WhatsGPS S100 Manuel utilisateur
Model:S100
User Manual
4G Vehicle GPS Tracker
Quick starting
Accessories
Appearance and interface
1. Correct install SIM card, Backup battery, Power line
2. Switch on the device, and make sure all indicate
light working (P6)
Main
machine Power line Sticker Backup
battery
Operation of switch button
Under the status of switch off: Long press this button
for 3 seconds to boot Under the status of switch on:
Long press this button for 3 seconds to shut down
Installation method
Note: This button is in recessed design, please use
sharp objects such as nib
1. Install SIM card and backup battery Open the
battery cover, insert the SIM card and fasten it, and
then install the backup battery and close the battery
cover.
2. Install the device
The device is recommended to be installed by a
professional organization designated by the dealer,
and pay attention to the following:
1) In order to avoid thief damage, the device
installation should be as concealed as possible;
2) Avoid being placed with the launch source, such
as reversing radar, other in-vehicle communication
equipment, etc.;
3) Avoid high temperature and high humidity
environment;
4) Use strapping or double-sided adhesive tape to
avoid affecting the effect of vibration detection;
5) Make sure that the front side (printed with This Side
Up) is facing up, and there is no metal covering on the
top;
3. Install power line
1) The standard power supply of this equipment is 9V
~ 30V (for cars, motorcycles) or 30V ~ 72V (for electric
bicycles), the red line is the positive pole of the power
supply, and the black line is the negative pole of the
power supply;
2) Please select a separate grounding for the negative
pole of the power supply, and do not connect it with
other grounding wires;
3. Install power line
1) The standard power supply of this equipment is 9V
~ 30V (for cars, motorcycles) or 30V ~ 72V (for electric
bicycles), the red line is the positive pole of the power
supply, and the black line is the negative pole of the
power supply;
2) Please select a separate grounding for the negative
pole of the power supply, and do not connect it with
other grounding wires;
4. Wire diagram
As below picture:
Color Description
Red
Black
Orange
Purple
Interface line description
Status indication
Positive, connect with the positive of
E-bike/Motorcycle
ACC detection, Connect the electric
door lock of the E-bike or the ACC
line of the motorcycle.
Negative, connect with ground wire
Cut off oil wire
1. SIM Card indication light
Status Meaning
Bright
Slow flash
Dark
Device is turned on and the SIM card is normal
Device is turned on but the SIM card
is not working properly
Not booting
2. GSM Signal strength indicator
Status Meaning
Bright
Slow flash
Dark
Full signal
3 signal level
Fast flash 1-2 signal level
No signal
3. GPS Signal strength indicator
Status Meaning
Bright
Slow flash
Dark
Positioning success
Search for satellites but can't locate
Fast flash GPS module is working but no satellite
signal is found
GPS module is turned off or not
working properly
Platform tracking
Command description
Operation of platform logging
1. Download APP and installed it, open and logging
your account (Account/final 6 numbers of IMEI)
2. Multiple device management, it required dealer
account The website is www.whatsgps.com
1.Activate
Use your mobile phone to send text messages to the
tracker: SZMM, initial password, new password,
tracker phone number. The initial password is
123456, and the new password is set by the user.
Command: SZMM, initial password, new password,
phone number
[Example]: SZMM, 123456, 123456, 138XXXXXXXX
The "138XXXXXXXX" is the phone number of the card
inserted in the tracker.
After receiving the prompt message, the owner can
perform other SMS command operations or online
check operations.APN Command
2. SMS operation
1) Set password
The method is the same as the "Activate" operation in
the previous section.
2) Address information positioning
Command: DW , sent to the tracker phone number,
and the tracker will reply to the Chinese text message,
which describes the current location of the vehicle.
For example: near the XX Building, XX Road, XX City,
XX Province.
3) Longitude and latitude positioning
Command: DWJW , sent to the tracker phone number,
and the tracker will reply to the location parameters
(latitude and longitude and base station number) to
which the vehicle belongs, without returning a
specific textual description of the location.
4) Fortification
Command: SF , sent to the tracker phone number.
After the setting is successful, the vehicle will be
alerted by SMS when the vehicle is illegally moved or
illegally vibrated.
5) Disarming
Command: CF , sent to the tracker phone number.
After the setup is successful, the tracker returns to
normal.
3. Turn on vibration SMS notification:
SZCS, password, VIB=1
Turn off vibration SMS notification:
SZCS, password, VIB=0
[Note]: The factory defaults to turn off. If you need this
function, please turn it on yourself and you can alarm
in the armed state.
4. Turn on vibration phone notification:
SZCS, password, VIBCALL=1
Turn off vibrate phone notification:
SZCS, password, VIBCALL=0 (default)
5. Turn on speeding SMS notification:
SZCS, password, SPEED = 130
(Speeding 130 km is SMS alarm, the value is freely set)
Turn off speeding SMS notifications:
SZCS, password, SPEED =0 (default)
6. Turn on the power off and low power alarm:
SZCS, password, POF=1 (default)
Turn off power off and low power alarms:
SZCS, password, POF=0
7. Turn on power off alarm report:
SZCS, password, POFSW =1
Turn off power off alarm report:
SZCS, password, POFSW =0
8. Turn on vibration alarm report:
SZCS, password, VIBS =1
9. Dial the tracker mobile phone card number for 15
seconds (three ticks around the beep is fortification)
Call the tracker card number again for 5 seconds
(After hang up and hang up is to disarm)
Loop this way
SMS code: SZCS, password, CALLDISP=1 (factory
default)
(The owner number dial is valid, but the locator card
number needs to be activated for caller ID!)
SMS code: SZCS, password, CALLDISP=0 (requires
the owner to set it himself)
(Any number dial is valid, the locator card number
does not need to open caller ID!)
10. Turn on sleep mode: SZCS, password, SLEEP =1
Turn off sleep mode: SZCS, password, SLEEP =0
(default)
(Auto Sleep Description: Automatically enters the
sleep power saving state after more than 30 minutes
of rest.
Immediately wake up with vibration, or the owner dials
the locator card number to wake up)
11. Turn on the displacement alarm:
SZCS, password, OUTSMS =1
Turn off displacement alarm:
