Webasto 533 Manuel utilisateur

Vorwahluhr 1533

Digital timer 1533

Horloge de programmation 1533

Timer programmabile 1533

Programador 1533

Schakelklok 1533

Timer 1533

Tidur 1533

Tidsur 1533

Ajastin 1533

Programator zegarowy 1533

Программируемый таймер 1533

定时器

定时器定时器

定时器

1533

1301138F04_BA_VWU_1533.BOOK Page 1 Monday, October 1, 2012 11:23 AM

itte ausklappen!

Unfold!

Veuillez rabattre S.V.P. !

Aprire la pagina!

¡Desplegar, por favor!

Svp. uitvouwen!

Fold ud!

Vik ut!

rett ut!

Avaa!

ProszęrozłoŜyć!

Разверните!

请打开

请打开请打开

请打开！

！！

！

1301138F04_BA_VWU_1533.BOOK Page 2 Monday, October 1, 2012 11:23 AM

1301138F04_BA_VWU_1533.BOOK Page 3 Monday, October 1, 2012 11:23 AM

Legend 14

General Information 15

Operation 17

Switching on 18

Switching off 18

Setting the time 19

Checking the time 19

Setting Mode 19

Program start of heating or ventilation 21

Deactivate preset time 21

Select and activate preset time 22

Setting Operating Time 23

Set remaining time 23

1301138F04_BA_VWU_1533.BOOK Page 13 Monday, October 1, 2012 11:23 AM

Operating and Maintenance Instructions

Digital timer 1533 with 3 time settings



1 Time / remaining time

2 Ventilation mode indicator

3 Forward (viewing the time)

4 Program selection

Program number indicator

6 Instant heat

7 Symbol for setting / viewing the time

8 Reverse (viewing the time)

9 Heating operation indicator

1301138F04_BA_VWU_1533.BOOK Page 14 Monday, October 1, 2012 11:23 AM

General Information

Dear Webasto customer!

We are delighted that you have selected this Webasto product.

We assume that the workshop / service partner that carried out the installation

explained to you the operation and principle of functioning of your digital timer

1 33 to your complete satisfaction.

With these operating and maintenance instructions we would like to provide you

with an overview of the use of the digital timer 1 33.

The digital timer 1 33 complies with the homologation approval in accordance

with the directive 72/24 /EEC (EMC).

1301138F04_BA_VWU_1533.BOOK Page 15 Monday, October 1, 2012 11:23 AM

The heater must not be operated:

•In filling stations and tank farms.

•At locations at which highly flammable gases or

dusts can form, and at locations at which highly

flammable liquids or solid materials are stored (e.g.

near fuel, coal and wood dust, grain warehouses,

dry grass and leaves, cardboard , paper, etc.).

•In enclosed rooms (e.g. garages), not even via the

timer or Telestart.

Danger of explosion

and suffocation!

1301138F04_BA_VWU_1533.BOOK Page 16 Monday, October 1, 2012 11:23 AM

Operation

The time for starting heating operation can be preset precisely anywhere between

"1 minute" and "24 hours". Three starts can be programmed, but only one can

be activated.

The heating time can be programmed as desired between 10 minutes and

60 minutes.

NOTE:

Take into account summer time or winter time!

Operation of the timer is designed so that the symbols flash rapidly in setting

mode. If no button is pressed for seconds, the displayed time will be saved.

The display changes at high speed when the buttons or are pressed for

more than 2 seconds.

1301138F04_BA_VWU_1533.BOOK Page 17 Monday, October 1, 2012 11:23 AM

Switching on

Manually: by pressing the button "Instant heat" .

The heating time and the symbol for heating operation are displayed.

The heating time disappears after 10 seconds.

Automatically: upon reaching the preset starting time for heating or ventilation.

The program number and the symbol for heating or ventilation are

displayed.

Switching off

Manually: by pressing the button "Instant heat" .

Automatically: via the programmed end time.

The display field goes out when the heating time expires.

1301138F04_BA_VWU_1533.BOOK Page 18 Monday, October 1, 2012 11:23 AM

Setting the time

This function is not available when heating or ventilation mode is active!

Press and hold the button . Press the button "Forward" or "Reverse"

as well.

Release the button.

The time of day is displayed and the clock symbol flashes.

Set the time via the button "Forward" or "Reverse" .

The set time is saved when the display goes out and by pressing the button.

Checking the time

Press the button "Forward" or "Reverse" .

The remaining time is displayed if heating or ventilation mode is active.

1301138F04_BA_VWU_1533.BOOK Page 19 Monday, October 1, 2012 11:23 AM
