Waterpik WF-20 Series Manuel utilisateur

Waterpik®Water Flosser

WF-20 | 21 Series

www.waterpik.com

Limpiador dental Waterpik®

WF-20 | 21 Serie

IMPORTANT SAFEGUARDS

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USING.

• This product is for household use.

When using electrical products, especially when children are present,

basic safety precautions should always be followed, including

the following:

DANGER:

To reduce the risk of electrocution:

• Do not place or store product where it can fall or be pulled into a tub

or sink.

• Do not handle the user supplied USB wall charger with wet hands.

• Do not place or drop the device or user supplied USB wall charger

into water or other liquid.

• Check the charging cord and user supplied USB wall charger for

damage before the rst use and during the life of the product.

WARNING:

To reduce the risk of burns, electrocution, ire,

or injury to persons:

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety.

• Children should be supervised to ensure that they do not play with

the appliance.

• Use this product only as indicated in these instructions or as

recommended by your dental professional.

• Only use tips and accessories recommended by Water Pik, Inc.

• Do not use this product if it has a damaged cord or plug, if it is not

working properly, if it has been dropped or damaged, or dropped

into any liquid. Contact Water Pik, Inc. at 1-800-525-2774 or visit

www.waterpik.com.

• Keep the charging cord and user supplied USB wall charger away

from heated surfaces.

• Never drop or insert any object into any opening or hose.

ENGLISH

ORIGINAL INSTRUCTIONS

• Do not use outdoors or operate where aerosol (spray) products are

being used or where oxygen is being administered.

• Do not expose the battery or appliance to excessive temperatures.

• A user supplied USB-A wall charger (power adapter), safety certied

(IPX4, Class II) and with a rated output of 5.0 VDC, 1.0 A Max

must be used to chart this device.

• Do not plug this device into a voltage system that is dierent from

the voltage system specied on the device or charger.

• Unplug USB wall charger when not in use.

• Do not use the Water Flosser for more than ve minutes in each two

hour period.

• Do not direct water under the tongue, into the ear, nose or other

delicate areas. This product is capable of producing pressures that

may cause serious damage in these areas.

• Do not direct water into the nose or ear. The potentially deadly

amoeba, Naegleria fowleri, may be present in some tap water or

unchlorinated well water and may be fatal if directed into the nose

or ear.

• If your physician advises you to receive antibiotic premedication

before dental procedures, you should consult your dental

professional before using this product or any other oral hygiene aid.

• Fill reservoir with warm water or other dental professional

recommended solutions only.

• Do not use iodine, saline (salt solution), or water insoluble

concentrated essential oils in this product. Use of these can reduce

performance and will shorten the life of the product.

• If the Pik Pocket™ tip (not included in all models) separates from the

sha for any reason, discard tip and sha and replace with a new

Pik Pocket™ tip.

• Remove any oral jewelry prior to use of this product.

• Do not use if you have an open wound on your tongue or in your

mouth.

• There are no consumer serviceable electrical parts in this product

and it does not require maintenance.

• Remove charging cord from the unit and replace charging port cover

prior to lling the reservoir.

• If the supply cord is damaged, it must be replaced by a special cord

or assembly available from the manufacturer or its service agent.

SAVE THESE

INSTRUCTIONS

TABLE OF CONTENTS

Product Description 5

Getting Started 6

Cleaning and Troubleshooting Your Waterpik® Water Flosser 9

Battery Care, Disposal/Recycling, Battery Removal 10

Limited Two Year Warranty 11

SYMBOLS

The following symbols may appear on your product and/or packaging. Some of these symbols may not be relevant in your region and are listed for information purposes only.

Symbol Deinition Symbol Deinition Symbol Deinition Symbol Deinition

Refer to instruction manual Detachable Power Supply Do not use this device in a shower, bathtub

and do not immerse in any liquid. Regulatory Compliance Mark

Manufacturer Direct Current (DC) Voltage Authorized Representative in the European

Community

Separate collection for waste electrical

and electronic equipment.

IPX7 or IPX4 Ingress Protection Code Alternating Current (AC) Voltage CE marking of conformity

IEC Class II Equipment Do not immerse this device in any liquid. UK Conformity Assessed

REP

ENGLISH

PRODUCT DESCRIPTION

USB Charging Cable

20030405-2 White

WF-20 WF-21

NOT ALL TIPS INCLUDED IN ALL MODELS

TIPS

A. Orthodontic Tip*

- Braces/General use

B. Pik Pocket™ Tip*

- Periodontal Pockets/Furcations

C. Plaque Seeker™Tip*

- Implants/Crowns/Bridges/

Retainers/General use

C D

*Replace Every 3 months **Replace Every 6 months

Replacement tips/attachments may be purchased online at

www.waterpik.com, or by phone from Water Pik, Inc. at 1-800-525-2774

(USA). To nd detailed information about tips, other accessories, and product

usage please visit our website at www.waterpik.com.

D. Toothbrush Tip*

- General use

E. Classic Jet Tip**

- General use

F. Tongue Cleaner**

- Fresher breath

G. Travel Plug

- Keeps excess water from

draining out while traveling

1. Power handle

2. Power/pressure switch

3. Battery charge indicator

4. Charge port/cover

5. Tip

6. Tip eject button

7. Reservoir ll door

8. Reservoir

Charging Unit Prior to First Use

Connect the USB charging cable to the unit (USB-C) and then to the USB wall charger (USB-A).

Then plug the USB wall charger into the power outlet and charge unit for approximately 4 hours.

Note: Refer to the IMPORTANT SAFEGUARDS section for required USB wall charger specications.

Always ensure USB plugs and USB ports are clean and dry before connecting.

LED will glow as it charges. LED stays lit when fully charged until USB cable is unplugged from the device. LED blinks 8 times once you

are nished ossing and if the battery is below 30%.

NOTE: Make sure unit is dry before opening weathercap and connecting the charger.

Replace the weathercap aer charging and ensure it’s fully seated

(ush with the outside surface of the handle).

Filling the Reservoir

Before lling, disconnect charging cable and replace charging port cover.

Li ip top on reservoir and ll with lukewarm water.

Inserting and Removing Tips

Insert tip into the center of the knob at the top of the Water Flosser handle. Press rmly until the tip clicks into place. To remove the tip

from the handle, press the tip eject button and pull tip from the handle.

CAUTION: Do not press tip eject button while unit is running.

GETTING STARTED

Eject

Insert

Fill

USB wall charger is not

standard accessory

with this

appliance.

ENGLISH

Adjusting the Pressure Setting

You can adjust the pressure setting on your Water Flosser by simply sliding the pressure/power switch on the handle.

Slide power switch up 1 click for Low (l) pressure and 2 clicks for High (ll) pressure.

Start with the lowest setting and increase to your liking.

Recommended Technique

Lean low over sink and place tip in mouth. Aim the tip toward gumline, and turn the unit ON (I).

For best results, start with the back teeth and work toward the front teeth. Glide tip along gumline and pause briey between teeth.

Continue until you have cleaned the inside and outside of both the upper and lower teeth.

Direct the jet stream at a 90-degree angle to your gumline. Slightly close lips to avoid splashing but allow water to ow freely from

mouth into the sink. Keep unit upright during use for best results.

When Finished

Turn the unit OFF (O). Empty any liquid le in the reservoir.

If desired, the reservoir may be removed from the power handle by simply pulling down on the reservoir to remove.

High

Low

Off

Remove

NOTE: NOT ALL TIPS INCLUDED WITH ALL MODELS.

TIP USAGE

Pik Pocket™Tip

The Pik Pocket™ tip is specically designed to deliver water or anti-bacterial solutions deep into periodontal pockets.

To use the Pik Pocket™ tip, set the unit to the lowest pressure setting. Place the so tip against a tooth at a 45-degree angle and

gently place the tip under the gumline, into the pocket.

Tongue Cleaner Tip

Set to lowest pressure setting, place tip in the center/middle of your tongue about half way back. Pull forward with light pressure.

Increase pressure as you prefer.

Orthodontic Tip

To use the orthodontic tip, gently glide tip along gumline, pausing briey to lightly brush area between teeth and all around orthodontic

bracket, before proceeding to the next tooth.

Toothbrush Tip

Place the toothbrush tip in mouth with the brush head on the tooth at the gumline. The toothbrush tip can be used with or without

toothpaste. Using a light pressure (bristles should not bend) massage the brush back and forth with very short strokes – much like you

would with a manual toothbrush.

Plaque Seeker™Tip

To use the Plaque Seeker™ tip, place the tip close to the teeth so that the bristles are gently touching the teeth. Gently glide tip along

gumline, pausing briey between teeth to gently brush and allow the water to ow between the teeth.

ENGLISH

CLEANING AND TROUBLESHOOTING YOUR WATERPIK® WATER FLOSSER

Using Mouthwash and Other Solutions

Your Waterpik® Water Flosser can be used to deliver mouthwash and antibacterial solutions. For ease of adding other solutions remove

the reservoir (see “When Finished” section) and add from top opening on reservoir. If you are adding additional water you may replace

the reservoir and ll reservoir fully with the ll door. Aer using any special solution, rinse unit to prevent clogging by partially lling

reservoir with warm water and running unit with tip pointed into sink until unit is empty.

Cleaning

Never immerse unit in water. Before cleaning, unplug from the electrical outlet. Clean the product when necessary by using a so cloth

and mild non-abrasive cleanser to wipe exterior.

The water reservoir is removable for easy cleaning and is top rack dishwasher safe.

It is recommended that the reservoir is removed and cleaned weekly.

Removing Hard Water Deposits / General Cleaning

Hard water deposits may build up in your unit, depending on the mineral content of your water. If le unattended, it can hinder

performance. Cleaning internal parts: add 1 tablespoon of white vinegar to a full reservoir of warm water. Point the handle and tip

into sink. Turn unit ON and run until reservoir is empty. Rinse by repeating with a full reservoir of clean warm water.

This process should be done every 1 to 3 months to ensure optimal performance.

Remove

Battery Care

If the Water Flosser is to be stored for an extended period of time (six months or more), be sure to fully charge it prior to storage.

Do not expose the battery or appliance to excessive temperatures.

Disposal/Recycling

This product contains a rechargeable lithium ion battery. The battery is not replaceable. At the end of product life, do not dispose

of in household garbage or recycling bins. Please recycle at your nearest recycling center or take to hazardous waste collection point to

comply with local and state regulations.

Please contact your local waste administrative department for any questions.

Note: The rechargeable battery is not replaceable, remove only at end of product life. This process is not reversible and

voids the product warranty.

Battery Removal

To remove the rechargeable battery for recycling, please discharge the battery fully before removing.

Observe basic safety precautions when you follow the procedure below. Be sure to protect your eyes, hands, ngers and surface on

which you work.

1. Remove reservoir and wrap unit in towel. Hit with hammer until lower cover comes o.

2. Pull out battery, cut wires. Cut battery wires one at a time.

Note: Do not cut both battery wires at the same time.

BATTERY CARE, DISPOSALRECYCLING, BATTERY REMOVAL

Remove

Autres manuels pour WF-20 Series

Table des matières

Autres manuels Waterpik Accessoires

Waterpik

Waterpik WP-310A Manuel utilisateur

Waterpik

Waterpik water flosser Manuel utilisateur

Waterpik

Waterpik Water Flosser WF-10 Manuel utilisateur

Waterpik

Waterpik Sidekick WF-04 Manuel utilisateur

Waterpik

Waterpik WF-09 Manuel utilisateur

Waterpik

Waterpik Water Flosser WF-02 Manuel utilisateur

Waterpik

Waterpik Water Flosser WP-860 Manuel utilisateur

Waterpik

Waterpik WP-100 Series Manuel utilisateur

Waterpik

Waterpik WP-250 Manuel utilisateur

Waterpik

Waterpik WP-100 Series Manuel utilisateur

Waterpik

Waterpik WF-10 Series Manuel utilisateur

Waterpik

Waterpik WP-200 Series Manuel utilisateur

Waterpik

Waterpik Water Flosser WF-06 Manuel utilisateur

Waterpik

Waterpik WP-120 Manuel utilisateur

Waterpik

Waterpik WP-360 Manuel utilisateur

Waterpik

Waterpik waterflosser WP-860 Manuel utilisateur

Waterpik

Waterpik WF 02A Manuel utilisateur

Waterpik

Waterpik WP-112 Manuel utilisateur

Waterpik

Waterpik WP-250 Manuel utilisateur

Waterpik

Waterpik WP-100 Series Manuel utilisateur

Waterpik

Waterpik waterflosser WP-861 Manuel utilisateur

Waterpik

Waterpik Models WF-11 Manuel utilisateur

Waterpik

Waterpik Water Flosser WP-560 Manuel utilisateur

Waterpik

Waterpik Waterflosser WF-02 Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
