Wi Digital Systems AudioStream Pro AV Manuel utilisateur
OWNER’S MANUAL
OPERATING INSTRUCTIONS
PACKING LIST 5
SYSTEM CHARGING & PAIRING 6
TRANSMITER MICROPHONE SETUP
• MONO LAVALIER SETUP 8
• TRANSMITTER PLACEMENT 11
• OPTIONAL STEREO LAVALIER SETUP 12
• OPTIONAL EARSET SETUP 14
• OPTIONAL SHOTGUN SETUP 18
RECEIVER SETUP
• CAMERA CONNECTION 20
• SMARTPHONE CONNECTION 22
• TABLET & SMART DEVICE CONNECTION 26
• SOUND SYSTEM CONNECTION 28
AUDIO MONITORING 30
2-WAY USB 2.0 WIRELESS AUDIO INTERFACE 32
• MAC & PC USB SETUP 34
• iPad, Surface & Tablet PC USB SETUP 38
• AUDIO LISTENING, VoIP & PODCASTING 40
SMART DEVICE DIRECT MIC CONNECTION 42
WI TRANSMITTER & RECEIVER FEATURES 44
MICROPHONES FEATURES 58
FCC NOTICE & RECYCLING INFO 62
WARRANTY 64
Thank You For Choosing Wi Digital Systems.
Congratulations on your purchase of the Wi AudioStream Pro AV 2.4GHz Smart Pocket Portable Stereo Digital
Wireless Lavalier & Audio Monitoring System with 2-Way Wireless USB 2.0 Audio Interface.
Please thoroughly read this User’s Manual for all the feature operation information necessary
to install and operate your new Wi AudioStream Pro AV system.
Notice: Product specications and package contents are subject to change without notice.
Package contents may vary according to the different regions.
For additional support, please visit www.widigitalsystems.com
CONGRATULATIONS!
PACKING LIST 5
SYSTEM CHARGING & PAIRING 6
TRANSMITER MICROPHONE SETUP
• MONO LAVALIER SETUP 8
• TRANSMITTER PLACEMENT 11
• OPTIONAL STEREO LAVALIER SETUP 12
• OPTIONAL EARSET SETUP 14
• OPTIONAL SHOTGUN SETUP 18
RECEIVER SETUP
• CAMERA CONNECTION 20
• SMARTPHONE CONNECTION 22
• TABLET & SMART DEVICE CONNECTION 26
• SOUND SYSTEM CONNECTION 28
AUDIO MONITORING 30
2-WAY USB 2.0 WIRELESS AUDIO INTERFACE 32
• MAC & PC USB SETUP 34
• iPad, Surface & Tablet PC USB SETUP 38
• AUDIO LISTENING, VoIP & PODCASTING 40
SMART DEVICE DIRECT MIC CONNECTION 42
WI TRANSMITTER & RECEIVER FEATURES 44
MICROPHONES FEATURES 58
FCC NOTICE & RECYCLING INFO 62
WARRANTY 64
Thank You For Choosing Wi Digital Systems.
Congratulations on your purchase of the Wi AudioStream Pro AV 2.4GHz Smart Pocket Portable Stereo Digital
Wireless Lavalier & Audio Monitoring System with 2-Way Wireless USB 2.0 Audio Interface.
Please thoroughly read this User’s Manual for all the feature operation information necessary
to install and operate your new Wi AudioStream Pro AV system.
Notice: Product specications and package contents are subject to change without notice.
Package contents may vary according to the different regions.
For additional support, please visit www.widigitalsystems.com
TABLE OF CONTENTS
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------
TECHNICAL SUPPORT
Getting Answers!
We want you to get the most from your new WiAudioStream ProAV stereo digital wireless audio system!
Simply logon to www.widigitalsystems.com and access the resources available online including
instructional manuals and more.
Our customer service support staff are ready to assist you with any question you may have.
Your Wi AudioStream Pro AV comes with one year of telephone support and service coverage.
There are several ways to contact Wi Digital Systems customer service support.
Website: www.widigitalsystems.com/support
Technical support: (714) 505-4567
Wi Transmitter
1/8” to 1/8” TRS Stereo
Cable & 1/4”Adapter
Universal USB
AC Charger
PACKING LIST
MIC
Windscreens
Smartphone
MountingAdapter 1/8” to 1/8” TRS
Smart Device Cable
Single Feed
Cable Clips
Wi Transmitter Wi Receiver
XLR to 1/8”
TRS Cable
1/8” to 1/8” TRS Stereo
Cable & 1/4”Adapter Hard Shell
Carrying Case
1/4”-20 Camera
Hot ShoeAdapter
Universal USB
AC Charger
USB Y-Split
Power Cable
MIC/Headphone
Adapter
USB
Data Cable
5
Wi SmartMic™ Lavalier with
Omnidirectional Microphone Capsule
1/4”-20
SmartphoneAdapter
6
Charging The System
Before using your new Wi AudioStream™ Pro AV digital wireless system,
you need to fully charge the batteries for approximately 2 hours.
1. Plug the AC Charger into a power socket.
2. Connect the USB power cable to the USB port on the AC charger.
3. Connect one of the two mini USB connectors to the Transmitter
USB port.
4. Connect the second mini USB connector to the Receiver USB port.
5. The Power/Status LED will turn to solid Red ON.
6. When charging is complete the Red LED will turn OFF.
The system’s power source’s exible design boasts 4 power options:
• 4~6 hours internal rechargeable battery use.
• 13 hours with USB AA battery adapter (optional accessory).
• Continuous use with AC power adapter.
• Continuous use with USB port bus power.
POWER
LINK
AC Charger
USB Port
Mini USB
Connector
USB Port
USB Connector
CHARGING
Pairing the Wi Transmitter & Receiver
The Wi Transmitter and Receiver are paired at the factory. Perform the
following steps ONLY if you need to reestablish connection between
the Transmitter and the Receiver.
1. First turn ON the Transmitter (Tx) and the Receiver (Rx) by pressing and
holding the POWER button , on each of the units for 2 seconds.
The green LED on Each unit will ash.
2. Press and hold the LINK button on the Transmitter (Tx) for 3 seconds.
The Power/Status green LED on the Transmitter will start ashing faster.
The Transmitter is now in a Pairing mode and ready to search for the Receiver.
3. Press and hold the LINK button on the Receiver (Rx) for 3 seconds.
The Power/Status green LED on the Receiver will ash momentarily.
4. Once the Transmitter links with the Receiver, the Power/Status LED on both
devices will turn to solid green.
5. The Transmitter and Receiver are now ready for use.
POWER
LINK
7
PAIRING
(Tx)
pk
zv
(Rx)
r
Pairing the Wi Transmitter & Receiver
The Wi Transmitter and Receiver are paired at the factory. Perform the
following steps ONLY if you need to reestablish connection between
the Transmitter and the Receiver.
1. First turn ON the Transmitter (Tx) and the Receiver (Rx) by pressing and
holding the POWER button , on each of the units for 2 seconds.
The green LED on Each unit will ash.
2. Press and hold the LINK button on the Transmitter (Tx) for 3 seconds.
The Power/Status green LED on the Transmitter will start ashing faster.
The Transmitter is now in a Pairing mode and ready to search for the Receiver.
3. Press and hold the LINK button on the Receiver (Rx) for 3 seconds.
The Power/Status green LED on the Receiver will ash momentarily.
4. Once the Transmitter links with the Receiver, the Power/Status LED on both
devices will turn to solid green.
5. The Transmitter and Receiver are now ready for use.
p
k
z
v
8
Using The Lavalier Option
The Wi SmartMic Mono Lavalier easily accommodates
alternative mounting applications such as:
• Ties, Shirts, Jackets and Behind-the-Button Positioning
• In-Hair
• Beneath T-shirts & Blouses
• Hard to MIC Instruments
The included Lavalier cable clip can be used to customize
the t of the lavalier to be both comfortable and discreet.
Ideal for lmmaking, news-gathering, presenters,
reporters, worship leaders and pastors, broadcasters,
interviewers, artists, tness instructors, speaking and
singing performers and more!
Wi SmartMic Mono Lavalier Mic
Wi Digital Systems SmartMic high-end
broadcast quality lavalier features an ultra-
small 3.1 mm MIC capsule mounted on an
ultra-thin rugged cable designed to capture
vocals clearly with excellent rejection of
wind and ambient noise.
The crisp, high-quality Wi SmartMic™ Mono
Lavalier microphone provides superb vocals
and sound pick-up from all directions mak-
ing it an excellent choice for video
camera, camcorders, DSLRs,
smartphones and tablets miking.
Refer to the “Lavalier Specs” on
page (58) for more details.
F
MONO LAVALIER SETUP
9
Using The Lavalier Option
The Wi SmartMic Mono Lavalier easily accommodates
alternative mounting applications such as:
• Ties, Shirts, Jackets and Behind-the-Button Positioning
• In-Hair
• Beneath T-shirts & Blouses
• Hard to MIC Instruments
The included Lavalier cable clip can be used to customize
the t of the lavalier to be both comfortable and discreet.
Ideal for lmmaking, news-gathering, presenters,
reporters, worship leaders and pastors, broadcasters,
interviewers, artists, tness instructors, speaking and
singing performers and more!
MONO LAVALIER SETUP
10
Connecting The Microphone to The Transmitter
Connect the 1/8” TRS end of the microphone cable to
the audio output port of the Wi Transmitter.
For Mono MIC connection, ensure that the
Transmitter is set for
Mono Mic-In Mode
and the LED is in FAST blue ashing mode.
For Stereo MIC or Mono Redundancy MIC connection,
ensure that the Transmitter is set for
Stereo Mic-In Mode
and the LED is in SLOW blue ashing mode.
For Camcorders or DSLRs without microphone noise lter
circuit or limited MIC gain control capability set the Transmitter
to
Stereo Line-In Mode
. The blue LED will reect
TWO FAST ashes.
Refer to the “Tx Button Functions”
on page (50) for more details.
j
r
r
r
j
F
F
F
r
MONO LAVALIER SETUP
