Westinghouse LTV-20V4 Instructions de montage

Westinghouse Digital Electronics

Power Button

Keypad

CONGRATULATIONS on pur-

chasing a Westinghouse LCD

TV! This Quick Connect Guide

will help you get started in 3

easy steps. On the back you

will find information to maxi-

mize your LCD TV experience.

For complete installation,

usage instructions, and safety

precautions please refer to

the User’s Manual.

20”

QUICK

CONNECT

GUIDE

CONNECT THE

POWER

Use the enclosed AC

power cable to connect

to a power outlet.

CONNECT THE

TUNER

Connect either cable or

TV antenna wire to the

cable ready NTSC tuner

input labeled "ANT" on the

connection panel.

Note: This step can be skipped if

you do not use these options.

Refer to the table on the back for

connection to satellite set top

box or digital cable.

CONNECT A DVD

PLAYER

Connect a DVD player

to the component YPbPr

input (Red, Green, blue)

and the corresponding

component audio inputs.

Press the Power button

to turn on the LCD TV.

GO!

LTV-20v4 LCD TV

www.westinghousedigital.com

Video 1 (S-Video 1)/

Video 2 (S-Video 2)/YPbPr/ANT Inputs

MAXIMIZE

YOUR LCD TV

EXPERIENCE

You can attach your LCD TV to

a variety of electronic devices

including a digital cable or

satellite set top box, a game

console or a VCR. The chart

shows our recommendations

for the best quality picture for

these commonly used devices.

If you have trouble connecting

these or other devices, please

refer to the User’s Manual.

TYPICAL SETUP

• Progressive scan DVD players with YPbPr

• Game console action using Video Input

• VCR viewing and editing with S-Video

*Only if receiver outputs 480p

DID YOU KNOW THAT

YOUR LCD TV ALSO HAS:

• Integrated 3 W Stereo Speakers

• Progressive Scan

• Inverse 3:2 Pull Down

CHECK OUT

www.westinghousedigital.com for our:

• Versatile Décor Wall Mounting options

reserved. Specifications subject to change without notice.

¼, Westinghouse and You can be sure... if it's Westinghouse are

trademarks of Westinghouse Electric Corporation and are

used under license.

MA-PS-0113-0501 Customer Service: 866.287.5555 • www.westinghousedigital.com

Use the source button on the remote control or keypad to navigate

between the TV, Video 1 (S-Video 1), Video 2 (S-Video 2) or YPbPr

inputs.

Digital Cable/

Satellite Receiver Good Better Better Best*

DVD Player Good Better Best

Game Console Good Better Best

VCR Good Better Best

YPbPr

Video S-VideoANT

VIDEO INPUTS

Note: The audio input is shared between Video and S-Video.

S Video Input 1

YPbPr Video Input

Video Input 1

Menu SourceChannel Volume

YPbPr Audio Input

Right Audio Input 1Left Audio Input 1

Video Input 2

Left Audio Input 2

S Video Input 2

Right Audio Input 2

ANT
