WHISPER KOOL EXTREME 5000TI Manuel utilisateur
EXTREME
5000 / & 8000 /
OWNER’S MANUAL
The Coolest Thing In Wine Storage
Page 2 EXti 110111
Copyright © 2011. WhisperKOOL. All rights reserved.
This manual, the product design, and the design concepts are copyrighted by WhisperKOOL, with all rights reserved. Your rights
with regard to the hardware and manual are subject to the restrictions and limitations imposed by the copyright laws of the
United States of America. Under copyright laws, this manual may not be copied, reproduced, translated, transmitted, or reduced
to any printed or electronic medium or to any machine-readable form, for any purpose, in whole or in part, without the written
consent of WhisperKOOL.
Every eort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing
or clerical errors.
WhisperKOOL reserves the right to make corrections or improvements to the information provided and to the related hardware
at any time, without notice.
Vinothèque and WhisperKOOL are registered trademarks, and ECE is a trademark of WhisperKOOL. All rights reserved.
Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommenda-
tion. WhisperKOOL assumes no liability with regard to the performance or use of these products.
11.01.11
We manufacture, test and certify 100% of our wine cooling units in
the USA. By sourcing the best components and closely controlling our
manufacturing processes, we can assure the highest-quality, lowest
defect manufacturing rates in the industry.
Page 1
TABLE OF CONTENTS
Quick Reference Guide
Unit .....................................................
Controller ................................................
Fan Speed & Specications ...............................
Introduction ................................................
Receiving & Inspecting The Unit ............................
Quick Start Guide ...........................................
Preparing the Wine Cellar ...................................
Through-the-Wall Installation
Pre-Installation ...........................................
Preparing the Installation Location . . . . . . . . . . . . . . . . . . . . . . .
Preparing the System for Installation . . . . . . . . . . . . . . . . . . . . . .
Optional Exterior Grille ...................................
Installing the Unit ........................................
Ducted Installation
Ducting Overview ........................................
Ducting Congurations ..................................
Installing the Duct Plenums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Controller Installation .............................
Drain Line ..................................................
Liquid Measuring Thermostat System ......................
Multi Speed Control ........................................
System Operation: Standard and Remote ..................
Standard Control Functions ................................
Standard Wire Schematic ...................................
Remote Controller Functions ...............................
Remote Wire Schematic .....................................
Maintenance Schedule .....................................
Troubleshooting Guide .....................................
Technical Assistance & Accessories .........................
Installation Terms and Conditions ..........................
2
6
7
8
9
10
11
14
15
16
18
20
21
22
24
25
27
28
29
30
31
34
35
38
39
40
42
44
Page 2 EXti 110111
QUICK REFERENCE GUIDE
5000 - Front / Side View
5000 / 5000 - Rear / Side View
MADE IN THE USA
Controller
Bottle Probe
Probe Input
Grille w/Filter
Control Panel
(see page 14 for details)
Compressor
Access Panel
Fan Speed Control
Grille w/Filter
Drain Port
Drain Line
Access
Rear Power Option
Page 3
QUICK REFERENCE GUIDE
5000 - Front / Side View
5000 Fully Ducted - Front / Side View
R
MADE IN THE USA
R
Rear
Controller w/Remote Box
Bottle Probe
Grille w/Filter
Control Panel
(see page 14 for details)
Compressor
Access Panel
Compressor
Access Panel
Fan Speed Control
Drain Port
Controller w/Remote Box
Bottle Probe
Return Plenum
Supply Plenum
Control Panel
(see page 14 for details)
Compressor
Access Panel
Fan Speed Control
Exhaust Plenum
Intake Plenum
Page 4 EXti 110111
QUICK REFERENCE GUIDE
8000 - Front / Side View
8000 / 8000 - Rear / Side View
Controller
Bottle Probe
Probe Input
Grille w/Filter
Control Panel
(see page 14 for details)
Compressor
Access Panel
Fan Speed Control
Grille w/Filter
Drain Port
Rear Power Option
Page 5
QUICK REFERENCE GUIDE
8000 - Front / Side View
8000 Fully Ducted - Front / Side View
Compressor
Access Panel
Controller w/Remote Box
Bottle Probe
Grille w/Filter
Control Panel
(see page 14 for details)
Compressor
Access Panel
Fan Speed Control
Controller w/Remote Box
Bottle Probe
Return Plenum
Supply Plenum
Control Panel
(see page 14 for details)
Compressor
Access Panel
Fan Speed Control
Exhaust Plenum
Intake Plenum
Page 6 EXti 110111
Evaporator and Condenser Fan
•
•
•
•
ALARM Pre-Chill Display
Control “ON/OFF” Buon
•Turns the Cooling Unit
“ON/OFF”
1
An Frost Compressor
Energy Reducon
Hi Bole Temp History & Scroll
Buon 1
Low Bole Temp History & Scroll
Buon
Push to see the min. stored temperature.
In programming mode use to browse the
parameter codes or decrease
the displayed value.
1
Energy Saving
Buon 1
Cellar “Pre-Chill” Buon 3 -5
Push to see the max stored temperature.
In programming mode use to browse the
parameter codes or increase the display
value. Hold for 3 seconds to start fast
freezing cycle.
Set Buon
View Set Point 1
Change Set Point 3-5
SET + Down = CPSM 10-15
Reset Hi & Lo Buon 3 -5
Display and modify set point. In
programming mode it selects a
parameter conrms an opera-
tion. Hold for 3 seconds when
the min or max temperature is
displayed to RESET.
Evaporator and Condenser Fan
Set Buon
•View Set Point
1
•Change Set Point
3-5
•SET + Down = CPSM
3 - 5
•Reset Hi & Lo Buon
3-5
ALARM Pre-Chill Display
Control “ON/OFF” Buon
•Turns the Cooling Unit
“ON/OFF”
1
An Frost Compressor
Hi Bole Temp History & Scroll
Buon
1
Cellar “Pre-Chill” Buon
3-5
Low Bole Temp History & Scroll
Buon
Push to see the min. stored temperature.
In programming mode use to browse the
parameter codes or decrease
the displayed value.
1
Inacve
Display and modify set point. In
programming mode it selects a
parameter conrms an opera-
tion. Hold for 3 seconds when
the min or max temperature is
displayed to RESET.
Push to see the max stored temperature.
In programming mode use to browse the
parameter codes or increase the display
value. Hold for 3 seconds to start fast
freezing cycle.
QUICK REFERENCE GUIDE
Standard Controller Layout
*If your unit is installed through the wall and does not have a remote keypad you have the Standard Controller*
Remote Controller Layout
*If your unit has a remote keypad then you have the Remote Controller*
Note: The 1 or 3-5 qualies the amount of time in seconds that the button must be pushed to activate the feature.
Refer to page 30 for complete listing of buttons and symbols.
Note: The 1 or 3-5 qualies the amount of time in seconds that the button must be pushed to activate the feature.
Refer to page 34 for complete listing of buttons and symbols.
Page 7
FAN SPEED REFERENCE
UNIT SPECIFICATIONS
Your fan speed selection will depend on the amount of heat that needs to be removed from the cellar and the ap-
plication of the unit (through a wall or fully ducted). Fan speed selection will depend on the cellar size, insulation
factor, door seal and desired wine temperature. When initially installing the unit, set the fan speed to High setting
for a quick chill down. Once the temperature of the cellar reaches the desired temperature, you may be able to select
a lower fan speed to handle the normal load. In the event the temperature outside goes above 90 degrees, (when
exhausting to the outside) you may need to select the higher fan speed.
* To get a feeling for decibels, a food blender at 3ft is 90 dBA, garbage disposal at 3ft is 85 dBA, vacuum cleaner at
10ft is 75 dBA, normal speech at 3ft is 79 dBA, dishwasher in the next room is 55dBA, Quiet night is 35dBA
Fully ducted systems need to be set and stay in the High fan speed position.
Model 5000ti & 5000tiR 8000ti & 8000tiR
Cellar Size 1000 cu. ft. 2000 cu.ft
Dimensions 14.25”W x 15.75”H x 28”D 14.25”W x 22”H x 28”D
Weight 96 lbs 110 lbs
AMPS (running) 9 10
dBA 51 low 58 med 66 high 57 low 59 med 61 high
Installation Through-the-Wall, Partially Ducted, Fully Ducted
Thermostat Digital Control Display
Temp. Delta 55°F temperature dierential
(maintains proper cellar temperature when exhaust environment does not exceed 110°F)
Outside Venting Can be done if the outside temperature does not exceed 110°F, the external grille cover is
required.
Ducting Options Unit can be fully ducted.
Warranty 2 year parts and labor / 5 year compressor
Model 5000ti & 5000tiR 8000ti & 8000tiR
Speed Selection Low Med High Low Med High
Air Flow
(CFM) 147 180 256 274 318 333
Sound
(dBA In Cellar / Out of Cellar) 51/51 58/57 66/65 57/57 59/59 60/61
Cooling Capacity
(BTU/h) 2967 3142 3360 5140 5606 5760
Page 8 EXti 110111
INTRODUCTION
Customer Service
Thank you for purchasing a WhisperKOOL Extreme Series cooling unit. We strive to provide the highest quality prod-
ucts and the best possible customer service. If you have any questions about your WhisperKOOL unit, please call us
at 1(800) 343-9463.
Using the Manual
This User’s Manual is intended to assist in the proper installation and maintenance of the WhisperKOOL Extreme cool-
ing system. In order to ensure the longevity of your cooling unit, the equipment should be installed properly and
have a proper care and maintenance schedule. Please read and review this manual carefully and keep it for future
reference.
What Is the WhisperKOOL Extreme Series Cooling System?
The WhisperKOOL Extreme Series system is a specialized refrigeration unit designed for one purpose only: to main-
tain the optimal temperature and humidity levels conducive to the proper storage and aging of ne wines. It is a
self-contained cooling unit designed to be used as a forced-air through-the-wall unit or as a remote mount unit with
external ductwork connections.
How Does the WhisperKOOL Extreme Series Work?
The WhisperKOOL Extreme Series cooling system is especially designed for the use and application to maintain
optimal conditions for wine storage and aging. The system is fully self-contained and can be installed as a “Through-
The-Wall’ application, or the unit is capable of an even more exible “Ducted” application, which allows the unit to be
placed in an indoor remote site, resulting in a quiet airow. The standard “Through-the-Wall” and ducted units are
temperature controlled via a bottle probe, and the ducted system comes standard with a remote key board that can
be located up to 50 ft from the cooling system (Note: Remote Unit comes standard with a 50 ft bottle probe and 50 ft.
of cable for the remote keypad, additional lengths are optional).
Temperature Setting
The WhisperKOOL Extreme unit can be set at any temperature within the acceptable wine-aging range of 50°F to
67°F. It is designed to cool up to 55°F cooler than the ambient temperature of the space to which it is exhausting.
