6. Voice Guide
3-7. PC Original Viewer Program Installation
3-8. PC Original Viewer – Screen Configuration
3-8. PC Original Viewer – Viewer Configuration
3-10. PC Original Viewer – Configuration
3-11. Configuration Default Setting
3-12. Playback (Standard video player)
3-13. Playback (PC original viewer)
3-14. Playback (TV/Can Navigation)
3-15. Smartphone Wi-Fi -Download
3-16. Smartphone Wi-Fi – How to set iOS
3-17. Smartphone Wi-Fi – How to use
3-18. Smartphone Wi-Fi – Variable Bitrate
3-19. To save video file on your PC
3-20. Firmware Upgrade
3-21. SD Card Format
3-22. REC Time
3-23. Specification
4. FAQ
Warranty
2
4
5
6
7
8
8
9
11
12
13
14
15
17
19
21
25
26
27
28
29
30
31
34
35
36
36
37
38
39
40
Contents
2
WINYCAM LOG
How to use
Caution on Operation and Storage
Do not operate the product during driving. It may cause
accident.
The product must be installed at a point which would not
obstruct the driver’s view.
Do not allow unauthorized disassembly or alteration to the
product. It may cause malfunction, and the consequent product
damage will not be covered under the warranty.
If the product is damaged or power is cut off by a serious
accident, the product may not be able to record such event
Always keep the windshield clean to enable clear recording.
Since the product is purpose to record video data during driving,
video quality may be deteriorated when in/out the tunnel, and
at night or by contrast and backlight.
Contaminated camera lens may deteriorate the video quality.
Keep the lens clean.
Do not place the product under direct sunlight or inside the
closed vehicle as it may cause malfunction.
Do not use chemicals or detergent to clean the product. Clean
gently with soft cloth.
Use of the product at temperature below -20℃ or above 70℃
may cause malfunction or breakdown. (This caution should be
applied when product is unused.)
Do not use the product in places in high temperature/humidity.
Do not exert excessive force to the product (especially to LCD
buttons and to bracket) as it may cause breakdown.
Operate the product for 3-5 minutes to check for correct
recording, before each use.
Extended exposure to sunlight and high temperature in the
summer may cause malfunction.
Do not turn off power, or remove the SD card during firmware
upgrading as it may cause malfunction.
Do not touch the cigar lighter cable with wet hand as it may
cause electric shock.
Do not use a damaged cigar lighter cable as it may cause electric
shock or fire.
Do not place the cigar lighter cable in near heating devices.
Do not leave the product connected to the cigar lighter if not
in use for a long period of time. Remove the cable from the
product.
Insert the cigar lighter securely.
Do not bend or pull the cigar lighter cable by excessive force, or
place heavy objects on the cable.
(It may damage the cord and as a result it may cause electric
shock or fire.)
The recorded file could be deleted to make an available space
for recording even if the overwriting setting is Off.
1. Safety Precautions
Safety Precautions
3
WINYCAM LOG
How to use
Caution on SD Card
In order to confirm normal operation of the product, please
check the image of a SD card and format it on a regular
basis. (PC format needed one to two times per month)
Because an SD card is consumables, if it is used for a long
time, you may lose the data or may not record due to an
error, so please check it periodically.
When the product is in recording or the power is on, do
not eject the SD card forcibly. It may cause a failure of the
SD card and data loss.
If temperature gets too high in the vehicle, data storing
may be disabled, or data may be damaged. Park your
vehicle in the shade in the summer.
When identify the car's accident or damage, please keep
the SD card separately. Due to overwrite, important data
may be deleted.
When turn off the power of the body and remove the SD
card before LED is turned off, the last recording file may not
be saved, so please be careful.
When turn off the power of the body and remove the SD
card before LED is turned off, the last recording file may not
be saved, so please be careful.
When driving a car, do not remove the SD card. Make sure
to remove it safely when a car is in parking or stop.
After turning on the power, make sure that it is in normal
operation.
Please note that the warranty period of an SD card is
six (6) months, and replace it at the time of more than
six (6) months. Please purchase and use SD Card that
manufacture recommended specification.
The SD card randomly purchased other than the one we
provide, shall be excluded from the warranty, and we shall
not take any responsibility for loss and damage of the data
recorded in the SD card in any case.
Safety Precautions
4
WINYCAM LOG
How to use
Thank you for purchasing LOG
This Manual contains important information
about the proper use and cautions in use of
the product. Please read carefully before use.
LOG is an auxiliary product to alert users
for safe driving and prevent accidents, by
recording video during driving. Also purpose
for evidence of an accident.
LOG does not however guarantee that all
accidents are recorded. Minor shock may not
detect sensor to record.
WinyTechnology shall not be liable for any loss
or damage to data or to the product which
may be caused by accident or impact.
All rights vested in the design and software
of LOG are the property of Winy Technology
Co., Ltd. and protected by the Copyright Law.
LOG may change without notice for further
function improvement.
This User Manual is published based on the
current state of the product, and may contain
typographical errors or omissions.
Contents of this User Manual may be
modified, changed or supplemented without
notice for further improvement.
2. Before Use
Before Use
5
WINYCAM LOG
How to use
High Quality Lens and High Image Quality
Resolution support
Front 5Mega Pixel / Rear 0.4 Mega Pixel image sensor
Wide mega lens
Front FHD(1920*1080) High Image Quality Resolution
Rear D1(720*480) High Image Quality Resolution
(Front 20 + Rear 30)
Various Recording Function and Video
Data Acknowledgement
Various REC - Normal, Manual, Event, Motion and auto change
to Parking recording mode
Recording video quality setting is available for changing.
(Super High Video Quality / High Video Quality / Normal Video
Quality)
Driving records can be stored with GPS data. (optional)
G sensor built-in - Event recording mode.
External video output.
(real-time video image can be checked in another monitor)
Flash memory back-up space – Available to boot back-up space
when the problem occur during upgrading the firmware.
PC viewer program are provided to change various setting
values and map data can be checked when using GPS. (In the
general video player (e.g. Windows media player), recorded
video can be played)
Each capacity of a normal / event/ motion folder can be set in
PC Viewer.
High Quality Voice Record and Voice
Guidance
Operating instructions service by voice guidance
Voice recording On/Off function and speaker output On/Off
function.
High performance microphone built-in
Back-up battery and Car constant power
discharge protection function
Stored recorded image safety by built-in high-capacity
capacitor when power is off.
Consume less than 2.5mA when power shutdown
(Based on 12V)
“
When using car constant power discharge protection
functions, If user car voltage is 12V and the voltage of less than
11.8V is maintained for more than 30 seconds the product
power will be shuts-off ”
(Note: Shutdown time depend on the Type of Car and car
condition.)
Other
Soft look and emotional design. (easy removable body)
Security LED light are mounted on front body (LED Lighting
function On/Off can be set in PC viewer)
2-1. Product Feature
Before Use
6
WINYCAM LOG
How to use
Standard Package
Option
Accessories
LOG Body Cigar Lighter
Null Cable External GPS Video Splitter Cable
(Y-Type)
3M tape for bracket USB Card Reader
Bracket
The viewer program is included in the micro SD card.
※Note : Please save the viewer program on your PC before using the micro SD card.
(If the viewer program is deleted in SD card, you can download from our web site.)
The packaged product picture of the user manual may differ from the actual product.
The video cable is optional and it is available to use after checking the PLUG Pin of Navigation AV IN.
Video input type is different and check the user manual of monitor.
Micro SD card SD Card Adaptor WiFi Dongle
Rear(D1)Camera Rear Camera Video Cable
2-2. Package
Before Use
7
WINYCAM LOG
How to use
Power LED
REC LED
Bracket
Mute Urgent REC
SpeakerFront Camera
2-3. Product Parts
Before Use
Security LED SD Card Slot
Rear Camera Jack
(TV-OUT)
Power
DC Jack
Wi-Fi USB Jack
GPS Jack
8
WINYCAM LOG
How to use
1. Insert Micro SD card to LOG SD card
slot. (Check the SD card direction)
6. Arrange a power cable.
2. Remove the protect sticker.
4. Attach the Winner in place on the
top of front windshield or middle o left
and right of the mirror.
3. Connect Cigar lighter cable to Power
connection of product.
5. Connect a Cigar lighter to a Cigar
socket.
3-1. Front Camera Installation
9
WINYCAM LOG
How to use
Please power off a car and LOG before
installation.
(Disconnect the power connection)
1. Shutdown a car battery and power
4. Connect video cable
2. Install a rear camera
5. Check an operation
3. Adjust a rear camera angle
6. Arrange a front/rear camera cable
After checking recording operation, well-
arrange a cable.
If you embed cable to car wall, please check
cable connection. Also after embedded
double-check if LOG can record properly.
Remove a protect sticker and attach a rear
camera in proper location in windshield.
Connect the ( ㅡ ) shape’s rear camera
cable to a rear camera connection slot and
the ( ㄱ ) shape’s one to a main body.
Adjust a camera angle and fix it. To adjust
the angle, the horizon is seen above the
right center of the screen.
Power on LOG and check to playback a REC
video correctly.
(The video splitter cable has to be connected
when check it with TV-OUT.)
3-2. Rear Camera Installation
