VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
A2780
ISO9001
Vulcan-Hart Co.
Item # __________________________
C.S.I. Section 11420
F-32636 (6-07)
MODEL: 1GPC12 GAS PASTA COOKER
STANDARDFEATURES
Stainless steel front and sides.
316 stainless steel tank, 12 gallon capacity. Includes limited
12 year tank warranty.
Set of four 6" adjustable casters (2 locking).
Overflow dam with skim port for starch removal and overflow
protection.
1" full port drain valve.
90,000 BTU/hr. input.
Temperature control adjusts from 190 to 212F. Power "ON",
"HEATING" and "HI-LIMIT" indicators.
Hi-limit shut-off.
Combination gas shut-off valve, pressure regulator and
electronic pilot ignition system.
1/2" rear gas connection.
Tank cleaning brush.
One year limited parts and labor warranty.
ACCESSORIES
Fine mesh stainless steel bulk cook basket.
Twelve section retherm basket with a set of twelve plastic
retherm portion cups. NSF approved.
Set of six individual 51/4" round fine mesh stainless steel cook
and retherm baskets with base screen.
3/4" x 4 ft. flexible gas hose with quick disconnect and restrain-
ing device.
MODEL 1GPC12
GAS PASTA COOKER
SPECIFICATIONS:
Gas pasta cooker, Vulcan-Hart Model No. 1GPC12. 316 stain-
less steel tank, 12 gallon capacity. Stainless steel front and
sides. Set of four 6" adjustable casters (2 locking). Overflow
dam with diameter skim port. 1" full port ball type drain valve.
90,000 BTU/hr. input. Temperature control adjusts from 190
to 212F. Power "ON", "HEATING" and "HI-LIMIT" indicators. Hi-
limit shut-off. Combination gas shut-off valve, pressure regulator
and electronic pilot ignition system. 1/2" rear gas connection.
Tank cleaning brush.
Overall dimensions: 151/2"w x 343/4"d x 471/8"h. Working height
361/4".
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFYALTITUDEWHENABOVE2,500FT.
