Winmate M133 Series Manuel utilisateur

Please read these instructions carefully before using this product, and save this manual for future use.

Rugged Tablet PC

M133 Series

Windows 10 IoT Enterprise

Windows Embedded 8.1 Industry Pro

Windows 7 Professional for Embedded System

OS Deployment Guide

Version 1.1

Release date: 17-Apr-2017

- 1 -

Document Revision History

Version

Date

Note

1.0

09-Mar-2017

Initial document release

1.1

17-Apr-2017

Add Graphics Settings

- 2 -

CONTENTS

CHAPTER 1: INTRODUCTION 3

CHAPTER 2: BIOS 4

2.1 BIOS and OS Support Overview 4

2.2 Changing BIOS Mode for OS Installation 4

2.3 BIOS Navigation Keys 5

2.4 Changing BIOS Settings to Install OS 7

2.5 BIOS and EC Firmware Update Guide 11

CHAPTER 3: SETTING UP OS FIRST TIME 24

3.1 Windows 10 IoT Enterprise 24

3.2 Windows Embedded 8.1 Industry Pro 30

3.3 Windows 7 Ultimate / Professional for Embedded System 35

CHAPTER 4: DRIVER INSTALLATION 40

4.1 Windows 10 IoT Enterprise 40

4.2 Windows Embedded 8.1 Industry Pro 41

4.3 Windows 7 Professional for Embedded System 42

4.4 WMMIO Driver Installation (For Windows 7/8/10) 52

CHAPTER 5: UTILITY INSTALLATION 54

5.1 List of Winmate AP and Utilities 54

5.2 Installation Procedure 55

CHAPTER 6: SERIAL COM PORT SETTINGS 56

6.1 COM Port Settings 56

6.2 Adjusting COM Port Number 57

6.3 Setting Up Bluetooth COM Port 59

6.4 How to Check COM Port Proprieties 61

CHAPTER 7: OS SETTING ADJUSTMENTS 63

7.1 Microphone Setting Adjustment 63

7.2 Display Size Adjustment 66

7.3 On-screen Keyboard Adjustment (For Windows 10 Only) 69

7.4 Graphics Setting 74

CHAPTER 8: WINMATE SDK SUPPORT 78

8.1 Winmate Download Center 78

8.2 Download SDK from Winmate File Share 78

- 3 -

CHAPTER 1: INTRODUCTION

This document contains references and instructions on operation system and utility

installation. This guide describes the procedure how to update BIOS or change

BIOS settings to install the OS different from Winmate shipment.

For standard installation Windows OS installation, you can use Winmate’s

Recovery CD/ DVD or use Recovery Wizard following procedures described in

the M133 Series User Manual.

For alternative way, if customer installs Windows from Microsoft CD/ DVD; this

document explains some key important information (especially for consumer

versions of Windows, Non-Embedded OS).

- 4 -

CHAPTER 2: BIOS

2.1 BIOS and OS Support Overview

Newer operating systems such as Windows 8 and Windows 10 are supported when

the BIOS is in UEFI mode, while Windows 7 is only supported when the BIOS is in

Legacy Mode. Please make sure the BIOS is in the corresponding mode before

proceeding to OS installation:

BIOS Mode

Supported Operating System

UEFI

Windows 8, Windows 10

Legacy

Windows 7

2.2 Changing BIOS Mode for OS Installation

There are two ways to change the BIOS mode on the tablet for new OS installation

1. Through change of BIOS settings (UEFI / LEGACY mode) using the BIOS

2. Update the BIOS to the corresponding preset versions dedicated to different

Windows versions.

IMPORTANT:

Choose only one BIOS Setup method for OS Installation: either

change BIOS settings (UEFI/LEGACY mode) or update the BIOS to

the corresponding preset versions dedicated to different Windows

versions.

The choice depends on your preferences.

- 5 -

2.3 BIOS Navigation Keys

This section describes the procedure to enter BIOS settings and introduces BIOS

navigation keys. To enter the BIOS setup, you need to connect an external USB

keyboard, press Del key when the prompt appears on the screen during start up.

The prompt screen shows only few seconds so need press Del key quickly.

BIOS Navigation Keys

The following keys are enabled during POST:

Key

Function

Del

Enters the BIOS setup menu.

Display the boot menu. Lists all bootable devices that are connected

to the system. With cursor ↑and cursor ↓and by pressing <ENTER>,

select the device used for the boot.

Pause

Pressing the [Pause] key stops the POST. Press any other key to

resume the POST.

- 6 -

The following Keys can be used after entering the BIOS Setup.

Key

Function

General Help

Previous Values

Optimized Defaults

Save & Exit

Esc

Exit

+/-

Change options

Enter

Select or execute command

Cursor ↑

Moves to the previous item

Cursor ↓

Goes to the next item

Cursor ←

Moves to the previous item

Cursor →

Goes to the next item

- 7 -

2.4 Changing BIOS Settings to Install OS

This section describes how to change operating system mode in BIOS settings to

install OS that is different from the version that is shipped.

2.4.1 Default Windows 8/8.1 change to Windows 7

The instruction below describes how to change Windows 8/8.1 to Windows 7.

1. Enter BIOS Setup utility.

2. Go to “Boot” at BIOS setup menu. Click on Select Operating System.

- 8 -

3. Change OS setting to Windows 7.

- 9 -

2.4.2 Default Windows 7 change to Windows 8.1

1. Enter BIOS Setup menu.

2. Go into item “Boot” at BIOS setup menu.

3. Change OS setting to Windows 8.X.
