Wildview Xtreme 3 Manuel utilisateur
STC-TGL3M
User’s Manual
Toll Free Customer Support 1-888-304-6125
www.wildviewcam.com
Version 1.1 08/06
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
2
For Customer Service or Warranty Information Call
Toll Free
888-304-6125
WILDVIEW
P.O. Box 535189
Grand Prairie, Texas 75053-5189
www.wildviewcam.com
Wildview Scouting Camera Limited Warranty
Your Wildview Scouting Camera is covered by a One Year
Limited Warranty on parts & labor from the date of purchase.
The warranty covers defects in workmanship & materials.
The warranty does not apply to units, which have been
damaged or abused intentionally or unintentionally.
Tampering with or altering the unit will void the warranty. Any
unauthorized service will void warranty. Original sales receipt
must be produced for any warranty service.
Questions call 888-304-6125.
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
3
Manual Contents
Camera overview 4
Camera kit contents 7
Battery and memory Installation 8
Definition 11
Programming 13
Mounting the camera 16
Viewing images 20
Saving and Deleting images 23
Memory compatibility chart 26
Technical Specs 27
General Information 30
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
4
Camera overview
Front view Side view
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
5
Open view image with major parts indication
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
6
Image Capacity Chart
SD card High Low AVI
Built In 32MB
SDRAM
12 33 10
16MB 10 26 8
32MB 20 52 16
64MB 40 104 32
128MB 80 208 64
256MB 160 416 128
512MB 320 832 256
1GB* 640 1664 512
2GB* 1280 3328 1024
* Subject to card compatibility under different brand
NOTE: Picture / Image Capacity Chart provides approximate
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
7
number of images or AVI movies based on resolution setting
and the size of memory card. These figures may vary
depending on the amount of detail in the image.
Camera kit contents
• Model STC-TGL3M Digital Scouting Camera
• Camera driver
• User Manual
• USB cable
• Strap
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
8
Battery & memory installation
The Wildview STC-TGL3M Digital Scouting Camera is
designed to operate using alkaline batteries for optimum
performance.
NOTE: Always have camera in OFF position when
installing or removing batteries.
Batteries “C” cell
The internal battery compartment accepts 4 “C” cell
batteries. Be sure to use high quality brand name
alkaline batteries. Install batteries in correct polarity (+/-)
as noted inside battery compartment.
Warning: Do not use different Voltage lead
acid battery other than the one specified in
this section. Doing so will damage the camera
and will void the warranty.
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
9
12V Lead Acid external battery
The STC-TGL3M is equipped with an external power jack
designed to accept a barrel plug cable to attach to a
sealed lead acid battery. (sold separately). Battery cable
and complete 12V Lead Acid battery kits are available
wherever Wildview scouting cameras are sold or call toll
free 888-304-6125. Only Wildview external battery
accessories are recommended.
• Insert the battery pack plug into the DC 12V jack at
the bottom of camera housing
• Turn on the camera by sliding the power switch to
PIR position
Please make sure the voltage and polarity (+/-) are
correct before connection. Incorrect voltage or
polarity (+/-) will damage the camera.
STC-TGL3M
www.wildviewcam.com Toll Free 888-304-6125
10
Memory Options
Your Wildview scouting camera is equipped with 32MB
built in SDRAM memory. The camera is also equipped
with an expandable media card slot capable accepting up
to 2GB* SD card (sold separately). With no memory card
inserted into the slot, the camera will use the built in
32MB SDRAM memory. If a SD card is inserted into the
slot then the camera will bypass the built in memory and
utilize the SD memory. The front counter display will
show the number of images on the built in memory
unless the expansion card is inserted at which point the
counter will only show the number of images in the
expansion card.
Inserting SD card
Make sure camera is in the OFF position whenever
adding or removing memory.
• Insert SD memory card in to the SD card slot
completely and in the correct direction as shown on
the inside of the housing.
