Westgate DV62 Manuel utilisateur
50-2163
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED
PAPER.
TECHNICAL
MANUAL
DV62
This appliance may be installed in an
after-market permanently located,
where not prohibited by local codes.
This appliance is only for use with
the type of gas indicated on the
rating plate. This appliance is not
convertible for use with other gases,
unless a certied kit is used.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open
ame.
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbour’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
WARNING: If the information in this manual is
not followed exactly, a re or explosion may result
causing property damage, personal injury or loss of
life. Installation and service must be performed by a
qualied installer, service agency or the gas supplier.
FOR YOUR SAFETY: Do not store or use gasoline or
other ammable vapours and liquids in the vicinity of
this or any other appliance.
Massachusetts installations (Warning): This product must be installed by a licensed plumber or
gas tter when installed within the Commonwealth of Massachusetts. Other Massachusetts code
requirements: Flexible connector must not be longer than 36in., a shut off valve must be installed;
only direct vent sealed combustion products are approved for bedrooms/bathrooms. A carbon
monoxide detector is required in all rooms containing gas red direct vent appliances. The replace
damper must be removed or welded in the open position prior to installation of a replace insert.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
BY: SHERWOOD INDUSTRIES LTD
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
FOR SAFE INSTALLATION AND OPERATION OF YOUR “WESTGATE”
HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION:
• All Westgate gas-red appliances must be installed
in accordance with their instructions. Carefully read all
the instructions in this manual rst. Consult the building
authority having jurisdiction to determine the need for a
permit prior to commencing the installation.
• NOTE: Failure to follow these instructions could
cause a malfunction of the replace, which could result in
death, serious bodily injury, and/or property damage.
• Failure to follow these instructions may also void
your re insurance and/or warranty.
GENERAL
• Installation and repair should be done by a qualied
service person. The appliance should be inspected before
the rst use and, at least, annually by a qualied service
person. More frequent cleaning may be required due to
excessive lint from carpeting, bedding material, etc. It
is imperative the control compartments, burners and
circulating air passageways of the appliance be kept
clean.
• Due to high temperatures, the appliance should be
located out of high trafc areas and away from furniture
and draperies.
Children and adults should be alerted to the
hazards of high surface temperatures and should
stay away to avoid burn or clothing ignition.
• Young children should be carefully supervised when
they are in the same room as the appliance, Toddlers,
young children and others may be susceptible to accidental
contact burns. A physical barrier is recommended if there
are at risk individuals in the house. To restrict access to
a replace or stove, install an adjustable safety gate to
keep toddlers, young children and other at risk individuals
out of the room and away from hot surfaces.
• Clothing or other ammable materials should not be
placed on or near the appliance.
FOR YOUR SAFETY
• Installation and service must be performed by a
qualied installer, service agency or gas supplier.
• This installation must conform to local codes or, in the
absence of local codes, to the current CAN/CSA-B149.1
Natural Gas and Propane Installation Code (Canada) or
National Fuel Gas Code ANSI Z223.1.2 (USA)
• To prevent injury, do not allow anyone who is
unfamiliar with the replace to operate it.
• To prevent injury, if the pilot or pilot and
burners have gone out on their own, open the
glass door and wait 5 minutes to air out before
attempting to re-light the replace.
• Always keep the area around these appliances clear
of combustible material, gasoline and other ammable
liquids and vapours.
• These appliances should not be used as a drying
rack for clothing or for hanging Christmas stockings/
decorations.
• Due to the paint curing on the replace, odor and
slight smoking will likely be noticed when the replace is
rst used. Open a window until the smoking stops.
Always connect this gas replace to a vent system and
vent to the outside of the building envelope. Never vent
to another room or inside the building. Make sure the
specied vent pipe is used, properly sized and of adequate
height to provide sufcient draft. Inspect the venting
system annually for blockage and signs of deterioration.
WARNING: Failure to position the parts in accordance
with the diagrams in this booklet, or failure to use only
parts specically approved with this appliance, may result
in property damage or personal injury.
WARNING: Do not operate with the glass front removed,
cracked or broken. Replacement of the glass should be
done by a licensed or qualied service person.
• Never use solid fuels such as wood, paper, cardboard,
coal, or any ammable liquids, etc., in this appliance.
• Do not use this heater if any part has been under
water. Immediately call a qualied service technician to
inspect the heater and to replace any part of the control
or gas control systems that have been under water.
• Do not abuse the glass by striking it or slamming the
door shut.
Safety PrecautionS
2
HOT GLASS WILL
CAUSE BURNS
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW
CHILDREN TO TOUCH
GLASS.
WARNING
table of contentS
Safety Precautions..........................................................................................2
Table of Contents............................................................................................3
Codes And Approvals......................................................................................4
Specications.................................................................................................5
Dimensions........................................................................................5
Rating Label Location..........................................................................5
Rating Label.......................................................................................6
Planning Your Installation................................................................................7
Introduction.......................................................................................7
Non-Combustible Material Zone............................................................7
Typical Framing - Internal Chase..........................................................8
Typical Framing - External Chase..........................................................9
Typical Framing - Corner:...................................................................10
Typical Framing - Sidewall and Mantel.................................................11
Typical Framing - Raised Hearth.........................................................12
Installation of Facing Trim..................................................................13
Installation of Fireplace Facing...........................................................14
Installation of Receiver.......................................................................16
Allowable Vent Congurations............................................................17
Vent Termination Restrictions.............................................................18
Approved Vent Parts..........................................................................19
Installation of Flue Restrictor..............................................................20
Planning Your Installation..................................................................21
Assembly of the Unit.........................................................................21
Securing unit into Position.................................................................21
Installation Set-Up........................................................................................22
Installation Of Non-combustible Wall ..................................................22
Installation Of Venting And Terminations.............................................23
Horizontal Installation........................................................................23
Vertical Termination Installation..........................................................26
Door Removal and Installation...........................................................28
Gas Hook-Up.....................................................................................29
Electrical Hook-Up.............................................................................30
Firebox Liner Installation...................................................................30
Log Burner / Ember Bed Installation...................................................32
Log Set Installation...........................................................................34
Glass Burner Installation...................................................................39
Porcelain Panel Kit Installation............................................................41
Optional Front Installation.................................................................44
Wiring Harness.............................................................................................45
Diagnostic Flash codes..................................................................................46
Troubleshooting............................................................................................47
Parts Diagram...............................................................................................49
Parts Diagram - Options................................................................................50
Parts List......................................................................................................51
Warranty......................................................................................................53
Installation Data Sheet..................................................................................54
3
DIRECT VENT ONLY: This type is identied by the prex DV. This appliance draws all of its air for
combustion from outside the dwelling, through a specially designed vent pipe system.
In the USA: The appliance may be installed at higher altitudes. Please refer to your American Gas
Association guidelines which state: the sea level rated input of Gas Designed Appliances installed at
elevations above 2000 (610 m) feet is to be reduced 4% for each 1000 feet (305 m) above sea level.
Refer also to National Fuel Gas Code, ANSI Z223.1/ NFPA 54, local authorities, or codes which have
jurisdiction in your area regarding the de-rate guidelines.
In Canada: When the appliance is installed at elevations above 4500 feet (1372 m), the certied high
altitude rating shall be reduced at the rate of 4% for each additional 1000 feet (305 m). Refer also
to CSA-B149.1 Natural Gas and Propane Installation Code, local authorities, or codes which have
jurisdiction in your area regarding the de-rate guidelines.
• This appliance has been tested by LabTest Certication Inc. and found to comply with the
established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows:
VENTED GAS FIREPLACE HEATER (DV62)
TESTED TO: ANSI Z21.88-2009/CSA 2.33-2009 VENTED GAS FIREPLACE HEATERS
CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES
CSA P.4.1-R2009 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY
This Westgate DV62 Fireplace:
• Has been certied for use only with natural gas.
• Is not for use with solid fuels.
• Is approved for bedroom or bed sitting room. (IN CANADA: must be installed with a listed wall
codeS and aPProvalS
thermostat. IN USA: see current ANSI Z223.1 for installation instructions.)
• Must be installed in accordance with local codes. If none exist, use current
installation code CAN/CSA-B149.1 Natural Gas and Propane Installation
Code in Canada or ANSI Z223.1/NFPA 54 in the USA.
• Must be properly connected to an approved venting system and not connected
to a chimney ue serving a separate solid-fuel burning appliance.
• The ow of combustion and ventilation air not be obstructed.
IMPORTANT NOTICE (Regarding rst re up): When the unit is turned
on for the rst time, it should be turned onto high without the fan on for
the rst 4 hours. This will cure the paint, logs, gasket material and other
products used in the manufacturing process. It is advisable to open a
window or door, as the unit will start to smoke and can irritate some people.
After the unit has gone through the rst burn, turn the unit off including the
pilot, let the unit get cold then remove the glass door and clean it with a
good gas replace glass cleaner, available at your local WESTGATE dealer.
4
5
Rating LabeL Location:
SPecificationS
Dimensions:
Figure 1. Dimensions of the Firebox.
The Rating and Lighting instruction label is located below the door frame,
underneath the rebox attached to a chain. To access the label, slide the
plate forward out from under the rebox. Always return it when nished.
Figure 2. Rating/Lighting Label Location.
SPecificationS
Rating LabeL:
Figure 3. Rating Label.
SAMPLE
6
7
Planning your inStallation
intRoDuction:
This section of the technical manual is for the use of qualied technicians only. Fireplace placement, hearths,
facings, mantles, and venting terminations will be covered, as well as the gas and electric systems. There are
several installation safety guidelines that must be adhered to. Please carefully read the safety precautions at the
front of this manual.
Warning: Clearances must be sufcient to allow access for maintenance and service.
If installing a Power Vent Kit (50-1970) refer to the instructions included with the kits to aid in your planning.
non-combustibLe mateRiaL Zone:
This installation guide will show you many options for installing your new DV62. Some options include external
chases, internal chases, rock facing and corner installations. No matter what direction your installation takes, this
illustration shows an area where combustible building products may NOT go. This illustration applies to any and all
installations for the DV62 and should be used as the rst reference before any others. Failure to comply with this
requirement can lead to elevated operating temperatures, degradation of materials or even result in re. If you are
un-clear about any details contained here, consult with your retailer prior to installation.
Figure 4. Non-Combustible Material Zone.
Figure 6. Typical Framing for Internal Chase - Detailed.
Planning your inStallation
typicaL FRaming - inteRnaL chase:
Figure 5. Typical Framing for Internal Chase - General.
8
9
Figure 7. Typical Framing for External Chase - General.
Figure 8. Typical Framing for External Chase - Detailed.
Planning your inStallation
typicaL FRaming - exteRnaL chase:
Figure 10. Typical Framing for Corner - Detailed.
Planning your inStallation
typicaL FRaming - coRneR:
Figure 9. Typical Framing for Corner - General.
10
Autres manuels pour DV62
3
Table des matières
Autres manuels Westgate Cheminée intérieure
