Item No. / Artículo No/ Article n° : 7402

1.5A Intelligent

Battery Charger

User’s Manual / Manual de Usuario / Guide d’Utilisation

We are constantly improving our products so speciﬁcations are subject to change

without notice. Visit our website for the latest product information.

Estamos mejorando nuestros productos constantemente, por lo tanto, las

especiﬁcaciones están sujetas a cambios sin previo aviso. Visite nuestro sitio

web para obtener la información más reciente de los productos.

Nous améliorons constamment nos produits, alors les spéciﬁcations sont sujettes à changement

sans préavis. Visitez notre site Web, pour obtenir les dernières informations sur nos produits.

1.5A Intelligent Battery Charger by Wagan Tech®

1www.wagan.com

Thank you for purchasing the 1.5A Intelligent Battery Charger by Wagan Tech®.

With normal care and proper treatment, it will provide years of reliable service.

Please read all operating instructions carefully before use.

FEATURES

LED Status

Light

6' AC Cord

6' Charging

Cord

Heavy-duty

Clamps

Ring Connectors

SPECIFICATIONS

Charging Rates 12V, 1.5A

Input Voltage 110 -2 40V AC

Battery types Lead Acid (wet, AGM, Gel)

Wagan Tech and wagan.com are trademarks of Wagan Corporation.

User’s Manual—Read before using this equipment

# of Charging Stages 3

Charging Stages Bulk, Absorption, Maintenance

Safety Features Short Circuit, Reverse Connection

Cable length AC Cord: 6 ft

DC Clamps: 6 ft

Dimensions (HWD) 5.3 x 2.6 x 1.5 in

Weight 0.9 lbs

IMPORTANT SAFETY INSTRUCTIONS

1. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

2. Working in vicinity of a lead-acid battery can dangerous. Batteries

generate explosive gases during normal battery operation. For this reason,

it is of utmost importance that before using your charger, you read this

manual and follow the instruction exactly.

3. To reduce risk of battery explosion, follow these instructions and those

published by the battery manufacturer and manufacturer of any equipment

you intend to use in vicinity of battery. Review cautionary markings on these

products and on engine.

4. Intended for indoor use only. Do not expose it to rain.

1.5A Intelligent Battery Charger by Wagan Tech®

3www.wagan.com

GENERAL SAFETY

1. Use charger for charging LEAD-ACID batteries only.

Do not use battery charger for other types of batteries, which may burst

and cause injury to persons and damage to property.

2. Use only attachments recommended or sold by manufacturer. Use of non-

recommended attachments may result in ﬁre, electric shock, or injury.

3. When disconnecting the battery charger, pull by the plug not by the cord.

Pulling on the cord may cause damage to cord or plug.

4. Do not operate charger with damaged cord or plug. Have cord replaced

immediately.

5. Do not operate charger if it has received a sharp blow, been dropped,

or otherwise damaged in any way. Take it to a qualiﬁed professional for

inspection and repair.

6. Do not disassemble charger. Take it to a qualiﬁed professional when service

or repair is required. Incorrect reassembly may result in electric shock or

ﬁre.

7. To reduce risk of electric shock, unplug charger from outlet before

attempting any maintenance or cleaning.

8. Do not use an extension cord unless absolutely necessary. Use of an

improper extension cord could result in ﬁre or electric shock. If an extension

cord must be used, make sure that:

• Pins on plug of extension cord are the same number, size, and shape

as those of plug on charger.

• Extension cord is properly wired and in good electrical condition.

• Wire size is large enough for AC ampere rating of charger

9. Always charge battery in a well ventilated area. NEVER operate in a

closed-in or restricted area without adequate ventilation. WARNING: Risk of

explosive gas.

Wagan Tech and wagan.com are trademarks of Wagan Corporation.

User’s Manual—Read before using this equipment

10. Locate charger as far away from battery as DC charger cable’s permit.

11. Do not expose charger to rain or snow.

12. NEVER charge a frozen battery. If battery ﬂuid (electrolyte) is frozen, bring

into a warm area to thaw before charging.

13. NEVER set a battery on top of charger.

14. NEVER place charger directly above battery being charged. Gases from

battery will corrode and damage charger.

15. NEVER touch the battery clamps together when the charger is energized.

16. NEVER crank engine with charger attached to battery.

PERSONAL PRECAUTIONS AND SAFETY

1. WARNING: Wear complete eye protection and clothing protection, when

working with lead-acid batteries.

2. Make sure someone is within range of your voice or close enough to come

to your aid when you work with or near a lead-acid battery.

3. Have plenty of fresh water and soap nearby for use if battery acid contacts

skin, clothing, or eyes. If battery acid contacts skin or clothing, wash

immediately with soap and water.

4. Avoid touching your eyes while working with a battery. Acid particles

(corrosion) may get into your eyes! If acid enters your eye, immediately

ﬂood eye with running cold water for at least 10 minutes. Get medical

attention immediately.

5. Remove all personal metal items such as rings, bracelets, necklaces, and

watches when working with a lead-acid battery.

6. Take care not to drop a metal tool or other metal onto the battery. Metal

may cause sparking or short circuit the battery or another electrical devise.

Sparking may cause an explosion.

1.5A Intelligent Battery Charger by Wagan Tech®

5www.wagan.com

7. Always operate battery charger in an open well ventilated area.

8. NEVER smoke or allow a spark or ﬂame in the vicinity of the battery or

engine. Batteries generate explosive gases!

OPERATING INSTRUCTIONS

1. Connecting the charger to the battery.

The charger’s output leads have color-coded battery clamps (RED-POSITIVE

and BLACK- NEGATIVE). Connect these directly to the corresponding

connectors on the battery posts.

2. Connect the charger to AC power socket. The light will turn “YELLOW”, and

then charging begins.

3. When the battery is full, the light will turn “GREEN”.

Stop charging at any time by disconnecting the AC cable from the wall

socket.

The light will be off in any cases of “loose clamps”, “reverse connection” or “short

circuit”.

CHARGING BATTERIES IN VEHICLE

1. Position AC and DC cords to reduce risk of damage by hood, door, or

moving engine part.

2. Stay clear of fan blades, belts, pulleys, and other parts that can cause

injury to persons.

Wagan Tech and wagan.com are trademarks of Wagan Corporation.

User’s Manual—Read before using this equipment

3. Check polarity of battery posts. POSITIVE (POS, P, +) and NEGATIVE (NEG,

N, –).

4. Determine which post of battery is grounded (connected) to the chassis.

If negative post is grounded to chassis (as in most vehicles), connect

POSITIVE (RED) clamp from battery charger to POSITIVE (P0S, P, +)

ungrounded post of battery. Connect NEGATIVE (BLACK) clamp to vehicle

chassis or engine block away from battery. Do not connect clamp to

carburetor, fuel lines, or sheet-metal body parts. Connect to heavy gauge

metal part of the frame or engine block.

If positive post is grounded to the chassis, connect NEGATIVE (BLACK)

clamp from battery charger to NEGATIVE (NEG, N, –) ungrounded post

of battery. Connect POSITIVE (RED) clamp to vehicle chassis or engine

block away from battery. Do not connect clamp to carburetor, fuel lines, or

sheet-metal body parts. Connect to a heavy gauge metal part of the frame

or engine block.

5. When disconnecting charger, disconnect AC cord ﬁrst, remove clamp from

vehicle chassis, and then remove clamp from battery terminal.

6. Do not charge the battery while the engine is operating.

1.5A Intelligent Battery Charger by Wagan Tech®

7www.wagan.com

CARE AND MAINTENANCE

With only minimal maintenance, the 1.5A Intelligent Battery Charger will deliver

years of dependable service. Follow these simple steps to maintain the charger

in optimum condition: After each use, clean the battery charger clamps - be sure

to remove any battery ﬂuid that will cause corrosion of the copper clamps. Clean

the outside case of the charger with a soft cloth and, if necessary, mild soap

solution. Keep the charger cords loosely coiled during storage to prevent damage

to the cords. Do not use the charger if cords or clamps have been damaged

in any way. If the power supply cord is damaged, it must be replaced by the

manufacturer, its service agent or qualiﬁed person in order to avoid a hazard.

The WAGAN Corporation warranty is limited to products sold only in

the United States.

Warranty Duration:

Product is warranted to the original purchaser for a period of one (1) year from

the original purchase date, to be free of defects in material and workmanship.

WAGAN Corporation disclaims any liability for consequential damages. In no event

will WAGAN Corporation be responsible for any amount of damages beyond the

amount paid for the product at retail.

Warranty Performance:

During the warranty period, a product with a defect will be replaced with a

comparable model when the product is returned to WAGAN Corporation with an

original store receipt. WAGAN Corporation will, at its discretion, replace or repair

the defective part. The replacement product will be warranted for the balance of the

original warranty period. This warranty does not extend to any units which have

been used in violation of written instructions furnished.

Warranty Disclaimers:

This warranty is in lieu of all warranties expressed or implied and no representative

or person is authorized to assume any other liability in connection with the sale of our

products. There shall be no claims for defects or failure of performance or product

failure under any theory of tort, contract or commercial law including,but not limited

to negligence, gross negligence, strict liability, breach of warranty, and breach of

contract.

Returns:

WAGAN Corporation is not responsible for any item(s) returned without an ofﬁcial

Return Authorization number (RA#). Please contact our customer service team by

phone or email to obtain an RA#. You can also visit our website and chat with our team

during our normal business hours. For more details and instructions on how to process

a warranty claim, please read the “Returns” section under the “Contact” page on our

website. WAGAN Corporation is not responsible for any shipping charges incurred in

returning the item(s) back to the company for repair or replacement.

WAGAN Corp. Limited Warranty

1.5A Intelligent Battery Charger de Wagan Tech®

9www.wagan.com

Gracias por comprar la 1.5A Intelligent Battery Charger de Wagan Tech®.

Con un cuidado normal y un uso adecuado, este producto le durará años. Lea

detenidamente el manual de instrucciones antes de poner en funcionamiento el

producto.

CARACTERÍSTICAS

Cable de CA de 1,80 m

Cable de

carga de

1,80 m

Agarraderas

de máxima

resistencia

Pantalla LCD

Anillos conectores

ESPECIFICACIONES

Especiﬁcaciones de

carga 12V, 1.5A

Voltaje de entrada 110 -2 40V CA

Table des matières

Langues :

Autres manuels Wagan Chargeur de batteries

Wagan

Wagan 2045 Manuel utilisateur

Wagan

Wagan Deluxe Power Backup Manuel utilisateur

Wagan

Wagan Companion GO Manuel utilisateur

Wagan

Wagan Solar ePower 2053 Manuel utilisateur

Wagan

Wagan 7406 Manuel utilisateur

Wagan

Wagan Travel Charge DC Link 2.4 Manuel utilisateur

Wagan

Wagan 2889 Travel Charge Manuel utilisateur

Wagan

Wagan Solar e Charger Exec-Duo Manuel utilisateur

Wagan

Wagan TravelCharge Companion GO-Plus2 Manuel utilisateur

Wagan

Wagan Solar e Link Glide Manuel utilisateur

Wagan

Wagan 7403 Manuel utilisateur

Wagan

Wagan Solar e Power Cube 1500 Plus Manuel utilisateur

Wagan

Wagan Solar e Charger Solo Manuel utilisateur

Wagan

Wagan Solar e Charger Manuel utilisateur

Wagan

Wagan 2558 Manuel utilisateur

Wagan

Wagan 2467-ES Manuel utilisateur

Wagan

Wagan 7407 Manuel utilisateur

Wagan

Wagan Power Dome 400 Manuel utilisateur

Wagan

Wagan TwinSoket 2104 Manuel utilisateur

Wagan

Wagan 8324 Manuel utilisateur

Wagan

Wagan Power Dome LT 2464 Manuel utilisateur

Wagan

Wagan 25A-7410 Manuel utilisateur

Manuels Chargeur de batteries populaires d'autres marques

AA Portable Power Corp

AA Portable Power Corp Universal Smart Charger Manuel utilisateur

Enelion

Enelion Vertica Manuel utilisateur

RCA

RCA CHU6 Manuel utilisateur

ANSMANN

ANSMANN ALCT 6/24-10 Manuel utilisateur

Hitachi

Hitachi UC 18YRSL Guide de dépannage

Olympus

Olympus B-20 LPC Manuel utilisateur

Exibel

Exibel ZH1708143 Manuel utilisateur

Lenmar

Lenmar Mach 1 Manuel utilisateur

CTEK

CTEK MXS 5.0 Manuel utilisateur

ABB

ABB HT842379 Manuel utilisateur

Nitecore

Nitecore Superb Charger SC4 Manuel utilisateur

Renogy

Renogy RBC2125DS-21W Manuel utilisateur

Braun

Braun BWC02M Manuel utilisateur

CTEK

CTEK MXS 3.6 Manuel utilisateur

Black & Decker

Black & Decker BDV090 Manuel utilisateur

Trinity

Trinity DPD Manuel utilisateur

Hulkman

Hulkman Sigma 1 Manuel utilisateur

IKEA

IKEA koppla Manuel utilisateur
