WIKA HP-2 Manuel utilisateur

Operating instructions

Betriebsanleitung

Mode d'emploi

Manual de instrucciones

Drucksensor, Typ HP-2

Pressure sensor for highest pressure, model HP-2

Pressure sensor, model HP-2

Capteur de pression, type HP-2

Sensor de presión, modelo HP-2

11379180.04 05/2018 EN/DE/FR/ES

WIKA operating instructions pressure sensor, model HP-2

WIKA®is a registered trademark in various countries.

WIKA®ist eine geschützte Marke in verschiedenen Ländern.

Prior to starting any work, read the operating instructions!

Keep for later use!

Vor Beginn aller Arbeiten Betriebsanleitung lesen!

Zum späteren Gebrauch aufbewahren!

Lire le mode d'emploi avant de commencer toute opération !

A conserver pour une utilisation ultérieure !

¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!

¡Guardar el manual para una eventual consulta!

Operating instructions model HP-2 Page 3 - 22

Betriebsanleitung Typ HP-2 Seite 23 - 42

Mode d'emploi type HP-2 Page 43 - 62

Manual de instrucciones modelo HP-2 Página 63 - 82

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

Contents

1. General information 4

2. Safety 5

3. Specications 8

4. Design and function 10

5. Transport, packaging and storage 10

6. Commissioning, operation 11

7. Adjustment of zero point and span 14

8. Spare part kit 15

9. Maintenance and cleaning 18

10. Faults 19

11. Dismounting, return and disposal 20

12. Accessories 21

Declarations of conformity can be found online at www.wika.com.

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

1. General information

■

The pressure sensor described in the operating instructions has been designed and

manufactured using state-of-the-art technology. All components are subject to strin-

gent quality and environmental criteria during production. Our management systems

are certied to ISO 9001 and ISO 14001.

■

These operating instructions contain important information on handling the instru-

ment. Working safely requires that all safety instructions and work instructions are

observed.

■

Observe the relevant local accident prevention regulations and general safety regula-

tions for the instrument's range of use.

■

The operating instructions are part of the product and must be kept in the immediate

vicinity of the instrument and readily accessible to skilled personnel at any time.

■

Skilled personnel must have carefully read and understood the operating instructions

prior to beginning any work.

■

The manufacturer's liability is void in the case of any damage caused by using the

product contrary to its intended use, non-compliance with these operating instruc-

tions, assignment of insuciently qualied skilled personnel or unauthorised modi-

cations to the instrument.

■

The general terms and conditions contained in the sales documentation shall apply.

■

Subject to technical modications.

■

Further information:

- Internet address: www.wika.de / www.wika.com

- Relevant data sheet: PE 81.53

- Application consultant: Tel.: +49 9372 132-8976

Fax: +49 9372 132-8008976

[email protected]

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

1. General information / 2. Safety

Explanation of symbols

WARNING!

... indicates a potentially dangerous situation that can result in serious injury

or death, if not avoided.

CAUTION!

... indicates a potentially dangerous situation that can result in light injuries

or damage to equipment or the environment, if not avoided.

Information

... points out useful tips, recommendations and information for ecient and

trouble-free operation.

WARNING!

... indicates a potentially dangerous situation that can result in burns, caused

by hot surfaces or liquids, if not avoided.

Abbreviations

2-wire The two connection lines are used for the voltage supply.

The measurement signal also provides the supply current.

3-wire Two connection lines are used for the voltage supply.

One connection line is used for the measurement signal.

UB, +5V Positive power supply

0V, GND Reference potential

S+ Positive output terminal

D+ ,D- Data link USB 2.0

2. Safety

WARNING!

Before installation, commissioning and operation, ensure that the appropri-

ate pressure sensor has been selected in terms of measuring range, design

and specic measuring conditions.

The operator must ensure the compatibility of the uid with the material

used. Where the medium is hydrogen, contact the manufacturer.

The uid must not be contaminated with abrasive substances.

Non-observance can result in serious injury and/or damage to the equipment.

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

2. Safety

WARNING!

■

Open the connections only after the system has been depressurised.

■

Observe the working conditions in accordance with chapter 3 “Specica-

tions”.

■

Always operate the pressure sensor within the overpressure limit.

Further important safety instructions can be found in the individual chapters

of these operating instructions.

2.1 Intended use

The pressure sensor is used to convert pressure into an electrical signal.

The instrument has been designed and built solely for the intended use described here,

and may only be used accordingly.

The technical specications contained in these operating instructions must be

observed. Improper handling or operation of the instrument outside of its techni-

cal specications requires the instrument to be taken out of service immediately and

inspected by an authorised WIKA service engineer.

The manufacturer shall not be liable for claims of any type based on operation contrary

to the intended use.

2.2 Personnelqualication

WARNING!

Riskofinjuryshouldqualicationbeinsucient!

Improper handling can result in considerable injury and damage to equipment.

The activities described in these operating instructions may only be carried

out by skilled personnel who have the qualications described below.

Skilled personnel

Skilled personnel are understood to be personnel who, based on their technical training,

knowledge of measurement and control technology and on their experience and knowl-

edge of country-specic regulations, current standards and directives, are capable of

carrying out the work described and independently recognising potential hazards.

Special operating conditions require further appropriate knowledge, e.g. of aggressive

media.

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

2. Safety

2.3 Special hazards

WARNING!

For hazardous media such as oxygen, acetylene, ammable or toxic gases

or liquids, and refrigeration plants, compressors, etc., in addition to all stand-

ard regulations, the appropriate existing codes or regulations must also be

followed.

WARNING!

No plant conditions are permitted that could lead to the formation of atomic

hydrogen in the connection channel of the pressure sensor.

WARNING!

Residual media in the dismounted pressure sensor can result in a risk to

persons, the environment and equipment.

Take sucient precautionary measures.

Do not use this instrument in safety or emergency stop devices. Incorrect use

of the instrument can result in injury.

Should a failure occur, aggressive media with extremely high temperature and

under high pressure or vacuum may be present at the instrument.

2.4 Labelling, safety marking

Product label

If the serial number becomes illegible due to mechanical damage or overpainting, trace-

ability will no longer be possible.

P# Product no.

S# Serial no. Measuring range

Power supply

Output signal

Pin assignment

Accuracy

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

2.Safety/3.Specications

Explanation of symbols

CE, Communauté Européenne

Instruments bearing this mark comply with the relevant European directives.

3. Specications

WARNING!

When designing the system, please note that the values given (e.g. burst

pressure, overpressure limit) are dependent upon the material and thread

used.

Measuring ranges

Relative pressure

bar Measuring range 0 ... 1,600 0 ... 2,500 0 ... 4,000 0 ... 5,000

Overpressure limit 2,300 3,500 5,000 6,000

Burst pressure 4,000 6,000 8,000 10,000

Measuring range 0 ... 6,000 0 ... 7,000 0 ... 8,000 0 ... 10,000

Overpressure limit 7,000 8,000 10,000 11,000

Burst pressure 11,000 11,000 12,000 12,000

Measuring range 0 ... 12,000 0 ... 15,000

Overpressure limit 12,500 15,500

Burst pressure 14,000 16,000

psi Measuring range 0 ... 23,000 0 ... 36,000 0 ... 58,000 0 ... 72,000

Overpressure limit 33,300 50,500 72,500 87,000

Burst pressure 58,000 87,000 116,000 145,000

Measuring range 0 ... 87,000 0 ... 100,000 0 ... 115,000 0 ... 145,000

Overpressure limit 101,500 116,000 145,000 159,000

Burst pressure 159,500 159,500 174,000 174,000

Service life

On request, since the service life depends on the actual pressure prole.

Despite its excellent load cycle stability a permanent load cycle stability is only given

conditionally.This is due to the extreme loadings faced by the highly pressurised

materials.This applies particularly to dynamic applications. Accordingly, the pressure-

loaded parts of the HP-2 are considered as wear parts that are not covered by the

warranty.

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

3.Specications

Output signals

Signal type Signal

Current (2-wire) 4 ... 20 mA

Voltage (3-wire) DC 0 ... 5 V

DC 0 ... 10 V

USB USB 2.0

Power supply

The power supply depends on the selected output signal

■

4 ... 20 mA: DC 10 ... 30 V

■

DC 0 ... 5 V: DC 10 ... 30 V

■

DC 0 ... 10 V: DC 14 ... 30 V

■

USB 2.0: DC 5 V

LoadinΩ

■

Current output (2-wire): ≤ (power supply - 10 V) / 0.02 A

■

Voltage output (3-wire): > maximum output signal / 1 mA

Ingress protection (per IEC 60529)

■

Angular connector DIN 175301-803 A: IP 65

■

Circular connector M12 x 1 (4-pin): IP 67

■

USB connector type A: Instrument: IP 67, connector: IP 20

■

Cable outlet: IP 67

The stated ingress protection only applies when plugged in using mating connectors

that have the appropriate ingress protection.

Permissible temperature ranges

■

Medium: 0 ... +80 °C

■

Ambient: -20 ... +80 °C

■

Storage: -40 ... +85 °C

CE conformity

■

EMC directive, emission (group 1, class B) and immunity (industrial application)

With USB signal output and strong electromagnetic disturbances in the frequency

range 650 … 750 MHz, the accuracy can be inuenced by up to 1 %.

■

Pressure equipment directive

■

RoHS directive

For special model numbers, e.g. HP-20000, please note the specications stated on the

delivery note.

For further specications see WIKA data sheet PE 81.53 and the order documentation.

WIKA operating instructions pressure sensor, model HP-2

11379180.04 05/2018 EN/DE/FR/ES

4. Design and function / 5. Transport, packaging and ...

4. Design and function

4.1 Short description

The prevailing pressure is measured at the sensor element through the deformation of a

diaphragm. By supplying power, this deformation of the diaphragm is converted into an

electrical signal. The output signal from the pressure sensor is amplied and standard-

ised.

4.2 Scope of delivery

Cross-check scope of delivery with delivery note.

5. Transport, packaging and storage

5.1 Transport

Check the pressure sensor for any damage that may have been caused during transpor-

tation.

Obvious damage must be reported immediately.

5.2 Packaging

Do not remove packaging until just before mounting.

Keep the packaging as it will provide optimum protection during transport (e.g. change

in installation site, sending for repair).

5.3 Storage

Permissible conditions at the place of storage:

see chapter 3 “Specications”

Store the pressure sensor in its original packaging in a location that fulls the conditions

listed above.

WARNING!

Before storing the instrument (following operation), remove any residual

media.This is of particular importance if the medium is hazardous to health,

e.g. caustic, toxic, carcinogenic, radioactive, etc.

Table des matières

Langues :

Autres manuels WIKA Accessoires

WIKA

WIKA O-10 (T) Manuel utilisateur

WIKA

WIKA MHC-1 Manuel utilisateur

WIKA

WIKA MG-1 Manuel utilisateur

WIKA

WIKA PEW-1000 Manuel utilisateur

WIKA

WIKA RLT-1000 Manuel utilisateur

WIKA

WIKA A2G-80 Manuel utilisateur

WIKA

WIKA CPT7000-IS Manuel utilisateur

WIKA

WIKA FLR Series Manuel utilisateur

WIKA

WIKA MH-3 Manuel utilisateur

WIKA

WIKA LF-1 Manuel utilisateur

WIKA

WIKA PG43SA-D Manuel utilisateur

WIKA

WIKA MH-4-CAN Manuel de l'opérateur

WIKA

WIKA CPT7000 Manuel utilisateur

WIKA

WIKA D-20-9 Manuel utilisateur

WIKA

WIKA TR31-3 Manuel utilisateur

WIKA

WIKA air2guide A2G-85 Manuel utilisateur

WIKA

WIKA SENSeOR AMS01 Manuel utilisateur

WIKA

WIKA MH-4 Manuel utilisateur

WIKA

WIKA air2guide A2G-70 Manuel utilisateur

WIKA

WIKA MH-4-CAN Manuel utilisateur

WIKA

WIKA MH-4 Manuel utilisateur

WIKA

WIKA TC46 Manuel utilisateur

WIKA

WIKA MH-3 Manuel utilisateur

WIKA

WIKA GD-20 Series Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
