Whirlpool ED5HVAXVL01 Manuel utilisateur
1
CABINET PARTS
For Model: ED5HVAXVL01
(Stainless VCM)
5−09 Printed In U.S.A. (jdc)(bay) Part No. W10185508 Rev. C
Refrigerator
CABINET PARTS
2
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10166791
Energy Guide
2318584 Owner’s Manual
W10142162
Service & Wiring
Sheet
2220407 Modular Icemaker
Service Sheet
2216001 Instruction Sheet
(Door Removal)
2 2174748 Front Roller (2)
3 3400517 Screw
4 2196236 Rear Roller (2)
5 489427 Screw
6 2155013 Clip, Grille
7 489478 Screw
8 2203771 Hinge Top (RC)
9 3400113 Screw
10 8281227 Screw
11 Hinge Cover
2203407B Black
12
W10138965
Hinge Bottom
13 Filler, Wrapper
2304848 Black
14 Grille
2260500B Black
15 489497 Screw
16 489464 Screw
17 2304888 Drain Fitting
18 2304937 Extension Tube
19 2188735 Cover, Unit
20 Cabinet (Not A
Serviceable Part)
21 Hinge Cover
2203408B Black
22 549193 Clamp, Service Cord
23 489084 Screw
24 2155311 Door Closer,
Lower Cam (2)
25 489483 Screw
26 2260507 Housing, Water
Filter
27 2313412 Water Filter
28 Cap, Water
Filter
2260502B Black
29 489500 Screw
30 2260519 Block, Housing
Support
31 Button, Water
Filter
2260503B Black
32 2319867 Tube, Filter
Outlet
33 2319867 Tube, Filter
Inlet
34 2203770 Hinge Top (FC)
REFRIGERATOR LINER PARTS
3
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2194744 Escutcheon, Meat
Pan Control
3 2182757 Slide Meat
Pan Control
4 2257741 Louver
5 2256035 Bracket,
Dual Crisper
Light
6 2311637 Wire Harness,
Dual Crisper
7 2319866 Shelf Ladder
8 489478 Screw
9
W10004810
Screw (2)
10 2256085 Bracket Retainer
11 489290 Screw
12 2209753 Air Diffuser
Assembly
13 2152019 Air Diffuser
Cover
14 2150331 Cover, Wiring
15 2162085 Socket
16 2307107 Reservoir
17 1129672 Light Bulb
18 2209769 Light Lens
19 488280 Screw
REFRIGERATOR SHELF PARTS
4
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION
1 2196485 Stud Assembly
2 2209698 Cover, Crisper
3 3400894 Screw
4 2196483 Stud Assembly
5 2179259 Glass, Meat Cover
6 2174150 Glass, Cover
7 2311726 Cover, Meat Pan
8 8281158 Screw
9 2188652 Crisper Pan
10 2179343 Body, Humidity
Control
11 2179342 Slide, Humidity
Control
12 2255593 Trim, Handle
13 2188724 Meat Pan
14 2188667 Snack Bin Assy.
15 2179350 Deflector
16 2255592 Trim, Meat Pan
17
W10141750
Shelf Assy
18 2179243 Trim, Snack Pan
19
W10141749
Shelf Assembly,
Spillguard (2)
FREEZER LINER PARTS
5
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
FREEZER LINER PARTS
6
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 2211746K Shelf, Slide Out
Upper
3 2301291 Track−Shelf (RS)
4 2301292 Track−Shelf (LS)
5 2211742K Shelf−Slide Out
6 2182971 Freezer Bin
7 3400893 Screw
8 2205837K Shelf (2)
9
W10004810
Screw (8)
10 842534 Clip, Air Duct (2)
11 2198587 Cover, Emitter
12 2198635 Spring
13 2198634 Pin
14 1115373 Switch, Rocker Arm
15 2220398 P.C. Board
Emitter
16 2255588 Cover, Ice Maker
17 2212321 Slide, Ice Maker
Mounting
18 489478 Screw
19 489214 Screw
20 2162085 Light Socket
21 2255743 Light Bulb
22 8281185 Screw
23 2198633 Flipper
24 2255558 Cover, Receiver
25 2255562 Slide, Ice Maker
Shut Off
26 2255114 P.C. Board,
Receiver
27 2198643 Lens
28 2198589 Light Shield
29 2212340 Light Lens
30 2198641 Bracket, Ice Maker
Cover
31 2155597 Socket, Light
32 Ladder
2198609 Left Side
2198610 Right Side
33 2303234 Shield, Wiring
MOTOR AND ICE CONTAINER PARTS
7
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
MOTOR AND ICE CONTAINER PARTS
8
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION
1 2198573 Ice Bin
2 2317254 Crusher Bin
3 2317240 Auger
4 2258220 Washer
5 1119007 Spacer, Flat (4)
6 2317248 Cover, Crusher
7 2257024 Blade, Rotary
8 1119005 Spacer, Step (2)
9 2257020 Blade, Fixed
10 2257023 Blade, Rotary
11 2317239 Block, Blade
12 489229 Roll Pin
13 2257022 Blade, Rotary
14 489235 Washer, Plain
15 2198661 Washer, Coupling
16 2188918 Coupling
17 8281164 Screw
18 3400065 Screw
19 2317262 Latch, Bin
20 2198608 Spring, Latch
21 8281163 Screw
22 2188919 Holder
23 2317243 Wiper
24 2198628 Seal
25 2317250 Divider, Chamber
26 2188916 Drive Shaft
27 2256154 Enclosure, Motor
28 2315544 Dispenser, Motor
29 2212305 Cover
30 489478 Screw
31 2315559 Sleeve, Coupling
100 2317251 Ice Container
(Complete)
REFRIGERATOR DOOR PARTS
9
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
REFRIGERATOR DOOR PARTS
10
For Model: ED5HVAXVL01
(Stainless VCM)
W10185508
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes Item #6)
2326326LG
Stainless VCM
2 2256101 Compartment Door
3 2203828K Shelf Bin (3)
4 3400012 Screw
5 2156022K Trivet, Shelf
6 Door Gasket,
Magnetic
2221313 Black
7 Handle, Extr
W10127768
Black
8 2182178 Door Closer,
Upper Cam
9 489420 Screw
10 Bracket, Door Stop
2206629B Black
11 2308091 Thimble−Top
12 2255121 Nameplate
13 Handle, Endcap
W10152862
Black
14 2255411 Clip, Mounting
15
W10155511
Screw, Clip
