Whistler 1670 Manuel utilisateur
TM
OWNER’S MANUAL
1670
LASER/RADAR DETECTOR
If you have questions concerning the
operation of this Whistler product
please call consumer relations:
1-800-531-0004
Hours:
Monday - Friday
8:00 am - 5:00 pm CST
Please keep the receipt in a safe
place. If the unit is returned without a
dated proof of purchase an out of
warranty service charge applies.
Note: Your warranty period begins at
the time of purchase. The warranty is
validated only by return of the
Warranty Validation card.
Now is the time to record the serial
number of the unit in the space pro-
vided in the warranty section of the
manual.
INTRODUCTION
Dear Whistler Owner,
For many of us, a vehicle is more than just transportation. It
can be a mobile office, communications or entertainment
center, or simply an expression of our personality. Whistler
products are designed to make the time you spend in your
vehicle more productive, more fulfilling, safer, or just simply
more fun. Our mission is to provide products that improve
your driving experience.
Your new Whistler 1670 laser/radar detector detects all radar,
laser and safety radar systems, plus offers Whistler’s exclusive
Safe Driving System™ with Real Voice™ technology, Vehicle
Battery Saver, and Memo Features. The comprehensive safe-
ty system detects all safety radar including the Safety
Warning System™ keeping you informed of road hazards
and adverse weather. Plus, Whistler’s unique Stay Alert™ fea-
ture tests driver’s alertness on long solo trips. Whistler’s 1670
also offers a digital display with safety messages to keep you
informed while you drive, and a memo feature that allows
you to record important dates, numbers or directions.
To fully acquaint yourself with the operation of the Whistler
1670 and to better understand the differences between
detecting radar, laser and safety radar signals, we recom-
mend reading this entire manual.
Enjoy the Whistler 1670 and please drive safely.
Sincerely,
THE WHISTLER GROUP
Topic Page
Model Features Summary....................................................3 - 5
Installation .............................................................................6 - 8
• Mounting Guidelines
• Dash/Visor/Windshield Mounting
• Power Connection And Fuse Replacement
Operation ............................................................................9 - 18
• Power On And Self-Test
• Feature Engaged Confirmation
• Integrated Real Voice™
• Auto Quiet/Quiet Modes
• City Mode
• Dim/Dark Mode
• Stay Alert
• Option Select Mode
• Teach/Tutorial Mode
• Engaging/Disengaging VG-2 Detection
• Vehicle Battery Saver Mode
Radar, Laser And VG-2 Alerts ..........................................19 - 23
• Radar Alerts
• Pulse Protection®
• Safety Radar Audio/Visual Alerts
• Laser Audio/Visual Alerts
• VG-2 Audio/Visual Alerts
• Alert Priority
• Reset Features
• Care Maintenance
Troubleshooting Guide............................................................24
Are Detectors Legal?...............................................................25
Speed Monitoring Technologies.....................................26 - 27
• Radar Facts
• Laser Facts
• Other Speed Detection Systems
• Radar Detector Detectors
Warranty Information........................................................28 - 30
Specifications............................................................................31
Accessories ...............................................................................32
TABLE OF CONTENTS
WHISTLER FEATURES
Whistler’s ergonomic and user-friendly design provides a
new level of operating convenience. Special features
include:
1. Bracket Release Button – Provides quick and easy
release of the mounting bracket.
2. Power Jack – Provides connection for the power cord.
3. Speaker – Provides distinct audio and Real Voice™
warnings for X, K, Ka band radar, safety radar, laser and
VG-2.
4. Power/Dim/Dark/Play Button – Turns unit on/off and
engages Dim/Dark modes (press and hold for 2 seconds).
In Memo mode, starts/stops playing a recorded message.
5. Volume Up/Down Buttons – Adjust volume up or
down. In Memo mode, selects one of six messages.
3
Whistler 1670
1
2
3
4
5
67
8
WHISTLER FEATURES
6. High Visibility Display – Provides distinct visual confir-
mation of signals detected, signal strength, and indicates
engaged modes of operation.
7. Quiet/Menu/Record Button - Pressing QUIET before a
signal is detected engages Auto Quiet Mode which auto-
matically reduces the audio level after the initial warning to a
low audio level setting. Pressing QUIET during a radar/laser
encountersilencesaudioalerts,whileallowingvisualalertsto
keep you informed. Pressing and holding for 2 seconds
allows you to enter Option Select Mode (see page 15). In
Memo mode, this button starts/stops recording.
8. CITY/CITY 1/CITY 2 Button - Reduces the annoyance
of false alerts typically encountered in urban driving areas.
9. Laser Antenna (Rear) - An integrated optical wave-
guide provides superior detection of laser signals trans-
mitted from behind.
10. Laser Antenna (Front) - High gain optical lens
provides increased sensitivity and field of view for leading-
edge laser detection.
11. Radar Antenna - Compact, high-efficiency antenna
receives radar signals.
12. Mounting Bracket Location - Slot holds mounting
bracket firmly. 4
11
12
10
WHISTLER FEATURES
Accessories
Accessories included are highly functional and easy to use.
Power Cord - Connects to the unit’s power jack and your
vehicle’s lighter socket.
Windshield Bracket - Allows installation of unit on your
vehicle’s windshield.
Hook & Loop Fasteners - Designed to secure the unit on
a level dashboard.
5
INSTALLATION
Mounting Guidelines
•Mount the unit as low as possible near the center of the
windshield.
•Do not mount your unit behind wipers, ornaments, mir-
rored sunscreens, etc. These obstructions have metal sur-
faces which can affect radar and laser signals and reduce crit-
icalwarning time. (Regular tinted glassdoesnot affectrecep-
tion.)
•Some windshields have an Instaclear™or Electriclear™
type coating, which affect radar signals. Consult your dealer
or the owner’s manual supplied with your vehicle to deter-
mine if your windshield has this coating.
•Avoid placing unit in direct contact with windshield.
•To reduce the possibility of theft, conceal your unit when
not in use.
Windshield Mounting
•Install the two suction cups and rubber bumper onto the
bracket by fitting them into their holes.
•Press the suction cups onto the windshield at the location
you have chosen. IMPORTANT: Some newer cars have a
plastic safety coating on the inside of the windshield. The
suction cups may leave permanent marks on this type of
surface. To find out if your vehicle has this type of wind-
shield, check the owner’s manual or ask your dealer. We
recommend that you do not leave the suction cup brack-
et on the window in direct sunlight. If the detector is
removed, this may cause blistering of the dash in some
vehicles.
•Slide the detector onto the bracket until it locks into place.
• If necessary, the unit may be leveled by bending the wind-
6
INSTALLATION
shield bracket. Press the bracket release button and remove
the detector before bending.
Dash Mounting
•Make sure the mounting location you have chosen is
relatively level and is clean and dry. Clean with isopropyl
alcohol if necessary to remove any waxes or polishes.
•Separate the fastener strips. Peel the paper backing off
each strip and adhere one piece to the dash and the other
piece to the bottom of the unit, taking care not to cover
the serial number.
Be careful not to place the fastener strip over the unit’s serial number. If the
fastener strip is removed, the serial number may be pulled off the unit. Units
without serial numbers are not covered under warranty.
7
INSTALLATION
Visor Mounting (optional accessory)
• Slide the visor bracket into the bracket mounting slot.
• Clip the visor bracket onto the visor making sure it is
relatively level and has a clear view of the road.
Power Connection
• Plug the small end of the power cord into the unit’s power
jack.
• Plug the large end into the vehicle’s cigarette lighter.
Fuse Replacement
The lighter socket plug is equipped with a replaceable 2
amp 3AG fuse located behind the silver tip. To replace the
fuse, carefully unscrew the tip of the plug. (IMPORTANT:
Unscrew slowly. The tip contains a spring which may fly out
when disassembling.) Insert the new fuse with the spring and
screw on the tip. With use, screw cap on plug may loosen.
Retighten occasionally.
Unscrew the tip of the lighter socket plug carefully when replacing the 2 amp
fuse. 8
Insert into bracket mounting slot. Do not bend this
section of bracket.
Slide on view
