Winmate R10L100-SPT2 Manuel utilisateur

Please read these instructions carefully before using this product, and save this manual for future use

Full IP65

Flat Stainless P-CAP

Display

Quick Start Guide

V1.0

For more information on this and other

Winmate products, please visit our

website at: www.winmate.com

Model No.:

R10L100-SPT2

R15L100-SPC3

R17L100-SPA1

R19L100-SPM1

W22L100-SPA3

Document Part Number: 91521110100N

FCC Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received

including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

class "B" digital device, pursuant to part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at him own expense.

European Union

Electromagnetic Compatibility Directive (2014/30/EU)

EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

EN55032: 2012/AC:2013

EN61000-3-2:2014

EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

This equipment is in conformity with the requirement of the following EU

legislations and harmonized standards. Product also complies with the

Council directions.

No part of this document may be reproduced, copied, translated, or transmitted in

any form or by any means, electronic or mechanical, for any purpose, without the

prior written permission of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their

respective owners.

Disclaimer

Winmate Inc. reserve the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order

to improve design and/or performance. We assume no responsibility or liability

for the use of the described product(s) conveys no license or title under any

patent, copyright, or masks work rights to these products, and make no

representations or warranties that these products are free from patent, copyright,

or mask work right infringement, unless otherwise specified. Applications that are

described in this manual are for illustration purposes only. We make no

representation or guarantee that such application will be suitable for the specified

use without further testing or modification.

Warranty

Winmate Inc. warranty guarantees that each of its products will be free from

material and workmanship defects for a period of one year from the invoice date.

If the customer discovers a defect, we will, at his/her option, repair or replace the

defective product at no charge to the customer, provide it is returned during the

warranty period of one year, with transportation charges prepaid. The returned

product must be properly packaged in its original packaging to obtain warranty

service. If the serial number and the product shipping data differ by over 30 days,

the in-warranty service will be made according to the shipping date. In the serial

numbers the third and fourth two digits give the year of manufacture, and the fifth

digit means the month (e. g., with A for October, B for November and C for

December).

For example, the serial number 1W17Axxxxxxxx means October of year 2017.

iii

Customer Service

We provide a service guide for any problem by the following steps: First, visit the

website of our distributor to find the update information about the product.

Second, contact with your distributor, sales representative, or our customer

service center for technical support if you need additional assistance.

You may need the following information ready before you call:

Product serial number

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers every business

day. We are always ready to give advice on application requirements or specific

information on the installation and operation of any of our products.

Safety Information

WARNING! / AVERTISSEMENT!

Always completely disconnect the power cord from your chassis

whenever you work with the hardware. Do not make connections

while the power is on. Sensitive electronic components can be

damaged by sudden power surges. Only experienced electronics

personnel should open the PC chassis.

Toujours débrancher le cordon d’alimentation du chassis lorsque

vous travaillez sur celui-ci. Ne pas brancher de connections lorsque

l’alimentation est présente. Des composantes électroniques

sensibles peuvent être endommagées par des sauts d’alimentation.

Seulement du personnel expérimenté devrait ouvrir ces chassis.

CAUTION/ATTENTION

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution, use a

grounding wrist strap at all times. Place all electronic components

in a static-dissipative surface or static-shielded bag when they are

not in the chassis.

Toujours verifier votre mise à la terre afin d’éliminer toute charge

statique avant de toucher la carte CPU. Les équipements

électroniques moderns sont très sensibles aux décharges

d’électricité statique. Toujours utiliser un bracelet de mise à la

terre comme précaution. Placer toutes les composantes

électroniques sur une surface conçue pour dissiper les charge, ou

dans un sac anti-statique lorsqu’elles ne sont pas dans le chassis.

Contents

INTRODUCTION 1

Features 1

Package Contents 2

Product Overview 3

Dimensions 10.4" 3

Dimensions 15" 3

Dimensions 17” 3

Dimensions 19” 4

Dimensions 21.5” 5

Physical Buttons and LED Indicators 6

Connectors 8

GETTING STARTED 9

Turning On Your Device 9

Turning Off Your Device 10

INSTALLATION 11

Wiring Requirements 11

Connector Pin Assignments 12

Power Cable 12

USB Cable (For Touch) 13

VGA Cable 14

DVI Cable (Optional) 15

Mounting 16

VESA Mounting 16

Yoke Mounting 17

SPECIFICATIONS 18

APPENDIX A: CLEANING THE MONITOR 20

APPENDIX B: AVAILABLE INPUT SIGNALS 21

INTRODUCTION

Congratulations on purchasing Winmate® IP65 Flat Stainless P-CAP Series

Display. Winmate® IP65 Flat Stainless P-CAP Series Display is rugged,

industrial-grade display series built to withstand challenging environments,

undergoing rigorous testing to ensure safety and top performance. All of the

models in the series are sealed to IP65 standard. Stainless housing features anti-

corrosion properties making it suitable for food, chemical and pharmaceutical

industries. Projected Capacitive Multi-Touch (P-CAP) screen supports glove

mode and provides even more convenience for the operator.

Winmate® IP65 Flat Stainless P-CAP Display goes beyond that of the standard

industrial panel computers with elegant, edge-to-edge design, rugged

construction, powerful performance, and flexible mounting options.

Features

Winmate® IP65 Flat Stainless Display features:

SUS304 Brushed Stainless Steel housing

Sealed to IP65 for protection against water and dust (it's suggested to use

LAN/USB/COM only)

A true flat, easy-to-clean front surface with edge-to-edge design

Flat multi-touch display with superior readability and P-CAP technology

Various mounting solutions, Yoke mounting and VESA mounting

Waterproof ports with adapter cables for external connectivity

Rain/ Glove Mode

Widely used in chemical industry, food industry, medical devices,

appliances etc. with good corrosion resistance

Package Contents

Carefully remove the box and unpack your device. Please check if all the items

listed below are inside your package. If any of these items are missing or damaged

Standard factory shipment list may include the following items:

Display

Quick Start Guide

(Hardcopy)

R-series AD Board

Manual (Hardcopy)

Varies by product

specifications

91521110100N

91521112100C

AC Adapter

Power Cable*

VGA Cable

50W: 90PO12050002

80W: 90PO12080003

Varies by country

944115010000

USB Cable

(For Touch)

DVI Cable

(Optional)

VESA Screws

948704010000

9455255250Q1

913511101101

Product Overview

This section contains mechanical drawing of the Display. Notice that this is a

simplified drawing and some components are not marked in detail.

Dimensions 10.4" Unit: mm

Dimensions 15" Unit: mm

Dimensions 17”

Unit: mm

Dimensions 19”

Unit: mm

Dimensions 21.5”

Unit: mm
