Whirlpool XWT-608 Manuel utilisateur

INSTRUCTION MANUALINSTRUCTION MANUAL

Please read instructions carefully before using

WHITEMAGIC WASHER

XWT-608

TABLE OF CONTENTS

KNOW YOUR MACHINE

Know your machine

Control panel

Installation

Wash

Drain

Rinse

You're going to use the washing machine. But first, it will be easy If you really know your machine.

Read the instruction manual carefully before using.

Spin

Care after use

Precautions

Maintenance

Reminder

CONTROL PANEL

WASH TIMER

WASHING WATER INLET

WASH TUB

LINT FILTER

PULSATOR

OUTER CASE

PLASTIC BASE

SPIN TUB

POWER CORD

DRAIN HOSE

SPIN TUB COVER

SPIN TIMER

PROGRAM SELECTOR

SAFETY COVER

WASH TUB COVER

SPINNING WATER INLET

Actual unit may differ from the picture above as it is only an illustration.

CONTROL PANEL

INSTALLATION

1.Location

2.Drain Hose

3.Inlet Hose

4.Electrical Connection

Place the machine on a flat/level surface, well-

ventilated area but away from direct sunlight or

any other heat source, conveniently close to

an electric outlet and near the drainage facility

(This could be a drain pipe, sink or bathroom).

Suitable for the down-drain type:

Drop the drain hose to a outfall ditch.

Suitable for the up-drain type:

Hang the drain hose over a drain outlet or

over the side of a bath or sink, not higher than

1.2 metres above floor level.

4.Open the Water Tap and fill the Wash Tub with

water up to 3 cm below the Water Level Mark.

5.Close the Water Tap.

6.Add a suitable amount of washing machine

detergent in the Wash Tub(Refer to the proper

amount of detergent as specified/directed by

the detergent's manufacturer).

7.Put the clothes one by one into the Wash Tub

and arrange them evenly.

8.Set the Wash Timer to the desired time or you

may refer to the table below for good washing

result.

9.Your Washing Machine will then operate as per

selected time and mode on the Wash Selector.

Connect one end of the Inlet Hose to a Water

Tap. Place the other end of the Hose into the

Inlet.

Turn both Timers (Wash and Spin) to "OFF"

position and insert the plug into an outlet.

1.Open the Wash Tub cover.

2.Insert the plug into an outlet.

3.Turn the Wash Selector to Normal, Strong.It

will depend on the type of fabric and degree of

dirt/soiled.

WASH TIME TABLE

TYPE OF

FABRIC

NORMAL

Normal

Normal Soiled

Clothes 3 - 9 mins.

HEAVY Work

Clothes 10 - 15 mins.

WASH

PROGRAM

WASH

TIME

WASH

WATER INLET WATER INLET

Whitemagic Washer

XWT-608 WASH TIMER

15 3

SPIN TIMER

SELECTOR

NORMAL

DRAIN

HEAVY

DRAIN

1.After the washing is completed, remove the

clothes from the Wash Tub and place it in the

Spin Tub.

2.If you wish to wash other clothes in the same

soapy water, you may do so. If not, turn the

Drain Selector to drain.

3.The soapy water will then be drained from the

Tub.

4.When all the water has been drained from the

Wash Tub, turn the Drain Selector to "Normal".

RINSE

After washing, it is best to first extract the soapy

wash water from the Wash Tub to obtain best

result of rinsing.

1.Place the clothes into the Spin Tub and

arrange them evenly.

2.Press the clothes gently into the Tub and place

the safety Cover so that it completely covers

the clothes (see illustration below).

3.Close spin tub cover of the Spin Tub.

4.Turn the Spin Timer to approximately 2

minutes.

5.Remove the clothes from the Spin Tub and

place it back to the empty Wash Tub.

6.Open the Tap and fill the Wash Tub with water

to a level of approximately 3 cm below the

Water Level Mark and then close the Tap.

7.Turn the Wash Selector to Normal .

8. Turn the Wash Timer to the required time.

9. After rinsing, turn the Drain Selector to Drain.

10. When all the water has been drained off ,turn

the Drain Selector to "NormaL" .

NOTE : You may repeat steps 6 to 10 if necessary.

SPIN

1.Transfer the clothes from the Wash Tub to the

Spin Tub and arrange them evenly.

2.Smaller items should be placed in first.

3.Press the clothes firmly towards the bottom of

the tub.

4.Place the safety Cover on the clothes (Please

see Illustration below) .

5.Close spin Tub Cover.

6.Turn the Spin Timer to the desired time (refer to

the table below).

SPIN TIME TABLE

MODE TYPE OF

FABRIC

SPINNING

TIME

Delicate Fabrics Synthetics 1 min.

White Fabrics Cotton-Linen 2 - 4 mins.

Heavy Fabrics Cotton 3 - 5 mins.

CARE AFTER USE

1.Ensure that the power is switched OFF and the

Plug is pulled out from the wall outlet.

2.Clean the machine with soft cloth.

3.Close the Wash Tub cover.

4.Hang up the Drain Hose well .

5.Take off the linlet Hose.

PRECAUTIONS

1.Do not touch Spin Tub while it is still rotating.

2.Do not use water hotter than 50 . Very hot

water may deform plastic parts of the machine

causing them to malfunction.

3.Always use the safety Cover duing spinning as

this prevents clothes from rising out of the Spin

Tub.

4.Do not wash the clothes with petroleum gas,

thinner or other inflammable liquids.

5.Check all clothes for loose buttons ,coins, pins,

etc.

6.Separate the clothes to be washed by color,

fabric and degree of dirt.

7.Use the detergent specifically produced for

Washing Machine.

NOTE: Do not spray water on the Control Panel.

MAINTENANCE

1. Clean

Wipe the machine with a clean dry or slightly

wet cloth. Do not use Household cleansers, or

volatile liquid cleaners.

2. Dismantle the Pulsator

If there is something under the Pulsator, it can

be taken out by dismantling the Pulsator.

Simply loose the Center Screw and use both

hands to lift evenly the Pulsator off its Shaft.

To refit, simply push it back and tighten the

screw.

3. Clean the Lint Filter

Grasp the frame of the Lint Filter, press down and

pull outwards.

Clean the lint in the Lint Filter.

REMINDER

If your machine does not work, check the following

points before calling a service technician.

1.Is the Plug in the wall outlet and is the Power

switched to ON position?

2.Is the house Safety Box Fuse blown?

3.Are the Control Knobs in the OFF position?

4.Is the Safety Box switched ON?

5.Is the Drain Hose twisted or is there any

obstruction?

NOTE: The design and the name of parts are

subject to change without prior notice.
