Well ENJOY Manuel utilisateur
INSTRUCTION MANUAL
DIGITAL VIDEO BROADCASTING
Thank you for choosing WELL. Please read carefully the following instructions and keep them
within reach.
Reorder No: REC-DVBT2-ENJOY-WL
1. Control Elements
Front Panel
POWER: Standby button
CH - : Channel down
CH + : Channel up
USB: USB Port
Rear Panel
ANT IN
ANT OUT
Coaxial
HD-OUT
SCART
DC: 12V for Power Adapter
2. Remote Control
1.STANDBY: Switch The Standby Mode
2.EPG: Electronic Program Guide
3.INFO: Show The Current Program Information
4.AUDIO: Choose Audio language Or Audio Mode
5.FAV: Enter Favorite List
6.MENU:Enter The Main Menu
7.CH+: Change Channel+
8.V+/-: Change Vol
9.CH-: Change Channel-
10.P+: Page Up
11.Number (0~9): Select A Channel Or Setting
12.REV: Return
13.FWD: Forward
14.Play/Pause
15.MUTE: Mute Or Restore Audio Output
16.PVR: Personal Video Recording
17.SUBTITLE: Select Subtitle Language
18.Exit: Exit The Current Menu
19.OK
20.P-: Page Down
21.RECALL: Return To Last Playing Program Or Last Operation
22.GoTo
23.Next
24.PRVE: Return To Last Page 25.REC: Record Program 26.Stop
27.28.29.30.Multi-Function Key
3. Basic Functions
3.1 First Installation
First installation shall setup some important configures. It contains several options shown as
figures below:
User can select Region, Language, Display Mode, Aspect Mode from this menu, when it is
complete, user can use “OK” to search channels as shown in the figure below:
3.2 Display Information Of Programs
Press key “INFO” to show the information of current programs when it is in normal playing state.
4. Installation
There are two kinds of installation mode as follow:
1 DVB-T2 Channel Scan
2 DVB T-2 Auto Scan
You can press “Right” button to enter into this menu, then press “up/down/ right/left” to choose
and change below functions:
DVBT channel Scan
DVBT Auto Scan
LCN ~ to be on or off
5.Tool
Parental Lock
The input default password is “1234”.
If “menu lock” on, the You can lock the menu of channel edit and searching.
If parental rating choose ”18 years”, that can lock the adult channels.
6.System Setup
System setup menu can provide convenient system setup, as shown below:
Press “Right” button to enter this menu and press up/down to choose and do the edit as you want.
Language
TV System
Display Setting
Local Time Setting
Local Code Setting
Timer Setting
Parental Lock
OSD Setting
7. Software Update
Upgrade by USB
Please make sure don't shut down the power in the upgrade process; When upgrade finish, system
will automatic restart with the new firmware.
Waste electrical and electronic equipment are a special waste category,
collection, storage, transport, treatment and recycling are important
because they can avoid environmental pollution and are harmful to
health. Submitting waste electrical and electronic equipment to special
collection centers makes the waste to be recycled properly and protecting
the environment. Do not forget! Each electric appliance that arrives at the
landfill, the field, pollutes the environment!
Importer & distributor:
SC VITACOM ELECTRONICS SRL
CIF: RO 214527
Tel. 0264-438401*
