151PowerDAC
manual
mini
Thank You.
All of us at Wadia Digital would like to say thank
you, and congratulations for purchasing the Wadia
151PowerDAC mini Digital Integrated Amplifier. We
sincerely believe that your Wadia 151PowerDAC
mini is an intelligent investment that will bring you
many years of musical enjoyment and satisfaction.
We understand how eager you are to begin listening
and we want you to become familiar with the full
capabilities of the Wadia 151PowerDAC mini.
However, before powering on the device, we
encourage you to look through the manual and
pay special attention to the sections highlighted
with an ◆.
Table of Contents
Installation
Connections
Operation
Appendices
Wadia Digital–aBriefHistory 4
Optimizing Performance 6
Getting Started 8
Features 8
Unpacking 9
Accessories 9
Installing Battery in Remote Control 10
◆Connecting to AC Power 10
◆Using Line Conditioners 11
◆Using Surge Protectors 11
Back Panel 12
◆Speaker Outputs 13
◆Connecting the Digital Inputs 13
Front Panel 14
Using the 151PowerDAC mini 15
Using the Remote Control 16
Warranty 18
Specifications 20
Wadia Digital – a Brief History
Wadia Digital, founded in 1988, is one of the original companies dedicated to
high performance digital audio reproduction. Wadia was formed by a team of
engineers from the Minneapolis based 3M Corporation (Minnesota Mining and
Manufacturing) who shared many years of experience in advanced digital
telecommunications research and development. In the early 1980’s, these engineers
became intrigued by the emerging compact disc technology. Disappointed with
the sound quality of early CD players, they examined the workings and designs of
these early components and found them to be unsophisticated when compared
with the technology available in other areas of digital design. In response, they
founded Wadia Digital – a company based on the philosophy of applying advanced
technology to improve the performance of digital audio components. Wadia’s
first product, the Wadia 2000 Decoding Computer, was an absolute breakthrough
in digital audio. For many discerning listeners, it proved that Digital Audio was a
musically responsive, evolving, and engaging format.
Building on a tradition of excellence, Wadia continues to develop innovative
technology; refining, listening, engineering, and improving along the way. Since the
Wadia 2000, new generations of industry-leading designs have been introduced
and embraced by listeners around the world. Each step of the way, Wadia has
consistently raised the standard for performance of Digital Audio playback.
4
Here is a brief list of the technological innovations the Wadia engineers
have pioneered over the past 20 years:
• DigiMaster™ patented algorithm (filter optimized for reproducing music)
• ClockLink™ proprietary jitter reduction technology
• SwiftCurrent™ current to voltage conversion technology
• First outboard Digital-to-Analog converter
• First to apply glass fiber-optics to home audio
• First to recognize jitter as a source of audible distortion
• First to perfect digital volume control
• First high-end CD player competitive with expensive separates
•First company to provide bit perfect digital audio output from the iPod
While Wadia’s expertise and track record exceed those of most digital audio
companies, technology alone does not guarantee an immersive and captivating
musical performance. Wadia’s intuitive designs are born of a delicate balance
of technology shaped by a passion for music.
Wadia continues to re-define the limits of digital music playback. We are proud to
introduce the Wadia 151PowerDAC mini–abreakthrough in sonic performance
and a strong statement of our dedication to music.
5
Optimizing Preformance
To get the best performance from your 151PowerDAC mini, and for your
own safety, please read and follow these important safety instructions.
• Before operating the 151PowerDAC mini please read all operating and
safety instructions.
• Never place the 151PowerDAC mini near heat sources such as
radiators, fireplaces, stove, or other appliances that produce heat.
Avoid placing the 151PowerDAC mini where it will be subject to direct
sunlight or low temperatures.
• This product is equipped with a three prong AC power cord which
includes an earth ground connection. To prevent shock hazard, all three
connectors must always be used. If your electrical outlets will not accept
this type of plug, an adapter may be purchased. If an adapter is necessary,
be sure it is an approved type and that it is used properly, supplying an
earth ground. If you are not sure of the integrity of your home’s electrical
system, contact a licensed electrician for assistance.
6
• AC extension cords are not recommended for use with this product.
If an extension cord must be used, be sure it is an approved type and
has sufficient current carrying capacity to power this product.
• Before cleaning the 151PowerDAC mini, always disconnect the power
supply cord. Use a soft cloth and, if necessary, dampen with plain water.
Never apply water, or any other cleaner, directly to the chassis.
• If you smell smoke, or an abnormal smell, immediately unplug the
151PowerDAC mini from the power supply and contact your Wadia dealer.
• Unplug unit if it becomes wet.
• THERE ARE NO USER SERVICEABLE PARTS INSIDE THE 151PowerDAC mini!
Do not attempt to repair or modify your 151PowerDAC mini.
All service should be performed by qualified service personnel.
Do not open the unit while it is attached to the AC outlet.
7
Installation
Getting Started
The Wadia 151PowerDAC mini is an integrated amplifier with 4 digital inputs
with upsampling to 24-bit/384kHz. Despite its small size the 151PowerDAC mini,
bursting with technology to bring you the best sound possible.
Features
•24-bit/384kHz upsampling
•Accepts up to a 24-bit/192kHz input data rate
•Wadia’s DirectConnect with Digital Volume Control technology
•25 Watt/channel 8 Ohm, 50 Watt/channel 4 Ohm
•4 Digital Inputs: 2 Coaxial S/PDIF (RCA), 1 TOSLINK Optical, 1 USB B
•5-way insulated Gold Binding Posts
•High quality Gold Plated Input Jacks
•Aluminum full function Remote Control
•Heavy Duty Power Cord
8
Unpacking
Use care in unpacking your Wadia 151PowerDAC mini. Inspect it for any shipping
damage and call your dealer immediately if any is found.
Do not plug your Wadia 151PowerDAC mini into an AC outlet if you find
shipping damage.
We advise saving all packing materials so that the unit can be easily and safely
shipped if the need arises.
Accessories
Provided with the Wadia 151PowerDAC mini are the following accessories:
• AC power cord
• Remote Control
• Two AAA batteries
9
Installing Battery in Remote Control
The Wadia 151PowerDAC mini remote control requires two AAA batteries,
which you will find in the accessories kit. To install the batteries, remove the
battery cover on the back of the remote. Insert the batteries as indicated on the
battery holders, and replace the cover.
◆Connecting to AC Power
Check to make sure that the power cord shipped with your Wadia 151PowerDAC
mini has been manufactured for operation at your AC line voltage. Damage caused
by improper operation is not covered by Wadia warranty. If the included cable
and wall termination is different from your AC outlet, contact your Wadia dealer.
