ZWCFS100 Wireless Leak & Temperature Sensor

This product will provide you with peace of mind and the protection you expect. Leaking pipes, corroded

water heaters, ﬁxtures in bathrooms and laundry rooms, or refrigerator drip pans can all cause water damage.

The ZWCFS100 is a Z-Wave® enabled device that will send a water alert on your Z-Wave® network.

Devices performing other functions and from other manufacturers can also be part of your

Z-Wave® network and can act as repeaters to extend your network range.

User Manual

The proven leader in household leak protection: WaterCop® is there when you’re not.

Program switch

for inclusions

or exclusion

Products that speak Z-Wave

work together better.TM

Functionality

The ZWCFS100 senses when water is detected and will also

provide a Z-Wave® alarm signal when the temperature drops

below a low temperature setpoint or rises above a high

temperature setpoint. The ZWCFS100 functionality is based

on wireless (RF) transmissions. Any wireless transmission can

be subject to RF interference and, although unlikely, this

interference may cause the device to not operate as intended.

The ZWCFS100 must not be used in life support and/or safety

applications.

Information provided in this manual is for your convenience

and may be superseded by updates. The speciﬁcations and

this manual are subject to change without notice. It is your

responsibility to ensure that the ZWCFS100 meets your

speciﬁcations.

Functionality

POWER: Two AA alkaline batteries

BATTERY LIFE: Calculated to be 1 to 2 years with no

alarms and default Z-Wave® network

settings

FREQUENCY RANGE: 908.4MHz (US); 868.4MHz (EU)

DISTANCE RANGE: Max. 100 ft line of sight in unobstructed

environment

PRODUCT SIZE LxWxD: 3" (76 mm) x 2.1" (53 mm) x 1.1" (30 mm)

PRODUCT WEIGHT: 0.24 lb (109 g)

OPERATING TEMP: -10°C (14F) to +70°C (158F)

REPORTED TEMP: Reported temperature is at the device

and has a +/- 2°C accuracy

SYSTEM REQUIREMENT: Any Z-Wave™ enabled network

and controller

Using the ZWCFS100 in a Z-Wave® Network

•The switch is used for including or excluding the ZWCFS100 in

a Z-Wave® network

•Refer to your controller’s User Manual for speciﬁc details on

network inclusions, exclusion, and association

Inclusion in (adding to) a network:

1. Set up the inclusion mode at the controller

2. Inclusions and exclusion are always done at normal transmit

power mode.

Exclusion from (removing from) a network:

Set up the exclusion mode at the controller

Associations:

Once in a network, a controller can be used to associate the

ZWCFS100 with other devices in the Z-Wave® network, such as a

light or another remote audible alarm. Refer to your controller’s

documentation on how to associate ZWCFS100 with another

device in your network. The ZWCFS100 supports three

association groups with a maximum of 5 devices in each group.

Basic Set commands are sent at 30-minute intervals to the

associated groups while alarms are active.

•A Basic Set Command is sent to the associated nodes, if any,

assigned to Group1 to indicate that EITHER a Water Alarm OR

Heat Alarm (under or over temperature) is active.

•A Basic Set Command with value = 0xFF is sent to the

associated nodes, if any, assigned to Group2 to indicate that

a Water Alarm is active. When the Water Alarm is cleared by

drying the contacts, one additional report with value = 0x00

is sent.

•A Basic Set Command is sent to the associated nodes, if any,

assigned to Group3 to indicate that a Temperature Alarm (over

or under temperature) is active. When the Temperature Alarm

is cleared due to temperature change, one additional report

with value = 0x00 is sent.

Node Info / Keep-Alive: While not in a network, the ZWCFS100

will send the Z-Wave® Node information frame when the

switch is brieﬂy pressed. This is primarily used for inclusion

as described above. The node information frame will also be

sent while in network when the switch is pressed and held for

2 seconds. In either case, the ZWCFS100 will “stay awake”

for approximately 30 seconds after this to allow time for

conﬁguration commands from the controller.

Wakeup Notiﬁcation: The ZWCFS100 will wakeup and send a

notiﬁcation every 4 hours (default) to allow a controller to query

and update the status of the device. A brief switch press while in

network will also cause the ZWCFS100 to wakeup and send a

notiﬁcation. The device stays awake for 5 seconds during this

time or longer if communicating with the controller.

Choosing a Mounting Location

The ZWCFS100 is suitable for use in dry, interior locations only.

Avoid placing the device close to a metal frame, or other metal

enclosures that may aect RF range. Place the device so that

any leaks that may occur will not drip directly on the device.

Recommended ZWCFS100 uses: under sink, next to sump

pumps, water heaters, laundry room, bathroom ﬂoor, storage

area, garage, utility sink, vacation/recreation homes, boats, etc.

During an Alarm

If water is detected at the monitoring location, the unit will

sound an 82 decibel, audible alarm and will send an alert

message to the Z- Wave® network (if included in the network

already). Pressing and holding the button for 2 seconds will

clear the Water Alarm. If freezing conditions are detected, no

audible alarm will sound but an alert message is sent to the

Z-Wave® network (if included in the network). The type of alert

message depends on how the ZWCFS100 is conﬁgured. If as-

sociations are conﬁgured, Basic Set messages will be sent as

described above under Associations. If Water or Heat Alarms

have been conﬁgured (via Alarm Command Class V2 Set com-

mands), then the ZWCFS100 will send alert messages to the

Node ID that conﬁgured the alarm. Association alert messages

and Alarm alert messages may both be conﬁgured and sent.

Drying the sensor contacts will clear the Water Alarm. If an over/

under Temperature Alarm occurred and the Temperature Alarm

conditions are no longer present, an “alarm clear” message is

also sent to the Z-Wave® network (if included in the network).

Also, depending on your Z-Wave® controller, it is possible to

receive a remote alert. For example, with some gateway

controllers, you can receive an email or cell phone text

message when an alarm is activated. Depending on your

speciﬁc controller’s capabilities you will be able to remotely

check the status of any ZWCFS100 in your network.

Testing the ZWCFS100

Moisten a paper towel and place over both of the small metal

pads on the water sensor until you hear the audible alarm

sound. The water alarm may take up to 4 or 5 seconds before it

sounds. If the alarm fails to sound, your battery may be old or

dead or incorrectly installed, the sensor may not be moist

enough, or the water sensor may be damaged. If you do hear

the audible alarm, remove the moistened paper towel, clean the

small metal pads of any water residue, and hold the button for 2

seconds to clear the alarm. You can then add your water alarm

to any Z-Wave® enabled network and controller. Examples of

Z-Wave® controllers can be found on the WaterCop website

(watercop.com).

Battery / Low Battery

The ZWCFS100 will send an alert on the Z-Wave® network at

regular intervals when it detects a low battery condition. In

addition, it will periodically sound an audible “chirp”. Your

controller may be able to be conﬁgured to monitor the device’s

wake up notiﬁcations. If these stop, then this might also be an

indication that the battery has died or that transmissions from

the ZWCFS100 are no longer being received. After a water leak,

please ensure that there is no moisture in the device and

around the battery. Do not install batteries that appear

damaged or unsealed. When replacing batteries, the water seal

may be broken around the screws. After screwing the parts

back together, the use of some sealant, such as silicone caulk,

around the screws is recommended.

Conﬁguring the ZWCFS100

The high and low temperature setpoints in the ZWCFS100 can

be conﬁgured. The low temperature setpoint must always be set

at least two degrees below the high temperature setpoint. The

low temperature setpoint cannot be set less than -10°C and the

high temperature setpoint cannot be set greater than 70°C. The

temperature setpoints can be conﬁgured via a “smart” controller

after inclusion; details are provided in the technical appendix.

Temperature Reports

If your controller sends the wakeup interval set command, the

controller will also become the Wakeup Master node. The

ZWCFS100 will automatically send temperature reports to this

Wakeup Master node within a half hour of a 1°C change in

temperature.

FCC Compliance Statement

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation. Contains

Transmitter Module FCC ID: XCT-Z3US

FCC Warning (Part 15.21). Changes or modiﬁcations not

expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC Interference Statement (Part 15.105 (b). This equipment has

been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one of the

following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment

and receiver.

•Connect the equipment into an outlet on a circuit dierent from

that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician

for help.

Industry Canada Statement per

Section 4.0 of RSP-100

“IC:” before the certiﬁcation/registration number only signiﬁes

that the Industry Canada technical speciﬁcations were met.

Section 7.1.5 of RSS-GEN. Operation is subject to the following

two conditions: 1) This device may not cause harmful interfer-

ence, and 2) This device must accept any interference received,

including interference that may cause undesired operation.

From section 5.2, RSS-Gen, Issue 2, June 2007

Equipment Labels:

Contains IC: 8156A-Z3X

From section 7.1.1 RSS-Gen, Issue 2, June 2007

a) The host device, as a stand-alone sensor without any

separately certiﬁed modules, complies with all applicable

Radio Standards Speciﬁcations.

b) The host device and all the separately certiﬁed modules

it contains jointly meet the RF exposure compliance

requirements of RSS-102AA, if applicable.

c) The host device complies with the certiﬁcation labeling

requirements of each of the modules it contains.

Europe

The ZWCFS100 module has been certiﬁed for use in European

countries. Test standard: ETSI EN 300 328 V1.7.1 (2006-10)

The Waste Electrical and Electronic Equipment (WEEE) directive

(2002AA/96/EC) was approved by the European Parliament and

the Council of the European Union in 2003. This symbol

indicates that this product contains electrical and electronic

equipment that may include batteries, printed circuit boards,

liquid crystal displays or other components that

may be subject to local disposal regulations at your

location. Please understand these regulations and

dispose of this product in a responsible manner.

Limited Warranty

DynaQuip Controls Corporation, 10 Harris Industrial Park, Saint

Clair, Missouri 63077, warrants its WaterCop electric valve

actuator and electronic sensor and electronic system control

components against defects in material and workmanship for a

period of two (2) years from the date of original shipment.

DynaQuip Controls warrants its WaterCop brass ball valve

mechanical component against defects in material and

workmanship for the life of the component. In the event that

such defects appear within the warranty period, DynaQuip

Controls will, at its option, and upon written notiﬁcation thereof

and substantiation that, the product(s) have been stored,

installed, maintained and operated in accordance with

DynaQuip’s recommendations and standard industry practice,

repair or replace the product without charge. This warranty shall

be invalidated by any abuse, misuse, misapplication, improper

installation, modiﬁcation, or disassembly at any place other than

the point of original manufacture. This shall constitute the

exclusive remedy for breach of warranty, and DynaQuip Controls

shall not be responsible for any incidental or consequential

damages, including, without limitation, damages or other costs

resulting from labor charges, delays, vandalism, negligence,

fouling caused by foreign material, damage from adverse water

conditions, chemicals, weather, or any other circumstances over

which DynaQuip Controls has no control. DYNAQUIP

CONTROLS MAKES NO OTHER WARRANTIES EXPRESS OR

IMPLIED EXCEPT AS PROVIDED BY THIS LIMITED WARRANTY.

The seller does not represent that the product; will prevent any

property loss by sudden or accidental discharge of water from

plumbing systems into living area of a residential dwelling; may

not be compromised or circumvented; or that the product will in

all cases provide adequate warning or protection. Buyer

understands that a properly installed and maintained automatic

water shut-o system may only reduce the risk of a sudden and

accidental water loss event resulting in signiﬁcant water damage

and is not insurance or a guarantee that such will not occur or

that there will be no personal injury or property loss as a result.

CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR

ANY PERSONAL INJURY, PROPERTY DAMAGE OR OTHER

LOSS BASED ON A CLAIM THE PRODUCT FAILED TO TURN

OFF WATER SUPPLY OR GIVE WARNING OF A POTENTIAL

WATER LOSS EVENT. HOWEVER, IF SELLER IS HELD LIABLE,

WHETHER DIRECTLY OR INDIRECTLY, FOR ANY LOSS OR

DAMAGE ARISING UNDER THIS LIMITED WARRANTY OR

OTHERWISE, REGARDLESS OF CAUSE OR ORIGIN, SELLER’S

MAXIMUM LIABILITY SHALL NOT IN ANY CASE EXCEED THE

ORIGINAL PURCHASE PRICE OF THE PRODUCT, WHICH

SHALL BE THE COMPLETE AND EXCLUSIVE REMEDY

AGAINST THE SELLER. This warranty gives you speciﬁc legal

rights, and you may also have other rights which may vary from

state to state. No increase or alteration, written or verbal, to this

warranty is authorized.

DynaQuip Controls Corporation reserves the right to change or

improve the design of any DynaQuip Controls manufactured

product without assuming any obligations to modify product

previously manufactured or sold.

TECHNICAL APPENDIX

MANUFACTURER ID 0x0084

PRODUCT ID varies

PRODUCT TYPE ID 0x0063 (US) 0x0061 (EU)

DEVICE CLASS Generic Type Sensor MultiLevel, Speciﬁc

Type Routing Sensor Multilevel

Made in the USA

COMMAND CLASSES SUPPORTED

(in addition to COMMAND_CLASS_BASIC)

COMMAND_CLASS_ALARM_V2

COMMAND_CLASS_WAKE_UP_V2

COMMAND_CLASS_CONFIGURATION

COMMAND_CLASS_ASSOCIATION

COMMAND_CLASS_BATTERY

COMMAND_CLASS_MANUFACTURER_SPECIFIC

COMMAND_CLASS_SENSOR_MULTILEVEL

COMMAND_CLASS_VERSION

WATER ALARM

•Sampling every 4 seconds

•Z-Wave® transmissions (every approximately 30 minutes while

alarm is active): ‘Basic Set’ with Value = 0xFF sent to associated

nodes in Group 1 and/or Group 2 and/or an Alarm Command

Class V2 Water Leak Report (Event = Water Leak Detected,

Unknown Location, 0x02AA with Alarm Level = 0xFF. What is

sent depends on whether associations are conﬁgured and/or

Water Leak Alarm is enabled with a non-zero destination

•Node ID (see Alarm Factory Default State under OTHER below)

•Audible will sound

•Alarm Command Class V2 Get (Sensor Type = 0x05, Water

Leak) can be used to request water alarm state

•When water alarm is no longer active, sends “Basic Set” with

Value = 0x00 to association nodes as above and/or Alarm

Command Class Water Leak Report (Unknown Event, 0xFE)

with Alarm Level = 0x00

UNDER/OVER-TEMPERATURE / ALARM

•Sampling every 4 seconds with averaging algorithm

•Sensor has an accuracy of approx. +/-2°C. Default alarm trigger

points set at approximately 4°C and 70°C

•Z-Wave® transmissions (every approximately 30 minutes while

alarm is active): “Basic Set” with Value = 0xFF sent to

associated nodes in Group 1 and/or Group 3 and/or Alarm

Command Class V2 Heat Report with Alarm Level = 0xFF and

Event = [Overheat Detected, unknown location, 0x02AA or

Underheat Detected, unknown location, 0x06]. What is sent

depends on whether associations are conﬁgured and/or Heat

Alarm is enabled with a non-zero destination Node ID (see

Alarm Factory Default State under OTHER below).

•Alarm Command Class V2 Get (Sensor Type = 0x04, Heat) can

be used to request heat alarm state

•When temperature alarm is no longer active, sends “Basic Set”

with Value = 0x00 to association nodes as above and/or sends

Alarm Command Class Heat Report (Unknown Event, 0xFE)

with Alarm Level = 0x00

BATTERY STATUS

•Battery level percentage estimated based on number of

Wakeup1 notiﬁcations (see below) since battery insertion

•In addition, battery voltage readings can trip the low

battery state

•Low battery report (Battery Command Class) approximately

every 30 minutes after low battery becomes active, and will

periodically sound an audible “chirp”

WAKEUPS

•Wakeup1: Power saving design wakes up every 4 seconds to

test water and freeze sensor

•Wakeup2: Once every approximately 4 hours (default) device

wakes up to send a notiﬁcation either to a wakeup node or

broadcast. The device stays awake for approximately 5

seconds or while communicating with a controller. Sensors

are not checked during this time.

•The Wakeup node is the node conﬁgured to receive the

Wakeup Notiﬁcation command. This is set in the ZWCFS100

by the Wakeup Interval

•Set command and is typically the Controller node. Only one

value for the wakeup interval, the default interval of 0x003840

(4 hours), can be set.

MULTILEVEL SENSOR

•Multilevel Sensor Report sent with current Temperature

(Degrees C) in response to Multilevel Sensor Get command

•Unsolicited Multilevel Sensor Report sent to Wakeup Node

within 30 minutes of a 1 degree temperature change (if Wakeup

node is set); ﬁltering is applied to avoid ‘oscillating’ report

transmissions and conserve battery life; transmission is

independent of a Wakeup Notiﬁcation

CONFIGURATION

•Parameter 1 sets Low Temperature Trigger Point (degrees

Centigrade, 1 signed byte, Default = 4)

•Parameter 2 sets High Temperature Trigger Point (degrees

Centigrade, 1 signed byte, Default = 70)

KEEP-ALIVE

•Switch activated causes 30 second RF receiver-on time

intended for Controller conﬁguration after network inclusion

•Sensors not checked during Keep-Alive time

OTHER

• Alarm Factory default state = Enabled; unsolicited alarm reports

(underheat, overheat, and water leak) will be sent to Node 0x01

(after inclusion)

• This Node ID can be changed via the Alarm Set Command

(Alarm Command Class V2)

• All Network Inclusions / Exclusions are at normal power levels

• Up to 5 nodes allowed in each association group

• Basic Report sent in response to a Basic Get with value equal

to Multilevel Sensor Type (Temperature, 0x01)

• Built with Z-Wave® SDK 4.51

192341 Rev B

To order or for additional information, visit watercop.com or call 800-545-3636.

Made in the USA

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
