WE-EF FLC301 Manuel utilisateur
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
FLC301 Wall bracket
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.
1
FLC301 Wall bracket
Projector
IP66, IK08. Class I. Ta= 40°C
Weight kg
for FLC301 Wall bracket 2.3
ø 6
117
800
ø 58
100
ø 135
2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.
3
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
The installation on site must comply with local and/or
national health and safety regulations.
4
Installation Procedure
1) Switch off mains electrical supply.
5HPRYHPRXQWLQJƃDQJHAby loosening
screw B Detach terminal connector C.
'HWHUPLQHSRVLWLRQIRUƂ[LQJVFUHZVD. Drill
relevant holes Eand insert wall plugs F.
Warning: Ensure not to damage any
electrical cable, water pipe or other items
drilling holes.
L
N
L
N
C
B
A
N
L
F
D
E
2) Check that rating shown on luminaire label
conforms with mains electrical supply.
(example)
FLC301-LED 220-240V/50-60 Hz
145-XXXX SOE XXXXXXX
LED 3000K 12W item no. XXX
07/20 IP66
5
7RƂ[PRXQWLQJƃDQJHA, insert and thighten
screws D.
5) Feed mains supply cable G(and second cable
Hfor through wiring, if required) through the
pressure screw IZKLOHVHWWLQJPRXQWLQJƃDQJH
Ain position.
7) Connect mains supply cable Gleads to
respective terminals of socket K:
a) ON-OFF (L = Phase, N = Neutral,
= Earthing)
b) ON/OFF 24VDC (+ = positive pole,
– = negative pole)
c) DALI 24VDC (+ = positive pole,
– = negative pole,
DA/DA = DALI control line,
= Earthing)
8) Ensure that all surfaces are clean and dry.
3RVLWLRQOXPLQDLUHRYHUPRXQWLQJƃDQJHA.
and attach terminal connector C. Tighten
screw B.
LN
LN
A
G
I H
LN
LN
G
K
L
N
L
N
C
B
A
''Operation with 24VDC is only permitted with a
SELV power supply suited for Class III appliances.''
6
9) Loosen screws Mand Nslightly.
Aim luminaire in desired direction, retighten
screws Mand N.
10)For accessory Linear Spread Lens IO-180 or
glare shield ES-FLC301: Turn frame Oto set
desired orientation of light or shielding.
O
N
M
www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel +49 5194 909 0
Fax +49 5194 909 299
info.germany@we-ef.com
WE-EF LUMIERE
France
Tel +33 4 74 99 14 44
Fax +33 4 74 99 14 40
info.france@we-ef.com
WE-EF HELVETICA
Switzerland
Tel +41 22 752 49 94
Fax +41 22 752 49 74
info.switzerland@we-ef.com
WE-EF LIGHTING
Thailand
Tel +66 2 738 9610
Fax +66 2 175 2174
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel +61 3 8587 0444
Fax +61 3 8587 0499
info.australia@we-ef.com
WE-EF LIGHTING
United States of America
Tel +1 724 742 0030
Fax +1 724 742 0035
info.usa@we-ef.com
TO9272W0721 © WE-EF 2021
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.
