Vulcan-Hart GHF91G Manuel utilisateur







 

A2780

ISO9001

Vulcan-Hart Co.



:

45 lb. capacity heavy duty gas range match fryer, Vulcan-Hart

Model No. GHF91G with millivolt control system. Temperature

adjusts from 200° to 400°F. Stainless steel front top ledge. 6"

adjustable nickel plated, noncorrosive legs. 11/4" diameter front

gas manifold. Stainless steel fry tank with 1" full port drain valve.

Four 30,000 BTU/hr. cast burners with pilot ignition system,

120,000 BTU/hr. total input. Four heat exchanger tubes posi-

tioned for easy cleaning. Hi-limit shut-off. Twin fry baskets with

plastic coated handles.

Exterior dimensions: 17"w x 391/8"d x 36" working height on

6" legs.

CSA design certified. NSF listed.













�Stainless steel front top ledge.

�6" adjustable stainless steel legs.

�11/4" diameter front gas manifold.

�Stainless steel fry tank, 45 lb. capacity.

�1" full port ball type drain valve.

�Four 30,000 BTU/hr. cast burners with pilot ignition system,

120,000 BTU/hr. total input.

�Four heat exchanger tubes positioned for easy cleaning.

�Millivolt control system. Thermostat adjusts from 200° to

400°F.

�Hi-limit shut-off.

�Twin fry baskets with plastic coated handles.

�One year limited parts and labor warranty.



�Cap and cover manifold end(s).

�15/8" stainless steel toe base - 315/8" working height.

�1/2" or 3/4" rear gas connection.

�Second year extended limited parts and labor warranty.



�17" high stainless steel backguard. (Common backguards

available up to 102" wide.)

�Extra set of twin baskets. (61/2"w x 131/4"l x 51/2"d.)

�Large single basket. (13"w x 131/4"l x 51/2"d.)

�Gas pressure regulator (specify size and type of gas).

�Flexible gas hose with quick disconnect and restraining

device. Consult price book for available sizes.

Printed On Recycled Paper

 

 In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.





1. A gas pressure regulator suitable for battery or single

unit application must be furnished and installed. Natural

gas 4.0" W.C., propane gas 10.0" W.C.

2. An adequate ventilation system is required for commercial

cooking equipment. Information may be obtained by

writing to the National Fire Protection Association,

Batterymarch Park, Quincy, MA 02269. When writing refer

to NFPA No. 96.

3. These units are manufactured for installation in

accordance with ANSZ223.1a (latest edition), National

Fuel Gas Code. Copies may be obtained from the

American Gas Association, 1515 Wilson Blvd., Arlington,

VA 22209.





   

      

       

17" 391/8" 36" 14" 14" 45 lbs. 120,000 225/102

4. All models require a 6" clearance at both sides and rear

adjacent to combustible construction.

5. For proper flueing, a backguard must be installed with

each unit.

6. This appliance is manufactured for commercial installation

only and is not intended for home use.
