Item # __________________________

C.S.I. Section 11420

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

A2780

ISO9001

Vulcan-Hart Co.

F-32096 (10-03)

MODEL: MG48 SERIES

Modular Gas Restaurant Range

MG48 SERIES

MODULAR GAS RESTAURANT RANGE

STANDARD FEATURES

■Stainless steel front, front top, sides and riser.

■Eight 26,000 BTU/hr. open burners. Pilot for every burner.

■Level cast iron burner grates for easy sliding of pots and pans

across the open top sections.

■Each open top removable grate section is cast in one piece

with the burner spillover bowl. Grate size 12" x 12".

■Full width pull out crumb tray under the burners.

■Lift-off anti clog open burner heads.

■Cool to the touch control knobs.

■Full width stainless steel panel behind controls.

■4" adjustable nickel plated legs, shipped attached.

■Pressure regulator.

■Ideal for 9, 12, or 16 quart stock pots.

■One year limited parts and labor warranty.

OPTIONS

■■Second year extended limited parts and labor warranty.

TOP OPTIONS

■■Even Heat Hot Top Sections

• 20,000 BTU/hr. input per section.

• 12" x 24" cast iron top sections.

• Substitute for open top burner 12" sections, specify

location(s).

• Corrugated heat absorbing ribs on under side of casting.

• Use for larger stock pots.

■■Step-Up Burners

• Rear burners elevated 4".

ACCESSORIES

■■3/4" x 4 ft. flexible gas hose with quick disconnect and

restraining device.

SPECIFICATIONS:

Modular gas restaurant range with eight 26,000 BTU/hr. open

burners, Vulcan-Hart Model No. MG48. Eight removable level

top cast iron grates. Total top BTU/hr. input 208,000. Stainless

steel front, front top, sides and riser. 4" adjustable nickel plated

legs. Lift-off anti-clog open burner heads and full width pull out

crumb drawer. Pressure regulator. Gas supply to be (natural)

(propane).

Exterior dimensions: 48"w x 293/4"d x 121/2"h.

CSA design certified. NSF listed.

SPECIFY TYPE OF GAS WHEN ORDERING.

MG48 Shown with

optional step-up rear burners

Printed On Recycled Paper

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

F-32096 (10-03)

MG48 SERIES

MODULAR GAS RESTAURANT RANGE

IMPORTANT

1. A pressure regulator sized for this unit is included. Natural Gas

3.7" W.C. Propane Gas 10.0" W.C.

2. An adequate ventilation system is required for Commercial

Cooking Equipment. Information may be obtained by writing to

the National Fire Protection Association, Batterymarch Park,

Quincy, MA 02269. When writing refer to NFPA No. 96.

NOTE:

TWO (2) OPEN TOP BURNERS (FRONT TO REAR ONLY)

MAY BE REPLACED BY ONE (1) 12" HOT TOP

3. These units are manufactured for installation in accordance

with ANSZ223.1a (latest edition), National Fuel Gas Code.

Copies may be obtained from American Gas Association,

1515 Wilson Blvd., Arlington, VA 22209.

NOTE: This appliance must be installed with a 6" clearance at

both sides and the rear adjacent to combustible construction.

Not intended for domestic household installation.
