Wilson Electronics 301121 Manuel utilisateur

Dual-Band Dome Antenna

Part# 301121

This package contains: Dual-Band DomeAntenna, antenna installation kit,

and a template with instructions for installing on the ceiling. See reverse

side for installation template.

TECHNICAL SUPPORT

Call Toll-Free 866-294-1660

E-mail [email protected]

Visit www.wilsonelectronics.com

Part Number 301121

Frequency Range 800~910 MHz / 1800~1990 MHz

Gain 2.5 dBi

Polarization Vertical

Max Power 50 watts

Impedance 50 ohms

Connector N-Female

Diameter 8 (inch) / 20.32 (cm)

Speciﬁcations

3301 East Deseret Drive, St. George, Utah 84790

For additional technical support visit

www.wilsonelectronics.com

Phone: 866-294-1660

Wilson

Electronics, Inc.

Part # 104031 - 09.04.07

screw

location

screw

location

Part # 301121

Dual-Band DomeAntenna

Installation Instructions and Template

Select a location on the ceiling that you can access from above to run the

antenna cable. Verify that your chosen location allows for the necessary

separation between the dome antenna and the outside antenna (see

ampliﬁer installation instructions for antenna separation requirements).

Tape this template in the selected antenna location. NOTE: ensure that the

cable connector location (marked by ) is NOT below a ceiling stud. Drill

a 5/8-inch hole in the template at the spot marked . Feed the cable from

above through the hole.

Included are two sets of mounting hardware: A) 3 bolts with nuts and

washers, B) 3 self-starting screws, and 3 mounting plugs.

A) If using the bolts, drill a 1/8” hole through each of the small

circles marked “screw location.” Remove template from the

ceiling, attach the dome antenna to the amplifier cable, insert the

bolts through the drilled holes, and tighten against the ceiling with

the enclosed nuts and washers. Snap the plugs into place on the

mounting holes.

B) If using the self-starting screws, mark the screw locations, remove the

template, and attach the amplifier cable to the dome antenna. Place the

antenna flush against the ceiling and screw in the self-starting screws

until snug. Be careful not to over-tighten. Snap the plugs into place

on the mounting holes.

If you have any questions about the installation procedure,

please contact our Technical Support Department toll free at

866-294-1660 or email [email protected].

screw

location

The Dual-Band DomeAntenna is designed for horizontal

installation on a ceiling. It is not designed for a vertical or

slanted surface, such as a wall.

Ceiling Installation

AC/DC

Power Supply

Dome Antenna

Ampliﬁer

Outside Antenna
