Whacker Verve 2.0 Mode d’emploi

Verve2.0

Installation&UserManual

Contents

Chapter1Safety&PrecautionsforInstallers&Users..............................................................................5

SafetyMessagestoInstallers&UsersBeforeInstallation.................................................................5

SafetyMessagestoInstallers&UsersDuringInstallation................................................................6

Chapter2IntroductiontothePoliceLightzLinearSlimProSeries...........................................................7

Features&Options...................................................................................................................7

TechnicalSpecifications.............................................................................................................7

Chapter3InstallingthePoliceLightzLinearSlimProSeries...................................................................8

InstallingtheMountingFeet.......................................................................................................8

InstallingtheLightbarandMountingBrackets...............................................................................9

Chapter4WiringthePoliceLightzLinearSlimProSeries.....................................................................10

RoutingtheWireHarnessestotheCabinandPowerSource............................................................10

MountingandConnectingtheControlPanel/Box.........................................................................10

HardwiringtheLightbartoNonFactoryControlPanel/Box............................................................11

Customer&TechnicalSupportInformation........................................................................................12

CHAPTER1

SafetyandPrecautionsforInstallers&Users

Forthesafetyofinstallersanduserspleasereadthismanualthoroughlybeforeinstalling,operatingandservicing

theWhackerTechnologiesVerve2.0.Thesafetyguidelinesandinstructionsthroughouttheusermanualare

reminderstoexercisecautionandcareatalltime.Pleasemakesuretokeepthisusermanualathandforquick

reference.Todownloadcopiesorupdatesofthismanualpleasevisitwww.whackerusa.com.Forquestionsrelatedto

thisorotherWhackerTechnologiesproductspleasecontactusat[email protected]orcallthe

WhackerTechnologiesTechnicalDepartmentat8882504144.

Note:Thisequipmentisintendedforusebyauthorizedpersonnelonly.Itistheresponsibilityoftheowner/operator

toobeyalllawsregardingemergencysafetyequipment.WhackerTechnologies,Incandanyofitssubsidiariesare

notresponsibleorliableforanylossresultingfromimproperorunauthorizeduseofthisequipment.

TheproperuseandinstallationofallWhackerTechnologiesproductsisimportanttoguaranteethatyougetfull

usefromsafetyproduct.Itisimportantthattheinstalleranduserreadandfollowallinstructionsshippedwiththis

product.

BeforeInstallationand/orService

● Topreventdamagetoproducts,pleaseensurethatallequipmentoperatesproperlybeforeinstallation.Also

carefullyplanwheretomountandwiretheequipment.

● Verifythatthelightbarandmountinghardwarefitthevehicle(Note:Universalbracketsmaynotfitthe

vehicleperfectly).

● Determinethelocationtomounttheequipment,locatetherouteforwiringtheequipmentpowercable,

locatetherouteforthefunctioncable.

● TheLEDsandlightingcomponentsofthisequipmentincludingbutnotlimitedtotheLEDs,strobetubes,

lensesandhousinggethotduringoperations.Pleaseallowallcomponentstocoolbeforeinstallingand/or

servicingequipment.

LED&LightWarning

● Thisequipmentproducesbrightlightsthatcanbehazardoustoyoureyesightwhenviewedwithinclose

proximityand/orforextendedperiodsoftime.Donotstaredirectlyintothisemergencylightingequipment

withincloseproximityand/orforextendedperiodsoftimeaspermanentdamagetoyoureyesightmayoccur.

● Donotinstallthisoranyemergencylightingequipmentinanareathatwouldblockand/orinterferewiththe

operator’sdrivingability.Careshouldbetakentomakesurethatcomponentsofthevehiclearenot

blockingthewarningequipmenttoensuremaximumvisibilityfromalldirections.

Electrical&WiringWarning

● Publicsafetyandwarningequipmentrequirehighelectricalvoltages.Ensurethatallwiringandconnections

areproperlyprotected/insulated.

● Goodelectricalconnectionstochassispositiveandgroundarenecessaryforoptimumefficiency.Separate

positiveandgroundconnectionsmustbemade.Ensurethatallwiresareratedcorrectlytohandlethe

amperagerequirementsoftherequirement.

DuringInstallationand/orService

● Ensurethatallequipmentandwiringdonotinterferewithanyairbagequipmentoritsabilitytofunction

properly.

● Separateallequipmentfromtwowayradioequipmenteveniftheequipmentisequippedwiththeproper

insulation.Toavoidinterferencewithsomeequipmentmakesurethatthetwowayradioantennasarea

minimumof50cmawayfromwarningequipment.

● Donotconnecttheequipmenttothebatteryuntilallotherconnectionshavebeenmadeandtestedto

ensurenoshortsinthesystemexist.

● Ifmountingtheequipmentrequiresthattheinstallerdrillsholes,theinstallermustmakesurethatno

vehiclescomponentscanbedamagedduringthedrillingprocess.Topreventelectricalshortsordamageto

anyoftheequipmentcomponentsensurethatalldrilledholeshavegrommetsinstalled.Alsoensurethatall

mountingscrewsandcomponentsdonotdamageanyofthewires.

● Duringthedrillingprocessensurethatmetalshavingdonotgetinsidetheequipment.Metalshavingscan

damagetheinternalwiringandpartsoftheequipment.

● Locatethecontrolequipmentsothattheusercansafelyoperatethevehicleandtheemergencyequipment

underalldrivingconditions.

AfterInstallationand/orService

●Testallequipmenttoensurethatallfunctionsworkproperly.Checktomakesurethatduringtheinstallation

oftheequipmentnosystemsorpartsofthevehicleweredamagedoraltered.

Failuretofollowallsafetywarningsandinstructionslocatedinthismanualmayresultindamagetotheequipment

and/orvehicle,seriousinjuryordeath.Pleaseretainthisusermanualforfuturereference.

CHAPTER2

IntroductiontotheWhackerVerve2.0LEDFullSizeLightBar

TheWhackerVerve2.0isanexterior,roofmounted360degreewarninglightsystemthatcanbeutilizedby

professionalsinawiderangeofindustries.TheVerve2.0iscurrentlyavailableina50”modelwithuniversalor

vehiclespecificmountingequipment.

Features&Options

TheWhackerVerve2.0LEDLightbarcomesstandardwith33selfcontainedwarningpatterns.TheVervecontainsa

totalof22warningmodulesthatincludestwotakedownsandtwoalleys.Thelightbarcomesinstandardcolor

configurationsofamber,red,blueorred/bluebutcolorscanalsobecustomizedpermodule.

Features:

● Coloroptions:Amber,Red,Blue,Red/Blueorcustomcolorconfiguration

● 120GenerationIIILEDs

● 33FlashPatternsincludingsteadyburn

● Integratedarrowstick

TechnicalSpecifications:

● Dimensions:50”Lx11.5”Wx4.375”H

● Weight:35lb

● WireHarness:19.5’

● UniversalMountingEquipment(Vehiclespecificmountinghardwareisavailableseparately).

CHAPTER3

InstallingtheWhackerVerve2.0

AfterunpackingtheWhackerVerve2.0,carefullyinspecttheunitfordamagethatmayhaveoccurredduringtransit.

Ifanydamagehasbeenfoundreportthedamagetothecarrierandkeeptheoriginalshippingcartonuntiltheclaim

hasbeenresolvedanddonotinstalltheproduct.Contactyourdealerordistributortofindouthowtoresolvethe

issuebeyondwhattheshippingcarrierhandles.Ifyouaremissingparts,contactcustomerserviceat8882504144.

Testtheunitbeforeinstallation.Totesttheunittouchtheblackwiretothegroundandtheotherwirestothe+12

voltDContheautomotivebattery.Ifanyproblemsoccuratthispointdonotinstallthelightbarandcontactthe

factoryat8882504144.

Onlyusethemountingequipmentandscrewssuppliedwiththeunit.Installingthisunitwithnonfactoryequipment

ormodifyingthemountingequipmentmayresultindamagetotheunitandthelossofwarrantycoverage.

IMPORTANT:Planallcableroutingbeforebeginningtheinstallationofthisunit.Ensurethatthelightsystem

controlsforthisunitarelocatedinaplacewheretheydonotinterferewithanyvehiclesafetyequipmentandwhere

thecontrolcanbesafelyoperatedbytheenduserunderalldrivingconditions.Failuretodosocanresultindriver

errorswhileoperatingthevehicle.

PreparingtoInstallMountingFeet

Useproperliftingtechniqueswhenremovingorinstallingthisproduct.Improperliftingtechniquesandavoiding

thiswarningcouldresultinpersonalinjury.

1.Placethelightbarwiththesmoothsurface(top)ofthelightbarfacinguponsoftragsorcardboardmaterialto

avoidscratchingordentingofthealuminumhousing.

2.Removeeachendcapbyremovingthefourscrewsoneachendcap.Therearetwoscrewsonthetopandtwo

screwsonthebottomofeachendcap.

3.Afterinstallingthemountingfeetpositiontheendcapsbackintheappropriatelocationandattachtothebodyof

thebarwiththefourscrews.

InstallingtheMountingFeet

1.Placethelightbarupsidedownonsoftragsorcardboardmaterialtoavoidscratchingordentingofthealuminum

housing.

2.Takethemountingfootandinsertfourbolts(eighttotal)throughthefouraccessholesonthemountingfoot

surfaceplate.

3.Positionthefourboltsattheopeningtothemountingtrackandslidethemountingfootintothedesiredlocation

onthetrack.

4.Installfourflatwashers,lockwasherandnutsonthebolts,leavingtheboltsjustlooseenoughtorepositionthe

mountingfootifnecessary.Donottightenthenutsyet.

5.Repeatthisprocessforthesecondmountingfoot.

InstallingtheLightbarontheVehicleRoof

1.Placethelightbaronthevehicleroofinthedesiredlocation.Thelightbarisusuallycenteredonthedoorcenter

post(Bpillar).

2.Adjustbothmountingfeetinoroutasnecessaryuntilthefootpadsrestneartheedgeoftherooforgutterwhere

theroofisthemostrigid.Makesurethatthelightbarandthemountingfeetarecenteredlefttorightonthevehicle.

3.Checkthatthelightbarislevelbyshiftingthelightbarslightlyforwardorback.

4.Carefullyremovethelightbarfromthevehicleroofandplaceitupsidedownonsoftragsorcardboardmaterialto

avoidscratchingordentingtothealuminumhousing.Ensurethatthemountingfeetdonotshifttheirposition.

5.Tightenthenutsthatsecurethemountingfeetinplacetothelightbar.

InstallingtheUniversalorVehicleSpecificMountingBracket

1.Placethelightbaronthevehicleroof.TheassemblyisusuallycenteredovertheBpillar.

2.Determinewherethemountingbracketwillattachtothevehicle.

3.Placethemountingbracketontheroofsheetmetal.

4.Placethemountingboltfromthemountingfeetthroughthedesiredpositiononthemountingbracketandtighten

inplacewiththeflatwasherandnut.

5.Securethemountingbrackettothevehicleusinga5/16”18boltoftheappropriatelength.

6.Repeatthisprocesstoinstallthesecondvehiclemountingbracket.

IMPORTANT:Frequentlyinspectthelightbar,mountingfeetandmountingbracketstoensurethatallfastenersand

bracketsaretight.

CHAPTER4

WiringtheWhackerVerve2.0

Beforewiringthelightbarinthevehicle,ensurethatthelightbarisproperlyinstalledandsecuredtothevehiclewith

thefactoryincludedmountingkit.

Thislightbariscompletelywiredatthefactoryanddoesnotneedanyadditionalinternalwiring.Moststandard

functionsofthislightbarcanbecontrolledbythefactoryincludedcontrolpanel/box.

AIRBAGDEPLOYMENT

Donotinstallequipmentorrouteanywiringofthisunitwhereitmayinterferewiththedeploymentofthevehicle

installedairbagorothersafetyequipment.

Failuretoobservethiswarningwithreducetheeffectivenessoroperationoftheairbagandanyothervehiclesafety

equipmentandcancauseseriousinjuryordeath.

BATTERYWARNING

Toavoidabatteryexplosion,disconnectthenegativecablefirstandreconnectitlastwheninstallingormaintaining

theequipment.Avoidanelectricalinterferenceorsparkswhenconnectingtheequipmentorworkingnearthe

battery.

1.Ensurethatalllinesareproperlyfusedwith20ampfuse(ifrequired).Fromthelightbar,routetheusercontrolwire

harnessintothevehiclescabneartheeventuallocationofthefactoryincludedcontrolpanel/box.

2.Routethepowerwireharnesstothevehicle’sbatteryandconnectthered+12positivewireandblacknegative

wiretothebattery.

MountingandConnectingtheControlPanel/Box

Lightcontrolsystemsincludingallcontrolpanels/boxesmustbelocatedinthevehiclesotheycanbeoperated

safelyunderalldrivingconditions.Lightcontrolsystemsmustbepositionedsoasnottointerferewithallvehicle

safetyequipment.

1.Preparethemountingareabyensuringthatthequickconnectwireharnessfromthecontrolpanel/boxreachedthe

quickconnectwireharnessfromthelightbar.Ensurethatthemountingareaislargeenoughtofitthecontrol

panel/box.Thefactoryincludedcontrolpanelboxdimensionsare:6⅛”x5”x2⅛”notincludingthemounting

bracket.

2.Positionthefactoryincludedcontrolpanel/boxmountingbracketinthedesiredlocationandmarkthelocationin

thevehiclefordrillingtwoholes.Oncemarkedandtheholesaredrilledinstallthemountingbracketwiththeincluded

screws.
