Westar WSS55010 Manuel utilisateur

WSS5O1O

Version 2.1

Installation

Manual

Table of Contents

Section 1 - System Introduction

1.1 Specifications ....................................................................... 1

1.2 Additional Devices ............................................................... 2

1.2.1 Keypads ............................................................................... 2

1.2.2 WSS5108 Eight Zone Expander Module ............................. 2

1.2.3 WSS5132-RS Wireless Receiver Module ............................ 2

1.2.4 WSS5204 Power Supply Output Module ............................. 3

1.2.5 WSS5208 Eight Low Current Output Module ...................... 3

1.2.6 WSS5580 Module ................................................................. 3

1.2.7 WSS5928 Audio Interface Module ...................................... 3

1.2.8 WSS5400 Printer Module ..................................................... 3

1.2.9 LINKS 1000 Cellular Communicator .................................... 4

1.2.10 Cabinets ............................................................................... 4

1.2.11 Backplates ........................................................................... 4

1.3 Out of the Box ...................................................................... 4

Section 2 - Getting Started

2.1 Installation Steps .................................................................. 5

2.2 Terminal Descriptions .......................................................... 6

2.3 Keybus Operation and Wiring ............................................. 7

2.4 Current Ratings - Modules and Accessories ...................... 8

2.5 Assigning Zones to Zone Expanders .................................. 8

2.6 Keypad Assignment ............................................................. 9

2.6.1 How to Assign Keypads ...................................................... 9

2.7 Enable Supervision .............................................................. 9

2.8 Removing Modules ............................................................ 10

2.9 Zone Wiring ........................................................................ 10

2.9.1 Normally Closed (NC) Loops ............................................. 10

2.9.2 Single End Of Line (EOL) Resistors .................................. 11

2.9.3 Double End of Line (DEOL) Resistors ............................... 11

2.9.4 Fire Zone Wiring - 4 wire Smoke Detectors ....................... 11

2.9.5 Fire Zone Wiring - 2 wire Smoke Detectors ....................... 12

2.9.6 LINKS Supervisory ............................................................. 12

2.9.7 LINKS Answer .................................................................... 12

Section 3 - Keypad Commands

3.1 Access Codes .................................................................... 13

3.2 Arming ................................................................................ 13

3.2.1 Stay Arming ........................................................................ 13

3.2.2 Away Arming ...................................................................... 13

3.3 Disarming ........................................................................... 14

3.4 [ ] Commands .................................................................. 14

[] [1] Zone Bypass/Reactivate Stay/Away Zones .......... 14

[] [2] Trouble Display ...................................................... 14

[] [3] Alarm Memory ....................................................... 16

[] [5] Programming Access Codes ................................ 16

[] [6] User Functions ....................................................... 17

[] [7] Output Functions ................................................... 18

[] [8] Installer Programming ........................................... 18

[] [9] Arming Without Entry Delay .................................. 18

3.5 Function Keys .................................................................... 18

Section 4 - How to Program

4.1 How to Enter Installer Programming .................................. 19

4.2 Programming Decimal Data ............................................... 19

4.3 Programming HEX Data ..................................................... 19

4.4 Programming Toggle Option Sections ............................... 20

4.5 Viewing Programming ........................................................ 20

4.5.1 LED Keypad ....................................................................... 20

4.5.2 LCD Keypad ....................................................................... 20

Section 5 - Program Description

5.1 Zone Definitions ................................................................. 21

5.2 Zone Attributes ................................................................... 23

5.3 Communicator - Dialing ..................................................... 24

5.4 Communicator - Phone Numbers ...................................... 24

5.5 Communicator - Account Identifier Code/DLS Panel

ID Code .............................................................................. 24

5.6 Communicator - Reporting Formats .................................. 24

5.6.1 SIA (Level 1) ....................................................................... 24

5.6.2 Pager Format ...................................................................... 25

5.7 Communicator - Reporting Codes..................................... 25

5.7.1 Zone Alarm ......................................................................... 25

5.7.2 Zone Restoral ..................................................................... 25

5.7.3 Closings.............................................................................. 25

5.7.4 Openings ............................................................................ 25

5.7.5 Tampers .............................................................................. 26

5.7.6 Priority/Emergency ............................................................. 26

5.7.7 Maintenance ....................................................................... 26

5.7.8 Test Transmissions ............................................................. 27

5.7.9 Wireless Maintenance ........................................................ 27

5.7.10 Miscellaneous .................................................................... 27

5.7.11 Up and About Timer ........................................................... 27

5.8 Downloading ...................................................................... 27

5.9 PGM Outputs ...................................................................... 28

5.9.1 PGM Output Options.......................................................... 28

5.9.2 WSSFOB PGM Pulse Timer ............................................... 30

5.10 Telephone Line Monitor (TLM) ........................................... 30

5.11 Siren Supervision ............................................................... 30

5.12 Test Transmission ............................................................... 30

5.13 Fire, Auxiliary, Panic Keys ................................................. 31

5.14 Entry/Exit Delay Options .................................................... 31

5.15 Event Buffer ........................................................................ 31

5.15.1 Viewing the Event Buffer through the LCD Keypad .......... 31

5.15.2 Stored Events ..................................................................... 32

5.16 Swinger Shutdown ............................................................. 32

5.17 Transmission Delay ............................................................ 32

5.18 Keypad Backlighting.......................................................... 33

5.19 Arming/Disarming Options ................................................ 33

5.20 Bell Output Options ........................................................... 33

5.21 Keypad Lockout ................................................................. 33

5.22 Keypad Blanking ................................................................ 33

5.23 Loop Response .................................................................. 33

5.24 LINKS 1000 Cellular Communicator .................................. 33

5.24.1 Using the LINKS as a Backup Communicator .................. 34

5.25 Wireless Expansion ............................................................ 34

5.25.1 Supervision of Wireless Zones .......................................... 34

5.26 WSS5580 Module ............................................................... 34

5.27 On-Site Printer .................................................................... 35

5.28 Audio Interface Module ..................................................... 35

5.29 Default (Factory) ................................................................ 35

5.29.1 Factory Default Main Panel (Hardware) ............................ 35

5.29.2 Factory Default Main Panel (Software) and other

Modules .............................................................................. 35

5.30 Installer Lockout ................................................................. 36

5.31 Walk Test (Installer) ............................................................ 36

5.31.1 Buzzer Walk Test Mode ..................................................... 36

5.31.2 Bell/Buzzer Walk Test Mode .............................................. 36

5.31.3 To end the Installer Walk Test with no communications ... 36

5.31.4 To end the Installer Walk Test with communications ......... 36

For the Record .............................................................................. 37

WSS5010 - Zone 1-32 Assignment ............................................. 38

Keypad Programming

[000] Keypad Assignment ............................................................. 39

Basic System Programming

Zone Definitions ............................................................................. 39

[001]-[003] Zone 1-24 Definitions ................................................. 39

[004] Zone 25-32 Definitions ......................................................... 40

[005] System times ........................................................................ 40

[006] Installer’s Code ..................................................................... 40

[007] Master Code ......................................................................... 40

[009]-[011] WSS5010 PGM Output Programming ........................ 40

[012] Keypad Lockout Options ..................................................... 41

[013]-[015] System Option Codes ................................................. 41

Advanced System Programming

Zone Attribute Defaults .................................................................. 42

Zone 1-32 Attributes ...................................................................... 42

[160] Maximum Dialing Attempts to Each Phone Number ........... 43

[161] Post Dial Wait for Handshake ............................................... 43

[162] Delay Between Dialing Attempts ......................................... 43

[170] Cross Zone Timer ................................................................. 43

[171] Up and About Timer ............................................................. 43

[172] WSSFOB PGM Pulse Timer .................................................. 43

Communicator Programming

[301] First Telephone Number ....................................................... 43

[302] Second Telephone Number .................................................. 43

[310] Account Identifier Code / DLS Panel ID Code .................... 43

[360] First Telephone Number Dialing Options ............................. 43

[361] First Telephone Number LINKS Backup Dialing Options .... 44

[365] Second Telephone Number Dialing Options ....................... 44

[370] Communication Variables..................................................... 44

[380] First Communicator Option Code ........................................ 44

[390] LINKS Preamble (Telephone Number) ................................. 44

Downloading Programming

[401] First Downloading Option Code ........................................... 45

[402] Downloading Computer’s Telephone Number ( 32 Digits) .. 45

[403] Downloading Access Code.................................................. 45

[404] Number of RIngs to Answer ................................................. 45

[405] Answering Machine Double-call Timer ................................ 45

[490] Initiate PC-LINK (Direct Connect Local Download) ............ 45

Module Programming

[801] RS232 Module (WSS5400) Programming ............................ 46

[804] WSS5132 Wireless Expansion Programming ...................... 46

Special Installer Functions

[902] Module Supervision Enable/Reset ....................................... 49

[903] View Module Supervision Field ............................................ 49

[904] Wireless Module Placement Test ......................................... 49

[980] Installer Buzzer Walk Test Mode Begin ............................... 49

[981] Installer Buzzer/Bell Walk Test Mode Begin ........................ 49

[982] Installer Walk Test Mode End (No Communications) .......... 49

[983] Installer Walk Test Mode End (Communications) ................ 49

[990] Installer Lockout Enable ....................................................... 49

[991] Installer Lockout Disable ...................................................... 49

[995] Restore WSS5580 Factory Default Programming ................ 49

[996] Restore WSS5132-RS Factory Default Programming .......... 49

[997] Restore WSS5400 Factory Default Programming ................ 49

[998] Restore WSS5928 Factory Default Programming ................ 49

[999] Restore Factory Default Programming ................................ 49

Programming LCD Keypads

How to Program the WSS5500 Keypad ......................................... 49

Appendix A - SIA Format ............................................................. 52

Appendix B - Pager Format ......................................................... 53

WSS5010 Control Panel Hookup Diagram................................. 54

System Introduction

S E C T I O N 1

1.1 Specifications

Control Panel Specifications

Flexible Zone Configuration:

• 8 Fully Programmable Zones

• 37 Access Codes: 32 User, 1 System Master, 2 Master and 2 Duress

• Expandable to 32 Zones

• Hardwired expansion available using the WSS5108 Eight Zone Expansion Module

• Wireless expansion available using the WSS5132-RS Wireless Zone Expansion Module (up to 32

wireless zones, 900MHz, True Spread Spectrum Technology, Fully Supervised)

• Normally Closed, Single EOL or Double EOL zone supervision

• 2-Wire Smoke Zone

• 27 Zone Types, 8 Programmable Zone Options

Audible Alarm Output:

• Supervised Bell Output (current limited at 3 amps), 12 VDC

• Steady or Pulsed Output

EEPROM Memory:

• Will not lose programming or system status on complete AC and Battery failure

Programmable Outputs:

• Up to 14 Programmable Voltage Outputs, 26 programmable options

• One High Current (300 mA) PGM output with 2 wire smoke detector capability on main panel

• Maximum Loop Current is 1.5 mA when the 2-wire smoke detector configuration is used

• One Low Current (50 mA) PGM output on main panel

• Eight Additional Low Current (50 mA) PGM outputs available using the WSS5208 module

• Four High Current (1 Amp) PGM outputs Available Using the WSS5204 module

• 1 WSS5204 Output Fully Supervised for Siren Output

Powerful 1 Amp Regulated Power Supply:

• 500 mA Auxiliary Supply, 12 VDC

• Positive Temperature Coefficient (PTC) components replace fuses

• Supervision for loss of AC Power, Low Battery

• Internal Clock Locked to AC Power Frequency

Power Requirements:

• Transformer = 16.5 VAC, 40VA • Battery = 12 volt 4 Ah minimum rechargeable sealed lead acid

Remote Keypad Specifications:

• 2 Different Keypads Available: • Connect up to 8 Keypads

- WSS5508 8 Zone LED Keypad • Four Wire (Quad) Connection to Keybus

- WSS5500 LCD Alphanumeric Keypad • Built in Piezoelectric Buzzer

Digital Communicator Specifications:

• Supports SIA Format • Event Initiated Personal Paging

• 2 Programmable Phone Numbers • 1 Account number

• Supports LINKS 1000 Cellular Communication • DTMF and Pulse Dialing

• DPDT Line Seizure • Anti-jam Feature

• Split Reporting of Selected Transmissions to Each Telephone Number

System Supervision Features

The WSS5010 continuously monitors a number of possible trouble conditions including:

• AC Power Failure • Trouble by Zone • Fire Trouble

• Telephone Line Trouble • Low Battery Condition • Bell Output Trouble

• Loss of Internal Clock • AUX Power Supply Fault • Tamper by Zone

• Failure to Communicate • Module Fault (Supervisory or Tamper)

False Alarm Prevention Features

• Audible Exit Delay • Audible Exit Fault • Urgency on Entry Delay

• Quick Exit • Swinger Shutdown • Recent Closing Transmission

• Communication Delay

S Y S T E M I N T R O D U C T I O N

Additional Features

• Keypad Activated Alarm Output and Communicator Test

• Keypad Lockout

• Audio Capability using the WSS5928 Audio Interface Module which allows local intercom and Central

Station 2-Way Listen in.

• All modules connect to the system via a four wire Keybus up to 1000’/330m from main panel

• Event Buffer can be printed using WSS5400 RS232 Serial Interface module

• Supports the WSS5580 Voice Prompt Module with Automation/Lighting Control

• 128 Event Buffer, Time and Date Stamped

• Upload/Download Capability

1.2 Additional Devices

1.2.1 Keypads

A maximum of eight (8) keypads can be connected to the control panel and can be any combination of

the following listed.

WSS5508 WSS5500

8 zone LED keypad with function keys LCD keypad with function keys

1.2.2 WSS5108 Eight Zone Expander Module

Eight zone expander module can be used to increase the number of zones on

the system. Up to 3 modules can be connected to increase the system zones to

a maximum of 32.

(See WSS5108 Installation Instructions.)

1.2.3 WSS5132-RS Wireless Receiver Module

The WSS5132-RS Wireless Receiver module can be used to connect up to 32

wireless devices. All devices are spread spectrum, 900 MHz, fully supervised

and use standard ‘AAA’ or ‘AA’ alkaline batteries

(See Section 5.25 “Wireless

Expansion”). (See WSS5132-RS Installation Manual.)

Additional wireless devices are available:

WSSPIR WSSSMK WSSSLX WSSPNC WSSFOB

WSSPIR Wireless Motion Detector

The wireless Motion Detector can be used in conjunction with the WSS5132-RS Wireless Receiver to

include wireless space protection. The unit comes with four ‘AAA’ batteries

WSSUTX/SLX Wireless Universal Transmitter

The wireless Universal Transmitter can be used in conjunction with the WSS5132-RS Wireless Receiver

module to add wireless door or window contacts. The Universal Transmitter comes with three ‘AAA’

batteries and has built-in contacts. The unit also provides terminals for connecting hardwire contacts

WSSSMK Wireless Smoke Detector

The wireless Smoke Detector can be used in conjunction with the WSS5132-RS Wireless Receiver to

include wireless fire (smoke) protection. The unit comes with six ‘AA’ batteries.

WSSPNC Wireless Panic Pendant

The wireless Panic Pendant can be used in conjunction with the WSS5132-RS Wireless Receiver to

include a mobile panic zone.

WSSFOB Wireless Key Fob

The wireless Key Fob can be used in conjunction with the WSS5132-RS Wireless Receiver as a portable unit

which can arm and disarm the system as well as activate PGM outputs and send emergency transmissions.

1.2.4 WSS5204 Power Supply Output Module

S Y S T E M I N T R O D U C T I O N

The WSS5204 can provide up to 1 Amp of additional power for modules or

devices connected to the control panel. The module requires a 16.5 volt AC 40

VA transformer and 4 AH battery. In addition, the module provides 4 program-

mable high current voltage outputs. Each output is individually programmable

with 26 different output options available

(See Section 5.9 “PGM Outputs”).

(See WSS5204 Installation Instructions.)

1.2.5 WSS5208 Eight Low Current Output Module

Adds eight low current outputs (50 mA) to the control. Each output is individu-

ally programmable with 26 different output options available

(See Section 5.9

“PGM Outputs”). (See WSS5208 Installation Instructions.)

1.2.6 WSS5580 Module This WSS5580 module will turn any touch tone phone into a fully functional

keypad. The module also includes a built-in interface to control up to 32 line

carrier type devices for lighting and temperature control

(See Section 5.26

“WSS5580 Module”).

For more information, see the WSS5580 Installation Manual.

1.2.7 WSS5928 Audio Interface Module

(This device is not UL Listed)

The WSS5928 Audio Interface module is a simple way to incorporate paging,

intercom, baby listen-in and door answer to the WSS5010 control panel. The

module also has talking and listening-in capability for the central station

(See

Section 5.28 “Audio Interface Module”).

Four additional devices are available:

WSS5923 WSS5923 EXT WSS5923 EXT/R WSS5904

WSS5923 Intercom Audio Station

(This device is not UL Listed)

The WSS5923 Intercom Audio Station can be used in conjunction with the WSS5928 Audio Interface Module

WSS5923 EXT Door Box Audio Station

(This device is not UL Listed)

The WSS5923 EXT Door Box Audio Station can be used in conjunction with the WSS5928 Audio Interface

Module

WSS5923 EXT/R Door Box Audio Station

(This device is not UL Listed)

The WSS5923 EXT/R Door Box Audio Station can be used in conjunction with the WSS5928 Audio

Interface Module. The Door Box contains a relay so the normal door bell can be used instead of the

internal one generated by the WSS5928 module.

WSS5904 Central Station Talk / Listen Module

(This device is not UL Listed)

The WSS5904 Central Station Talk / Listen module can be used in conjunction with the WSS5928 Audio

Interface Module

1.2.8 WSS5400 Printer ModuleThis WSS5400 Printer Module will allow the panel to print out all events that

occur on the system to any serial printer. All events will be printed with the time,

date and the event that occurred

(See Section 5.27 “On-site Printer”).

1.2.9 LINKS 1000 Cellular Communicator

(This device is not UL Listed)

S Y S T E M I N T R O D U C T I O N

The LINKS 1000 Cellular Communicator provides an efficient, cost-effective

method for adding cellular back up. The unit comes in its own cabinet with

antenna and requires a separate battery and transformer

(See Section 5.24

“LINKS 1000 cellular communicator”).

1.2.10 Cabinets

Several different cabinets are available for the WSS5010 modules:

WSS5002C Cabinet

Cabinet to house the WSS5010 main control panel and also the WSS5204 Power Supply Output Module.

Dimensions 213mm x 235mm x 78mm / 8.4” x 9.25” x 3” approximately.

WSS5004C Cabinet

Cabinet to house the WSS5580 Module and WSS5400 Printer Module. Dimensions 229mm x 178mm x

65mm / 9” x 7” x 2.6” approximately.

WSS5001C Cabinet

Cabinet to house the WSS5108 Zone Expander Module and the WSS5208 Eight Low Current Output

Module. Dimensions 153mm x 122mm x 38mm / 6” x 4.8” x 1.5” approximately.

WSS5001CP Cabinet

Plastic cabinet to house the WSS5108 Zone Expander Module, WSS5132-RS Wireless Receiver Module

and the WSS5208 Eight Low Current Output Module. Dimensions 146mm x 105mm x 25.5mm / 5.75” x

4.2” x 1” approximately.

WSS5132C Cabinet

Cabinet to house the WSS5132-RS Wireless Receiver Module. Dimensions 165mm x 143mm x 38mm /

6.5” x 5.625” x 1.5” approximately.

CMC-1 Attack Resistant Enclosure

Listed enclosure for local installations where attack resistance is required. Dimensions 288mm x 298mm

x 78mm / 11.3” x 11.7” x 3” approximately.

1.2.11 Backplates

There are two different backplates available for keypads to locate an Audio Station next to the keypad:

WSS55BP1 Backplate This backplate is to be used when an Audio Station is to be located next to

a keypad. Dimensions 208mm x 115mm x 18mm / 8.2” x 4.5” x 0.25”

approximately.

WSS55BP2 Backplate This backplate is to be used when an Audio Station is to be located next

to a keypad. In addition the backplate will allow you to mount a WSS5108

Zone Expander Module or the WSS5208 Eight Low Current Output

Module. Dimensions 208mm x 115mm x 18mm / 8.2” x 4.5” x 0.7”

approximately.

1.3 Out of the Box

You should find the following equipment included in your system. Verify each of the components is included:

• one WSS5010 main control cabinet (WSS5002C)

• one WSS5010 main control circuit board

• one Installation Manual

• one hardware pack consisting of:

- 5 plastic circuit board standoffs - 16 5600 ohm (5.6K) resistors

- 1 2200 ohm (2.2K) resistor - 1 1000 ohm (1K) resistor

- 16V 40VA transformer - ULF siren

- RJ-31X telephone block and cord - Battery, 12V, 4 Ah

Note: In order to complete the installation, a keypad(s) must also be used.

Getting Started

S E C T I O N 2

The following sections provide a complete description of how to wire and configure devices and zones.

2.1 Installation Steps

The following steps are provided to assist with the installation of the panel. It is suggested that you read

over this section briefly to get an overall understanding of the order of installation. Once this is done

carefully work through each step. Working from this plan will help reduce problems and reduce the

overall installation time required.

Step 1 Create a Layout

Draw a rough sketch of the building and include all alarm detection devices, zone expanders, keypads

and all other modules that are required.

Step 2 Mounting the Panel

Locate the panel in a dry area, preferably located near an unswitched AC power source and the incoming

telephone line.

Before attaching the cabinet to the wall be sure to press the five circuit board

mounting studs into the cabinet from the back.

Complete all wiring before applying AC or connecting the battery

.....

Step 3 Wiring the Keybus

(Section 2.3)

Wire the Keybus to each of the modules following the guidelines provided.

Step 4 Assigning Zones to Zone Expanders

(Section 2.5)

If zone expander modules are being used the modules must be configured so the panel knows which

zones are assigned to each expander. Follow the guideline provided to assign zones to expanders.

Step 5 Zone Wiring

(Section 2.9)

Power down the control panel and complete all zone wiring. Follow the guidelines provided in Section 2.9

to connect zones using normally closed loops, single EOL resistor, double EOL resistors, Fire zones and

Keyswitch Arming zones.

Step 6 Completing Wiring

Complete all other wiring including bells or sirens, phone line connections, ground connections or any

other wiring necessary. Follow the guidelines provided in Section 2.2 “Terminal Descriptions”.

Step 7 Power up the Control

Once all zone wiring and Keybus wiring is complete, power up the control panel.

The panel will not power up if only the battery is connected.

Step 8 Keypad Assignment

(Section 2.6)

Keypads must be assigned to different slots to be properly supervised. Follow the guideline provided in

Section 2.6 to assign keypads.

Step 9 Enabling Supervision

(Section 2.7)

After all modules have been wired to the Keybus, supervision must be enabled. Once supervision is

enabled, the panel will be able to indicate module communication faults. Follow the guidelines provided

in Section 2.7.

Step 10 Programming the System

(Sections 4 and 5)

Section 4.0 provides a complete description of how to program the panel. Section 5.0 contains complete

descriptions of the various programmable features, what options are available and how the options function.

The Programming Work Sheets should be filled out completely before attempting to program the system.

Step 11 Testing the System

Test the panel completely to ensure that all features and functions are operating as programmed.

G E T T I N G S T A R T E D

2.2 Terminal Descriptions

AC Terminals - AC

The panel requires a 16.5 volt, 40 VA transformer. Connect the transformer to an unswitched AC source

and connect the transformer to these terminals.

Do not connect the transformer until all other wiring is complete

.....

Battery Connection

The battery is used to provide back up power in the event of an AC power failure and to provide

additional current when the panel demands exceed the power output of the transformer, such as when

the panel is in alarm.

Do not connect the battery until all other wiring is complete

Connect the RED battery lead to the positive of the battery, the BLACK battery lead to the negative.

Auxiliary Power Terminals - AUX+ and GND

These terminals provide up to 500 mA of additional current at 12 VDC

(rated 11.6 - 12.6 V

for UL residential

applications)

for devices requiring power. Connect the positive side of any device requiring power to the

AUX+ terminal, the negative side to GND. The AUX output is protected; if too much current is drawn from

these terminals (wiring short) the panel will temporarily shut off the output, until the problem is corrected.

Bell Output Terminals - BELL+ and BELL-

These terminals provide up to 3 Amps of current at 12 VDC

(rated 11.6 - 12.6 V

for UL residential

applications)

(with stand-by battery; 700 mA continuous) for powering bells, sirens, strobes or other

warning type equipment. Connect the positive side of any alarm warning device to BELL+, the negative

side to BELL–. The BELL output is protected; if too much current is drawn from these terminals (wiring

short) the BELL fuse will open.

The Bell output is supervised. If no alarm warning device is being used connect a 1000 ohm resistor

across BELL+ and BELL– to prevent the panel from displaying a trouble condition

(See Section 3.4 “[ ]

Commands, [ ] [2]”).

If an alarm warning device is being used, connect the 1000 ohm resistor at the end

of the line across the last device.

Keybus Terminals - RED, BLK, YEL, GRN

The Keybus is used by the panel to communicate with modules and by modules to communicate with the

panel. Each module has four Keybus terminals that must be connected to the four Keybus terminals on

the panel. For more information,

see Section 2.3 “Keybus Operation and Wiring”.

Programmable Outputs - PGM1 and PGM2

Each PGM output is an open collector switch to ground. That is, when the PGM output is activated by the

panel the terminal will switch to ground.

PGM1 can sink up to 50 mA of current to activate LEDs or a small buzzer. Connect the positive side of the

LED or buzzer to AUX+, the negative side to PGM1. If more than 50 mA of current is required a relay must

be used. Refer to the following diagram:

PGM2 operates similar to PGM1.

Zone Input Terminals - Z1 to Z8

Each detection device must be connected to a zone on the control. It is suggested that each zone have

one detection device however it is possible to wire multiple detection devices to the same zone.

For zone wiring specifics,

see Section 2.9 “Zone Wiring” .

G E T T I N G S T A R T E D

Telephone Connection Terminals - TIP, RING, T-1, R-1

If a telephone line is required for central station communication or downloading connect an RJ-31X jack in

the following manner:

• RING - Red Wire ........ Incoming line from • R-1 - Grey Wire .......... Outgoing line to

• TIP - Green Wire telephone company • T-1 - Brown Wire house telephone(s)

Ensure the plugs and jacks meet the dimension, tolerance and metallic plating requirements

of 47 C.F.R. Part 68, SubPart F

.....

For proper operation there must be no other telephone equipment connected between the

control panel and the telephone company facilities

.....

2.3 Keybus Operation and Wiring

The Keybus is used by the panel to communicate with all modules connected and by the modules to talk to

the panel. The RED and BLK terminals are used to provide power while YEL and GRN are clock and data.

The 4 Keybus terminals of the panel must be connected to the 4 Keybus terminals or wires of

all modules.

The following conditions apply:

• Keybus should be run in minimum 22 gauge quad (0.5mm), two pair twist preferred

• the modules can be home run to the panel, connected in series or can be T-tapped

• any module can be connected anywhere along the Keybus, you do not need a separate Keybus wire

run for keypads, zone expanders etc.

• no module can be more than 1,000'/330m (in wire length) from the panel

• shielded wire is not necessary unless wires are run in an area that may present excessive RF noise or

interference

Example of Keybus Wiring

PANEL 500’

500’

150’

PANEL 500’

500’

150’

NOTE: Module (A) is wired correctly as it is within 1,000'/330m of the panel, in wire distance.

Module (B) is wired correctly as it is within 1,000'/330m of the panel, in wire distance

Module (C) is NOT wired correctly as it is further than 1,000'/330m from the panel, in wire distance.
