Vulcan-Hart 85MF Manuel utilisateur

VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

A2780

ISO9001

Vulcan-Hart Co.

Item # __________________________

C.S.I. Section 11420

F-32633 (6-07)

MODEL: 85MF MOBILE FILTER

MODEL 85MF

MOBILE FILTER

SPECIFICATIONS:

Mobile filter system, Vulcan-Hart Model No. 85MF. Filter vessel

constructed of 16 gauge stainless steel. Stainless steel fold

down handle and casters provide mobility. Roll up to any fryer to

drain and filter oil. 90 lbs. maximum filter capacity of shortening.

1/3H.P. motor and pump circulates hot frying compound at the rate

of 8 gallons per minute. 75 watt heater on intake line. System

provided with removable stainless steel mesh screen. Requires

120 volt, 60 Hz, 1 phase power supply.

Overall dimensions: 16"w x 307/8"d x 171/2"h.

UL Listed E206082.

STANDARDFEATURES

16 gauge stainless steel filter vessel.

Fold down stainless steel handle and casters for ease of

mobility.

6’ oil discard hose with handle.

1/3H.P. motor and pump circulates hot frying compound at

the rate of 8 gallons per minute.

75 watt heater on intake line.

Removable stainless steel mesh screen.

120 volt, 60 Hz, 1 phase.

One year limited parts and labor warranty.

OPTIONS

208 volt, 50/60 Hz, 1 phase.

220 - 240 volt, 50/60 Hz, 1 phase.

Second year extended limited parts and labor warranty.

85S

ACCESSORIES

Stainless Steel Cover

VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

F-32633 (6-07)

MODEL 85MF

MOBILE FILTER

IMPORTANT

1. The use of diatomaceous filtering compound is recommended

for thorough cleansing of the shortening. However, it is not

required for filtration with this unit.

2. This appliance is manufactured for commercial installation

only and is not intended for home use.

SERVICE CONNECTIONS:

120 volt, 60 Hz, 1 phase power supply. Cord & plug supplied.

PUMP FILTER APPROX.

MODEL NO. MOTOR ELEC./AMPS CAPACITY AREA SHIP. WT.

85MF

HP/1750RPM 115V / 5.0 8 gal./min. 283 sq. in 65 lbs./29 kg
