Weinmann ACCUVAC Basic Manuel

Description and

Operating Instructions

ACCUVAC

Basic

Aspirator

WM 10700

WM 10709

Contents

Description

. . . . . . . . . . . . . . . . . . . .

1.1

Purpose

. . . . . . . . . . . . . . . .

1.2

Function

. . . . . . . . . . . . . . . .

Safety

. . . . . . . . . . . . . . . . . . . . . . .

2.1

Special symbols on the

appliance

. . . . . . . . . . . . . . .

2.2

Safety rules

. . . . . . . . . . . . . .

Assembly

. . . . . . . . . . . . . . . . . . . . .

3.1

Assembly with wall bracket

. . .

3.2

Fitting a

re-usable

collection

canister

. . . . . . . . . . . . . . .

3.3

Fitting an accessory bag

. . . .

3.4

Fitting a rinsing glass

. . . . . .

Operation

. . . . . . . . . . . . . . . . . . .

4.1

Preparing for aspiration

. . . . .

4.2

Aspiration

. . . . . . . . . . . . . .

4.3

After aspiration

. . . . . . . . . .

4.4

Charging

ACCUVAC

Basic

. .

Hygienic preparation

. . . . . . . . . . .

5.1

Preparations

. . . . . . . . . . . . .

5.2

Cleaning, disinfecting and

sterilizing

. . . . . . . . . . . . . . .

5.3

Reassembling the disposable

collection canister

. . . . . . . . .

Functional check

. . . . . . . . . . . . . . .

6.1

Intervals

. . . . . . . . . . . . . . . .

6.2

Performing the functional check

Troubleshooting

. . . . . . . . . . . . . . .

7.1

Power pack

. . . . . . . . . . . . .

7.2

Changing fuses

. . . . . . . . . .

7.3

Changing the muffler

. . . . . . .

Maintenance

. . . . . . . . . . . . . . . . .

8.1

Intervals

. . . . . . . . . . . . . . . .

8.2

Disposal

. . . . . . . . . . . . . . .

Product and accessories

. . . . . . . . .

9.1

Standard product

. . . . . . . . .

9.2

Accessories

. . . . . . . . . . . . .

9.3

Spare parts

. . . . . . . . . . . . .

10.

Technical Data

. . . . . . . . . . . . . . . .

10.1

Safe distances

. . . . . . . . . . .

11.

Warranty

. . . . . . . . . . . . . . . . . . . .

-1,0

-0,8

-0,6 -0,4

-0,2

ACCUVAC

Basic

from front with disposable collection canister

Disposable

canister

2Vacuum control

3Voltage indicator

8Motor unit

6Release catch

4On/Off

switch

9Tube holder plate

1Pressure gage

5Membrane keyboard

ACCUVAC Basic from rear without collection canister

13 Muffler

(hidden)

11 Adapter/charger

plug

14 Suction port

12 Power socket

(hidden) 10 Loops for

accessory bag

ACCUVAC Basic interior

18 Plug X1 17 Power pack

15 Fuse F116 Fuse F2 (hidden)

Disposable collection canister

24 Collection canister

21 Disposable bag

19 Aspiration tube

with fingertip

23 T-piece

20 Intermediate tube

25 Holder 11 Adapter/charger plug

22 Vacuum

tube

Accessories

38 Holder set WM 15271 Connection cable

WM 10650

Accessory bag

WM 10655

Wall bracket

WM 15208

13,8 V

Mains / charger unit

WM 2645

27 Vent tab

28 Filter cover

29 Bacteria filter

30 Locking tab

32 Secretion cover

33 Ball (overfill guard)

37 Collection canister

36 Aspiration tube

35 Fingertip

26 Re-usable collection canister WM 15269

34 Sealing ring

31 Bracing

2Description

1. Description

1.1 Purpose

ACCUVAC Basic is a mobile and portable electrically

powered aspirator (suction pump).

It is used for:

•aspirating accumulations of blood, secretions and

food from the oral cavity, the nose and throat

region and the bronchial system;

• deflating vacuum matresses and inflatable splints.

ACCUVAC Basic:

• can when used by a skilled operator eliminate

obstruction of the respiratory tract and hence the

risk of respiratory failure;

• cuts energy consumption by reducing power

output on reaching the necessary vacuum;

• can optionally be powered by a rechargeable

internal power pack;

• or by an external DC source supplying 12.0 -

13.8 V;

• is also suitable for use in wards.

ACCUVAC Basic must not be used:

• in medical rooms where potential equalization is

necessary (e.g. heart surgery);

• in explosion-risk areas.

Description 3

1.2 Function

An electrically operated diaphragm pump generates

the vacuum necessary for aspiration.

Use the vacuum control 2to set the desired vacuum,

which is continuously variable between –0.05 bar

and –0.8 bar. You can read off the set value on the

pressure gage 1.

The aspirated material passes via the aspiration tube

19 into the disposable collection canister 7.

Disposable collection canister

The disposable collection canister 7consists of the col-

lection canister 24 itself, the disposable collection bag

21, the aspiration tube with fingertip 19, the interme-

diate tube 20, the T-piece 23 and the vacuum tube 22.

The disposable collection canister 7is inserted in the

holder 25 screwed on the side of the motor unit 8.

The vacuum tube 22 of the disposable canister 24 is

pushed onto the suction port 14 of the motor unit 8.

The aspirated material passes through the aspiration

tube 19 into the disposable collection bag 21. The dis-

posable collection bag is intended for once-only use.

When it is full, you can remove it from the collection

canister 24 and dispose of it complete with contents.

An overflow valve filter is integrated in the disposable

collection bag 21. This prevents secretions and liquid

from finding their way into the motor unit 8and passing

into the environment via the muffler 13.

-1,0

-0,8

-0,6 -0,4

-0,2

4Description

Power supply

Power for operating the appliance and charging the

power pack can be drawn:

• from the built-in power pack 17.

• from a 12-volt electrical cable system, using the

connecting cable WM 10650 which is available

as an accessory.

• from the mains and charger unit WM 2645

which is available as an accessory.

Important The AC adapter/charger plug 11 supplied with the

appliance is only designed for charging the power

pack with the appliance switched off. It must not be

used to operate the appliance itself, as this will over-

load it and cause it to overheat.

The voltage indicator 3shows the charge status of the

power pack.

Charging of the power pack starts automatically as

soon as the appliance is switched off and connected

to an external power supply (see “10. Technical Data”

on page 37).

Safety 5

2. Safety

2.1 Special symbols on the appliance

2.2 Safety rules

For your own safety and the safety of your patients,

and in accordance with the requirements of the

93/42/EEC, we would draw your attention to the

following points:

•Please read these operating instructions carefully.

They belong to the appliance and must be kept

available at all times.

• Before working with ACCUVAC Basic, you must

understand how to use it.

• Be sure to observe these operating instructions

when working with ACCUVAC Basic.

Rating plate ACCUVAC Basic

Do not dispose of the unit in domestic

waste!

Protection class BF

Protection class II, safety insulation

Year of manufacture

6Safety

•To avoid infection or contamination with bacteria

please read section “5. Hygienic preparation” on

page 19.

• ACCUVAC Basic may only be used by trained

staff instructed in aspiration techniques. Incorrect

use can cause serious bodily harm.

•ACCUVAC Basic must be used for the designated

purpose only (see “1.1 Purpose” on page 2).

• Maintenance operations such as inspection and

repair work must be performed by expert person-

nel or by the manufacturer Weinmann.

• Malfunctions and a lack of biocompatibility may

result if third-party articles are used. Please bear in

mind that in these cases any warranty entitlement

and liability shall lapse where the accessories rec-

ommended in the instructions for use or original

spare parts are not utilised.

•During the aspiration process, take particular care

not to cause injuries to the patient’s mouth or

throat, e.g. to mucous membrane.

The suction can be interrupted by briefly opening

the fingertip, for example if the nozzle becomes

firmly attached to the skin.

• Ensure sterile conditions during bronchial aspira-

tion, and always use sterile catheters.

Important! • The disposal of liquids such as blood and secre-

tions and any items contaminated with such liquids

should be carried out according to the national

guidelines for hygiene.

• The ACCUVAC Basic should only be operated in

the upright position, in order to prevent liquid from

wetting the overflow valve filter integrated in the

disposable collection bag 21. If this happens, the

overflow valve filter becomes impermeable to air

and the disposable collection bag 21 has to be

changed.
