WeBoost Drive Reach Fleet Manuel utilisateur

Installation Guide

PROFESSIONAL VEHICLE CELL SIGNAL BOOSTER KIT

DRIVE REACH FLEET

A WILSON ELECTRONICS BRAND

NEED HELP?

855.846.2654

SignalBooster.com

______

Index

Package Contents

STEP 1-A: Drill Cable Entry Hole Into Your Vehicle

STEP 1-B: Insert & Route Cable

STEP 1-C: Mount NMO Outside Antenna

STEP 2: Mount 4G In-Vehicle Antenna

STEP 3: Wiring The Power Supply To The Vehicle Battery

STEP 4: Connect Coax Cables To Booster

STEP 5: Connect Power Supply To Booster

Light Patterns

Troubleshooting

Safety Guidelines

Speciﬁcations

Warranty

Back Cover

DRIVE REACH FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 1

________

Package

Contents

Drive Reach

Booster

& Bracket

Outside NMO

Antenna +

Connector

Mounting Cable

4G In-Vehicle

Antenna

Power

Supply

Optional Antenna

Extension Cable

Protective Tape

For Installation

O-Ring Lubricant

Packet

2PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE REACH FLEET

______

Step 1-A: Drill Cable Entry

Hole Into Your Vehicle

Identify a location for NMO Outside Antenna on the

top of your vehicle that is:

 Near the center of the roof

 At least 12 inches away from any other antennas

 At least 6 inches away from any windows

(for best performance install on top of vehicle)

Do a ‘soft install’ before drilling the hole for the

cable entry.

 Set up the system by routing the cable through

an open door or window, completing the setup

instructions, verifying the system works as desired,

and then drilling the hole.

6 in. away from windows

(including sunroofs)

Good NMO Outside

Antenna Placement

DRIVE REACH FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 3

Place the protective tape on the

vehicle in the desired location.

Using a 3/4” hole saw, drill a

hole in the center of the

protective tape.

______

(STEP 1-A cont.)

After completing the ‘soft install’ and identifying NMO

Outside Antenna location:

protective tape

vehicle surface

protective tape

3/4” bit

4PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE REACH FLEET

apply silicone grease

After hole has been drilled, insert NMO Mounting Cable

through (connector end ﬁrst) and remove collar.

Position threads of the cable mount above vehicle surface.

Apply included silicone grease to the o-ring on the collar

then screw the collar to the base mount. Ensure the mount is

centered in the hole and tighten with wrench.

screw collar

to base mount

For a professional installation, we recommend routing the cable

under the headliner and down through the side trim panel to

the desired booster location on the ﬂoor of the vehicle.

side trim panel

headliner

______

Step 1-B: Insert & Route Cable

remove

collar

insert through hole

DRIVE REACH FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 5

Before attaching the antenna, apply a thin layer of silicone

grease only onto the threads of the NMO mount and onto

the o-ring on the antenna. Screw the antenna onto the NMO

mount and hand tighten into place.

hand tighten and make sure

gasket is touching vehicle

surface

screw on

NMO Antenna

______

Step 1-C: Mount NMO

Outside Antenna

apply silicone grease

NOTE: DO NOT apply silicone grease to the antenna pin contact surface.

6PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE REACH FLEET

The location should be at least 18 inches but no more than 36

inches from where the cellular device will be used. Use the

Velcro® adhesive strip or the 2-sided adhesive strip provided

and attach to the side of the antenna labeled “MOUNTING

SIDE”. Then mount to the desired location.

Identify a place to mount the 4G In-Vehicle Antenna, either

on the side of the seat or on the dash and mount.

______

Step 2: Mount 4G In-Vehicle

Antenna

In-Vehicle Antenna

Dash Mount

Velcro® strip

In-Vehicle Antenna

Seat Mount

DRIVE REACH FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 7

Before connecting the power supply, disconnect the vehicle battery

leads to avoid any electrical shocks during installation.

Locate a place where cables are already running through the ﬁrewall

(rear wall of engine bay) to the inside of the cabin.

Locate the same ﬁrewall hole from inside of the vehicle cabin.

Route the power cables of the power supply from the inside of the

vehicle cabin out through ﬁrewall hole.

Note: The cables must be routed inside to outside since the power

supply brick won’t ﬁt through the ﬁrewall holes. The power supply

brick should remain inside the vehicle cabin.

Connect the positive lead of the power supply (lead with red tape)

to the disconnected positive (+) lead of the battery (not the positive

terminal on the battery itself).

Connect the negative lead of the power supply (lead without tape)

to the disconnected negative (-) lead of the battery (not the negative

terminal on the battery itself).

Connect the positive (+) lead back to the vehicle battery.

Connect the negative (-) lead back to the vehicle battery.

Use steps below as a draft/template of the general install of

the power supply.

______

Step 3: Wiring The Power

Supply To The Vehicle Battery

NOTE: Having the power supply directly connected to the battery may

drain the battery’s life. Please review the vehicle’s owner’s manual for more

information. Adding a “fuse tap” may be another solution. A “fuse tap” is an

electrical part that functions as a power splitter and is meant to be installed

in the car’s fuse box, making the amp shut o when the vehicle’s ignition

switch is turned o.

8PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE REACH FLEET

______

Step 4: Connect Coax Cables

To Booster

Connect the cable from the Outside NMO Antenna to the port

labeled “Outside Antenna” on the booster.

Connect the cable from the 4G In-Vehicle Antenna to the port

labeled “Inside Antenna” on the booster.

from Outside NMO Antenna

from Inside Antenna

NOTE: Bracket can be used to fasten booster in a speciﬁc location if desired.

The Velcro® strip on the bottom of the bracket can also be used to keep

booster from sliding around.

bracket

Drive Reach
