Vulcan-Hart 900RE Series Manuel utilisateur

900RE SERIES

HEAVY DUTY GAS GRIDDLES

MODELS

924RE ML-135221-00G24

936RE ML-135222-00G36

948RE ML-135223-00G48

960RE ML-135224-00G60

972RE ML-135225-00G72

VULCAN-HART

DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC

WWW.VULCANHART.COM

P.O. BOX 696, LOUISVILLE, KY 40201-0696

TEL. (502) 778-2791

INSTALLATION &

OPERATION MANUAL

For additional information on Vulcan-Hart or to locate an authorized parts

and service provider in your area, visit our website at www.vulcanhart.com

FORM 35627 (09-04)

Model 948RE

— 2 —

IMPORTANT FOR YOUR SAFETY

THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL

GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND

ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.

POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE

EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED

FROM THE LOCAL GAS SUPPLIER.

IMPORTANT

IN THE EVENT A GAS ODOR IS DETECTED,

SHUT DOWN UNITS AT MAIN SHUTOFF VALVE

AND CONTACT THE LOCAL GAS COMPANY

OR GAS SUPPLIER FOR SERVICE.

FOR YOUR SAFETY

DO NOT STORE OR USE GASOLINE OR OTHER

FLAMMABLE VAPORS OR LIQUIDS IN THE

VICINITY OF THIS OR ANY OTHER APPLIANCE.

WARNING

IMPROPER INSTALLATION, ADJUSTMENT,

ALTERATION, SERVICE OR MAINTENANCE CAN

CAUSE PROPERTY DAMAGE, INJURY OR

DEATH. READ THE INSTALLATION, OPERATING

AND MAINTENANCE INSTRUCTIONS

THOROUGHLY BEFORE INSTALLING OR

SERVICING THIS EQUIPMENT.

IN THE EVENT OF A POWER FAILURE, DO NOT

ATTEMPT TO OPERATE THIS DEVICE.

— 3 —

INSTALLATION, OPERATION AND CARE OF

900RE SERIES HEAVY DUTY GAS GRIDDLES

PLEASE KEEP THIS MANUAL FOR FUTURE USE

GENERAL

Vulcan griddles are produced with quality workmanship and material. Proper installation, usage

and maintenance of your griddle will result in many years of satisfactory performance.

Thoroughly read this entire manual and carefully follow all of the instructions provided.

OPTIONAL FIELD INSTALLABLE ACCESSORIES

Cutting Board

Flex Hose

Stainless Steel Stand with Casters

INSTALLATION

Before installing, verify that the electrical service and type of gas supply (natural or propane) agree

with the specifications on the rating plate located inside the griddle door panel. If the supply and

equipment requirements do not agree, do not proceed with the installation. Contact your dealer or

Vulcan-Hart immediately.

UNPACKING

This griddle was inspected before leaving the factory. The transportation company assumes full

responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking,

check for possible shipping damage. If the griddle is found to be damaged, save the packaging

material and contact the carrier within 15 days of delivery.

Carefully unpack griddle. Make sure no parts are discarded with crating material. A pressure

regulator designed to operate with this griddle has been supplied. The regulator requires installation

before the griddle is placed into service. (Refer to GAS PRESSURE AND REGULATOR

INSTALLATIONS in this manual.) The regulator, in addition to a carpenter level and the Operation

and Installation manual is packaged in the grease drawer of the griddle. Read all directions supplied

before installing or operating the griddle. Place griddle in its final installed position.

— 4 —

ASSEMBLY

The griddle is shipped standard as a complete unit on 4" adjustable legs and does not require field

assembly.

INSTALLATION CLEARANCES:

COMBUSTIBLE NONCOMBUSTIBLE

CONSTRUCTION CONSTRUCTION

Back: 6" 0"

Right Side: 6" 0"

Left Side: 6" 0"

The installation location must allow adequate clearances for servicing and proper operation. A

minimum front clearance of 36" is required.

Do not obstruct the flow of combustion and ventilation air. Adequate clearance for air openings into

the combustion chamber must be provided. Make sure there is an adequate supply of air in the room

to replace air taken out by the ventilating system.

Do not permit air to blow directly at the griddle. Wherever possible, avoid open windows next to the

griddle. Avoid wall-type fans which create air cross currents within the room.

INSTALLATION CODES AND STANDARDS

The griddle must be installed in accordance with:

In the United States of America:

1. State and local codes.

2. National Fuel Gas Code, ANSI-Z223.1 (latest edition). Copies may be obtained from The

American Gas Association, Inc., 1515 Wilson Blvd., Arlington, VA 22209.

3. National Electrical Code, ANSI/NFPA-70 (latest edition). Copies may be obtained from The

National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.

In Canada:

1. Local codes.

2. CSA B149.1 Natural Gas and Propane Installation Code.

3. CSA C22.1 Canadian Electrical Code.

The above are available from the Canadian Standard Association, 5060 Spectrum Way, Suite 100,

Mississauga, Ontario, Canada L4W 5N6.

LOCATION

The equipment area must be kept free and clear of combustible substances.

This appliance is Design Certified for installation on non-combustible counter with 4" legs or

combustible floor with 25" high leg stand.

When installing, never enclose the bottom area of the unit with raised curb or other constructions

that would obstruct the flow of air into the unit.

— 5 —

GRIDDLES MOUNTED ON STANDS WITH CASTERS

Griddle mounted on casters must use a flexible connector

(not supplied by Vulcan) that complies with the Standard

for Connectors for Movable Gas Appliances, ANSI Z21.69

• CSA 6.16 and a quick-disconnect device that complies

with the Standard for Quick-Disconnect Devices for Use

With Gas Fuel, ANSI-Z21.41 • CSA 6.9. In addition,

adequate means must be provided to limit movement of

the appliance without depending on the connector and

the quick-disconnect device or its associated piping to

limit appliance movement. Attach the restraining device

at the rear of the griddle as shown in Fig. 1.

If disconnection of the restraint is necessary, turn off the gas supply before disconnection.

Reconnect this restraint prior to turning the gas supply on and returning the griddle to its installation

position.

Note: Casters are supplied only on a griddle stand. If for any reason the griddle is moved, it is

recommended that the griddle be re-leveled (see Leveling instructions found in this manuals).

Stand

The griddle has an optional 25" high by 30" deep by 24", 36", 48", 60" or 72" wide stainless steel

stand with casters. The two front casters are locking casters. The stand includes a top shelf with

marine edge style lip and a lower shelf.

INSTALLATION OF CUTTING BOARDS

Refer to the cutting board installation instructions provided with the cutting board kit.

GAS CONNECTIONS

CAUTION: Gas supply connections and any pipe joint compound must be resistant to

the action of propane gases.

Location of the gas inlet is at the rear of the griddle. For 24", 36" and 48" wide griddles, use a 3/4"

NPT gas supply line. For 60" and 72" wide griddles, use a 1" NPT gas supply line. All connection

of flexible and semirigid type must comply with the applicable ANSI standard. To insure maximum

operating efficiency, this appliance must be connected with a gas supply line of solid pipe or a

commercial Type Flexible Connector with the I.D. (net inside diameter) as large or larger than the

gas pipe inlet on this appliance. Codes require that a gas shutoff valve must be installed in the gas

line ahead of the griddle.

WARNING: PRIOR TO LIGHTING, CHECK ALL JOINTS IN THE GAS SUPPLY LINE FOR

LEAKS. USE SOAP AND WATER SOLUTION. DO NOT USE AN OPEN FLAME.

After piping has been checked for leaks, all piping receiving gas should be fully purged to remove

air.

Fig. 1

— 6 —

ELECTRICAL CONNECTIONS

WARNING: ELECTRICAL AND GROUNDING CONNECTIONS MUST COMPLY WITH THE

APPLICABLE PORTIONS OF THE NATIONAL ELECTRICAL CODE AND/OR OTHER LOCAL

ELECTRICAL CODES.

WARNING: DISCONNECT THE ELECTRICAL POWER TO THE MACHINE AND FOLLOW

LOCKOUT / TAGOUT PROCEDURES.

GAS PRESSURE AND REGULATOR INSTALLATION

Gas regulator pressure is preset at the factory at 5" W.C. (Water Column) for natural gas and 10"

W.C. for propane gas. No further adjustment should be required.

Install the regulator as close to the griddle on the gas supply line as possible. Make sure that the

arrow on the underside of the regulator is pointing toward the flow of gas to the griddle (Fig. 2) and

the regulator is positioned with the vent plug and adjustment screw up right (Fig. 3).

The installation supply pressure should be 7-9" W.C. (water column) for natural gas and 11-12"

W.C. for propane gas.

At no time should the griddle be connected to supply pressure greater than 1/2psig (3.45 kPa) or

14" W.C.

TESTING THE GAS SUPPLY SYSTEM

When gas supply pressure exceeds 1/2psig (3.45 kPa), the griddle and its individual shutoff valve

must be disconnected from the gas supply piping system.

When gas supply pressure is 1/2psig (3.45 kPa) or less, the griddle should be isolated from the gas

supply system by closing its individual manual shutoff valve.

FLUE CONNECTIONS

DO NOT obstruct the flow of flue gases from the flue located on the rear of the griddle. It is

recommended that the flue gases be ventilated to the outside of the building through a ventilation

system installed by qualified personnel.

From the termination of the flue to the filters of the hood venting system, a minimum clearance of

18" must be maintained.

Information on the construction and installation of ventilating hoods may be obtained from the

standard for "Vapor Removal from Cooking Equipment," NFPA No. 96 (latest edition), available

from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.

Fig. 2 Fig. 3

— 7 —

OPERATION

WARNING: THE GRIDDLE AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING,

CLEANING OR SERVICING.

BEFORE FIRST USE

The griddle is shipped covered with a protective coating. Remove this film only when the griddle

plate is being cleaned prior to its first cooking use. Use a non-corrosive, grease dissolving

commercial cleaner, following manufacturer's directions. Rinse thoroughly and wipe dry with a soft

clean cloth. Clean all accessories. Rinse thoroughly and wipe dry.

Seasoning the Griddle

Season the griddle to avoid possible surface corrosion. Heat griddle to a low (300-350°F)

temperature and pour on a small amount of cooking oil (about one ounce per square foot of surface).

Use a soft lint-free cloth to spread the oil over the entire griddle surface to create a thin film. Wipe

off any excess oil with a cloth. Repeat the procedure two to three times until the griddle has a slick,

mirror-like surface. This should also be done after every cleaning.

Seasoning the Chrome Griddle Plate

To season the chrome plate griddle, lightly coat the griddle surface with a film of cooking oil. Use

a soft lint-free cloth to spread the oil over the entire griddle surface to create a thin film. Heat the

griddle plate to 350°F for 60 minutes. Scrape off any carbonized oil.

CONTROLS

THERMOSTAT — Each thermostat controls the gas flow to the burner to bring that area of the

griddle plate up to the set temperature.

OPERATION OF GRIDDLE WITH ELECTRONIC IGNITION SYSTEM

1. Set the cooking temperature of each thermostat to be used.

2. Push ON/OFF switch to ON. The red indicator light will glow indicating the griddle is on and

calling for heat.

WARNING: APPLIANCES EQUIPPED WITH A FLEXIBLE ELECTRIC SUPPLY CORD ARE

PROVIDED WITH A THREE-PRONG GROUNDING PLUG. IT IS IMPERATIVE THAT THIS

PLUG BE CONNECTED INTO A PROPERLY GROUNDED THREE-PRONG RECEPTACLE.

IF THE RECEPTACLE IS NOT THE PROPER GROUNDING TYPE, CONTACT AN

ELECTRICIAN. DO NOT REMOVE THE GROUNDING PRONG FROM THIS PLUG.

Power supply for electric thermostats is 120 volts, 50/60 Hertz, 1 phase, 5 amperes.

Do not connect the griddle to electrical supply until after gas connections have been made.

— 8 —

SHUTDOWN OF GRIDDLE WITH ELECTRONIC IGNITION SYSTEM

1. Push ON/OFF switch to OFF. Red indicator light will stop glowing. This indicates that all gas has

been shut off to the main burners and griddle is not heating.

EXTENDED SHUTDOWN

1. Shut off the main gas supply valve.

2. Unplug the griddle electrical supply cord from the wall receptacle.

3. Apply a heavy coat of oil over the griddle plate to inhibit rusting.

ADJUSTMENTS

Leveling

Uneven cooking temperatures can be corrected by following the procedures below.

1. Place a level on the griddle.

2. Using the carpenter level supplied with the griddle, level the griddle as follows:

a) Place the level on the center of the griddle plate checking the level of the griddle side to side

and front to rear. The griddle must be level.

b) If the griddle is not level, proceed to adjustment instructions in step 3 to level.

3. Adjust legs by turning the bullet feet at the bottom of each leg. Using channel locks, turn the feet

counter clockwise to increase height and clockwise to decrease height until leveling is achieved.

From the full down position, do not extend the legs out more than 1 3/4".

Calibration

1. Each thermostat controls a 12" zone of the griddle. Using a suitable temperature measurement

device (i.e. Surface Probe), observe the temperatures at the center points of the cooking zones.

These points are located by starting 6" from either side and every 12" across the width of the

griddle, with all points located 12" back from the front edge of the griddle plate.

2. Set thermostats to 350°F and allow to stabilize. (Allow indicator light to cycle ON and OFF at

least two times.)

3. Watch for indicator light to cycle OFF, then measure the temperature for that zone. The

temperature should be 350°F (+/- 15°F). If not, continue to Step 4.

4. Carefully loosen knob set screw. DO NOT allow knob to turn. Carefully remove the knob from

the thermostat shaft, exposing the temperature dial. Loosen screws on the temperature dial and

adjust so that the temperature indicated by the knob arrow matches the griddle plate temperature

reading. (Knob will have to be placed back on the shaft to verify adjustment.)

5. Once calibration is achieved, tighten the temperature dial screws and knob set screws.

Pilot Adjustments

Using a flat head screwdriver, turn the pilot adjustment screw clockwise to decrease the flame and

counter clockwise to increase the flame. Pilot adjustments should be performed only by Authorized

Service Personnel.

— 9 —

ZONE COOKING

This griddle features a tubular U shaped burner in 12" sections, each operating off of independent

thermostats. Each 12" section is a separate cooking zone. This allows cooking a wide variety of

product over a single griddle plate. The chart below is a suggested usage of zone cooking.

When zone cooking, it is suggested that you start with your lowest temperature setting at either side

of the griddle, increasing the zone temperature as you move up the zone line. See chart below for

an example. These zone cooking guidelines will vary depending on product temperatures, size and

shape.

This guide should be adjusted to suit your product and operational cooking preference.

USING THE GRIDDLE

Each 12" section of the griddle is independently controlled by a thermostat. Turn the thermostat(s)

to the desired setting.

Turn the burners on about 20-25 minutes before cooking to preheat.

A uniform and systematic approach to the loading of the griddle will produce the most consistent

product results.

This griddle plate is steel, but the surface is relatively soft and can be scored or dented by carelessly

using a spatula or scraper. Be careful not to dent, scratch, or gouge the plate surface. Do not try

to knock off loose food that may be on the spatula by tapping the corner or the edge of the spatula

on the griddle surface.

ZONE 1

(300°F)

ZONE 2

(350°F)

PRODUCT

Pan Cakes Omelette

French Toast Hash Browns

Bacon Canadian Bacon

Eggs (Sunny Side Up)

Boiled Ham

Steak (Medium Well)

Fresh Burger (Medium Well)

Small Frozen Burger (Medium Well)

ZONE 3

(350°F)

ZONE 4

(400°F)

PRODUCT

Sausage

Eggs (Hard Fried)

Eggs (Scrambled)

Burger (Well Done)

Steak (Well Done)

Chicken Breast

Frozen Foods

Pork Chops

PRODUCT

Steak (Rare)

Stir Fry Vegetables

Salmon

Fish Cakes

Lobster

Scampi

— 10 —

CLEANING THE STANDARD GRIDDLE

WARNING: DISCONNECT THE ELECTRICAL POWER TO THE MACHINE AND FOLLOW

LOCKOUT / TAGOUT PROCEDURES.

Empty the grease drawer as needed throughout the day and regularly clean at least once daily.

Clean the griddle regularly. A clean griddle looks better, lasts longer and performs better. To

produce evenly cooked, perfectly browned griddle products, keep the griddle plate clean and free

of carbonized grease. Carbonized grease on the surface hinders the transfer of heat from the

griddle surface to food. This results in spotty browning and loss of cooking efficiency. Worst of all,

carbonized grease tends to cling to the griddle foods, giving them a highly unsatisfactory and

unappetizing appearance.

To keep the griddle clean and operating at peak efficiency, follow these procedures:

After Each Use

Clean the griddle with a wire brush or flexible spatula.

Once a Day

Thoroughly clean splash back, sides and front. Remove the grease drawer, empty it and wash it

out in the same manner as any ordinary cooking utensil.

Once a Week

Clean the griddle surface thoroughly. If necessary, use a griddle stone, screen or Scotch Bright

pad on the surface. Rub with the grain of the metal while the griddle is still warm. A detergent may

be used on the plate surface to help clean it, but be sure the detergent is thoroughly removed. After

removal of the detergent, the surface of the plate should be covered with a thin film of oil to prevent

rusting.

Clean stainless steel surfaces with a damp cloth and polish with a soft dry cloth. To remove

discolorations, use a griddle cleaner.

After each weekly cleaning, the griddle must be reseasoned.

If the griddle usage is very high, consider going through the weekly cleaning procedures more often

than once a week.

CLEANING THE CHROME GRIDDLE PLATE

After Each Use

Clean the griddle with a flexible spatula or griddle scraper. NEVER USE AN ABRASIVE SCOURING

PAD OR GRIDDLE STONE ON THE CHROME PLATE SURFACE.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Vulcan-Hart Plaque

Vulcan-Hart

Vulcan-Hart RRE24E Manuel utilisateur

Vulcan-Hart

Vulcan-Hart MGG24 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart MSA Series Manuel utilisateur

Vulcan-Hart

Vulcan-Hart RRE24 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GTS12 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Wolf VCRG24-T Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 24RRG Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 924RE ML-135221-00G24, 936RE M Manuel utilisateur

Vulcan-Hart

Vulcan-Hart VMG24 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Wolf VCRG36-T Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 924RE ML-135221-00G24, 936RE M Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 924RX Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 900RX Series Manuel utilisateur

Vulcan-Hart

Vulcan-Hart HEG24R Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 924RX Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 902A ML-52630 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Vulcan 924RE Manuel utilisateur

Vulcan-Hart

Vulcan-Hart RRE24D Mode d’emploi

Vulcan-Hart

Vulcan-Hart VCCG36 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GTS12-1 Operation and Fiche technique

Vulcan-Hart

Vulcan-Hart ASA24 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Wolf VCRG48-M Manuel utilisateur

Vulcan-Hart

Vulcan-Hart RRG Series Manuel utilisateur

Vulcan-Hart

Vulcan-Hart VCCG Series Manuel utilisateur

Manuels Plaque populaires d'autres marques

Proctor-Silex

Proctor-Silex 25340 Manuel utilisateur

New House Kitchen

New House Kitchen NH33-C Manuel utilisateur

Magikitch'n

Magikitch'n 24 Manuel utilisateur

Black Stone

Black Stone 1650 Manuel utilisateur

Anvil

Anvil FTA7116 Manuel utilisateur

Presto

Presto 07030 Manuel utilisateur

Pit Boss

Pit Boss PB2BGT1 Manuel

Dyna-Glo

Dyna-Glo DGL260SNP Manuel utilisateur

Char-Broil

Char-Broil 19952085 Manuel utilisateur

APW Wyott

APW Wyott HMG-2424 Manuel utilisateur

Pit Boss

Pit Boss Ultimate Griddle PB2BGD2 Manuel utilisateur

Airxcel

Airxcel Suburban Elite SOP-1005A Manuel utilisateur

Keating Of Chicago

Keating Of Chicago MIRACLEAN PRE-2000 Manuel utilisateur

Nexgrill

Nexgrill 720-0786A Manuel utilisateur

Outwell

Outwell FH-3047C Manuel utilisateur

Rankam

Rankam Member's Mark GR2298901-MM-02 Guide de référence rapide

Black Stone

Black Stone 1972 Manuel utilisateur

Star

Star Ultra Max 760TA Manuel utilisateur
