WALL-MOUNTED

FROST WATCHER

MODEL WL41003Y

YOUR SAFETY &

INSTRUCTION MANUAL

PLEASE READ CAREFULLY

CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056

TECHNICAL DATA

Description: Frost Watcher

Model: WL41003

Rated Voltage: 220 - 240V

Frequency: ~ 50Hz

Power consumption: 500W

DOCUMENTATION

We declare that this product conforms to the following product legislation in accordance with the

following directive(s):

2014/30/EU Electromagnetic Compatibility Directive.

2014/35/EU Low Voltage Directive.

2011/65/EU Restriction of Hazardous Substances Directive.

RKW Quality Assurance, United Kingdom

WARRANTY

This product is guaranteed for 12 months from the date of original purchase. If any defect arises due

to faulty materials of workmanship, the faulty products must be returned to the place of purchase.

Refund or replacement is at the discretion of the retailer.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.

• The product must be installed and used in accordance with the instructions contained in this

instruction guide.

• It must be used only for domestic purposes.

• It does not cover wear and tear, damage, misuse or consumable parts.

• RKW has limited liability for incidental or consequential loss or damage.

• This guarantee is only Valid in the UK and Eire Only.

An extended warranty is available for this appliance.

See back page for details.

www.warmlite.co

WIRING SAFETY FOR UK USE ONLY

IMPORTANT

As the colours in the

mains lead of this

appliance may not

correspond with the

coloured markings

identifying the terminals

in your plug, please

proceed as follows:

The wires in the mains lead are coloured in

accordance with the following code:

Blue neutral [N] Brown live [L]

Green/Yellow [EARTH]

Plug Fitting Details (Where Applicable).

The wire coloured blue is the neutral and must

be connected to the terminal marked [N] or

coloured black.

The wire coloured brown is the live wire and

must be connected to the terminal marked [L] or

coloured red.

The wire coloured green/yellow must be

connected to the terminal marked with the letter

[E] or marked .

On no account must either the brown or the blue

wire be connected to the [EARTH] terminal .

Always ensure that the cord grip is fastened

correctly.

The plug must be tted with a fuse of the same

rating already tted and conforming to BS 1362

and be ASTA approved.

If in doubt consult a qualied electrician who will

be pleased to do this for you.

Non-Rewireable Mains Plug

If your appliance is supplied with a non-

rewireable plug tted to the mains lead and

should the fuse need replacing, you must use an

ASTA approved one (conforming to BS 1362 of

the same rating).

If in doubt, consult a qualied electrician who will

be pleased to do this for you.

If you need to remove the plug - disconnect it

from the mains - and then cut it o the mains

lead and immediately dispose of its safely. Never

attempt to reuse the plug or insert it into a

socket outlet as there is a danger of an electric

shock.

WARNING:

This Appliance MUST be Earthed

FUSE

CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056

PRODUCT SAFETY

When using any electrical appliance, basic safety precautions should

always be followed including the following:

• Check that the voltage of the

main circuit corresponds with

the rating of the appliance

before operating.

• IMPORTANT: Only use appliance

when mounted to a wall.

• IMPORTANT: The wall mounting

bracket supplied with the

appliance must be used.

• DO NOT immerse cords, plugs

or any part of the appliance in

water or any other liquid.

• DO NOT leave the appliance

unattended while it is operating.

• Close supervision is necessary

when any appliance is used by

or near children or pets.

• This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

• Children shall not play with the

appliance.

• Cleaning and user maintenance

shall not be made by children

without supervision.

• Switch o at the wall socket

then remove the plug from

the socket when not in use or

before cleaning.

• If the supply cord or appliance

is damaged, stop using the

appliance immediately and seek

advice from the manufacturer

or its service agent or a similarly

qualied person.

• DO NOT let the cord hang over

the edge of a table or counter or

let it come into contact with any

hot surfaces.

• The use of accessory

attachments is not

recommended by the appliance

manufacturer, apart from those

supplied with this product.

• DO NOT pull the plug out by the

cord as this may damage the

plug and/or the cable.

• Do not use this product for

anything other than its intended

use.

• This appliance is for household

use only.

• DO NOT carry the appliance by

the power cord.

• DO NOT use the appliance

outdoors.

www.warmlite.co

• Always ensure that the heater

is only used when mounted on

a wall. Ensure that the heater is

not positioned close to curtains,

furniture or any combustible

materials as this could create a

re hazard.

• Allow a 50cm safe area around

the heater on the top and sides

and a 120cm safe area at the

front of the appliance.

• The heater must not be located

immediately below a mains

socket outlet.

• DO NOT cover the heater as this

may lead to a re risk.

• Do NOT obstruct any of the

openings of the heater.

• DO NOT insert any object

through any openings on the

heater.

• Check from time to time for

accumulated dust.

• DO NOT use the heater in

areas where ammable liquids

are stored or where ammable

fumes may be present.

• DO NOT operate the heater on a

timer, or leave on overnight.

• DO NOT operating the heater on

any oor or surface.

• When not being used, please

unplug the heater from the

mains socket.

• Keep the mains lead away from

the hot body of the heater and

ensure that it is not pulled tight

between the socket and the

heater.

• DO NOT use the heater in the

immediate surroundings of a

bath, a shower, a swimming

pool or similar indoor locations

and do not touch hot surfaces.

• Always unplug the heater and

allow it to cool before moving it

from one location to another.

• DO NOT attempt to dismantle

or repair any part of the heater.

This should only be done by a

qualied service agent.

• In the unlikely event the

appliance develops a fault,

stop using it immediately and

seek advice from the service

department.

HIGH VOLTAGE HOT SURFACE DO NOT COVER

CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056

WHAT’S IN THE BOX

Instruction Manual

Frost Watcher

2 Screws

2 Rawlplugs

Wall Bracket

1. Convection Grills

2. Thermostat

3. Power Indicator

BEFORE YOUR FIRST USE:

1. Remove your appliance from the packaging.

2. Plug the appliance into the mains supply.

3. Safely mount the appliance on a wall, away from curtains, furniture or any combustible

materials.

4. Your appliance is now ready for normal use.

Dispose of the packaging in a responsible manner.

www.warmlite.co

INSTALLING YOUR APPLIANCE

Please maintain the stated minimum distances.

WALL MOUNTING:

1. Unscrew the screws on the side from the

top cover.

2. Install the mounting bracket to the wall,

as shown in the drawing below. Two wall

anchors (6 mm) and mounting screws are

included.

3. Make sure that the device is mounted

level.

4. Hang the heater into the mounting bracket

and screw in the lateral screws back in

again.

5. The device may only be used when

installed on a wall and in an upright

(vertical position)!

6. After connecting the plug with the power

outlet the heater is ready to be used.

It must be guaranteed that a heater

permanently connected to the power

supply can be switched o through a

disconnection mechanism (e.g. a circuit

breaker, installation switch, etc.) with a

minimum separation distance of 3 mm to

the contact.

7. Should you have diculty tting this

product please contact your local

electrician.

8. If this product is being hard wire into you

electrical supply, it is recommend that any

installation of this nature is carried out by

a fully qualied electrician.

USING YOUR APPLIANCE

The heater WL41003 is only suitable to be

used in dry rooms (in accordance with the

norm IP 20).

The frost protection convector is intended to be

used in unheated rooms in order to prevent the

freezing of water pipes, frost damages on walls,

as well as for the hibernation of plants in the

house or winter garden.

The use of bathrooms as a frost protection

device is only permitted if it is guaranteed that

the device does not come into any contact with

humidity and moisture.

The heater may only be used when installed on

a wall and only for the purposes described.

The product automatically switches on when

the temp drops below 0°C, when the product

is set to the lowest setting

The thermostat will then control the

temperature upto a maximum of 30°C

depending on the room size. (The product will

not warm up a large room to 30°C !!)

CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056

CLEANING AND CARE

• Before attempting to clean the appliance

please ensure that the appliance is

disconnected from the power supply to

ensure that there is no risk of electrical

shock.

• To clean the appliance use a damp cloth

with a small amount of mild detergent and

wipe the case of the appliance.

• Do not attempt to clean the internal

spaces.

• If the appliance shows any signs of wear

or damage disconnect immediately from

the mains supply, do NOT use it – have it

checked by a suitably qualied person.

WARNING:

DO NOT IMMERSE ANY PART OF THE

APPLIANCE IN WATER

DISPOSAL OF THE UNIT

Appliances bearing the symbol shown here

may not be disposed of in domestic rubbish.

You are required to dispose of old electrical

and electronic appliances like this separately.

Please visit www.recycle-more.co.uk or

www.recyclenow.co.uk

for access to information about the recycling

of electrical items.

Please visit www.weeeireland.ie for access to

information about the recycling of electrical

items purchased in Ireland.

The WEEE directive, introduced in August

2006, states that all electrical items must be

recycled, rather than taken to landll.

Please arrange to take this appliance to your

local Civic Amenity site for recycling, once it

has reached the end of its life.

www.warmlite.co

NOTES

CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056

NOTES

Table des matières

Autres manuels Warmlite Chauffage

Warmlite

Warmlite WL41008 Instructions de montage

Warmlite

Warmlite WL42002 Manuel utilisateur

Warmlite

Warmlite WL42006 Instructions de montage

Warmlite

Warmlite WL41001 Manuel utilisateur

Warmlite

Warmlite WL43003YT Manuel utilisateur

Warmlite

Warmlite WL41001 Manuel utilisateur

Warmlite

Warmlite WL41006 Instructions de montage

Warmlite

Warmlite WL44014 Instructions de montage

Warmlite

Warmlite WL43003YTW Manuel utilisateur

Warmlite

Warmlite WL42006 Manuel utilisateur

Warmlite

Warmlite WL44018 Manuel utilisateur

Warmlite

Warmlite WL42013 Instructions de montage

Warmlite

Warmlite WL43002Y Manuel utilisateur

Warmlite

Warmlite WL43003Y Instructions de montage

Warmlite

Warmlite WL41001N Manuel utilisateur

Warmlite

Warmlite WL43009 Instructions de montage

Warmlite

Warmlite WL41007 Manuel de l'opérateur

Warmlite

Warmlite WL44005 Manuel utilisateur

Warmlite

Warmlite WHITBY 2KW Manuel utilisateur

Warmlite

Warmlite WL43006Y Manuel utilisateur

Warmlite

Warmlite WL43005Y Manuel utilisateur

Warmlite

Warmlite WL44002 Manuel utilisateur

Warmlite

Warmlite WL43004Y Manuel utilisateur

Warmlite

Warmlite WL44004 Instructions de montage

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
