Voyar Frog Manuel utilisateur
User Manual
Contents
Page
General Information
Intended Use 3
Safety Information 4
Overview of parts 5
Specifications 6
Operation
Unfolding the walker 8 & 9
Attaching Arm Supports 10
Folding the Walker 11 & 12
Basic Components & Adjustments
Seat Lifting Force & Height 14 to 20
Forearm Support 21 to 23
Front Wheels Swivel 25 to 27
Walker Frame (width) 31 to 39
Walker Frame (height) 40 to 51
2
Intended Use
•The FROG walker provides support during gait training and is to be used as part of
a developmental program.
• An initial training phase with a therapist is recommended to orient the child with
the walker.
• After sufficient training, the child should be able to use the walker autonomously
to transition from walking/standing to sitting and vice versa.
3
Safety Information
•Walker should be used on fairly flat ground.
•User should remain within the boundaries of the frame during use.
•Before use, check that all knobs & pins on frame, armrest, seat and
wheels are tightened.
4
Overview of parts
A. Adjustable forearm supports
B. Backrest
C. Adjustable lift seat
D. Seat mechanism
E. Foldable frame
F. Adjustable wheel casters
C
A
E
F
D
B
5
Specifications
6
Unfolding & Folding of the walker
7
Unfolding the Walker
Releasing the plunger locks:
1. Pull out and dis-engage left lock on frame.
Engaged Dis-engaged
8
L
R
Unfolding the Walker
Unfolding the walker:
1. Holding on to the left lock and frame,
slowly lift walker in an upward and
forward motion. The frame will
straighten out to unfold the walker.
2. Once walker is upright, ensure locks on
both sides are back into ‘engaged’
positions.
Caution: Please ensure locks are fully engaged before use. 9
Attaching Arm Supports
1. Locate the armrest socket.
2. Pull out lock [3] and hold it in
position.
3. Holding the aluminium shaft, lower the arm
support into the hole.
4. Release lock back in, ensuring pin
inside has engaged with the hole on
the shaft. If not, gently slide
the shaft up or down until lock engages.
Refer to 'Basic Components' section for how to adjust
arm supports.
10
