Voscom VOS-1HD-ADST Manuel utilisateur
VOS-1HD-ADT/R series
1-Channel HD-SDI Video + 2 Duplex Analog Audio
+ 1 Duplex RS485/232 Data
Installation Manual
Fiber Optic Transmission Systems
VOSCOM TECHNOLOGIES CO.,LIMITED
WWW.VOSCOM.COM
TM
Important Safety Instructions EN_1
1. Readthese instructions. Keep these instructions. Heed allwarnings. Follow all instructions.
5. Donot use this apparatus near water. Cleanonly with dry cloth.
7. Donot block any ventilation openings. Install in accordance with the manufacturers
instructions.
8. Donot install near any heat sources such as radiators, heatregisters, stoves,or other
apparatus (includingamplifiers) that produce heat.
9. Donot defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has twoblades with one wider than the other. Agrounding type plug has two blades and a third
grounding prong. The wideblade or the third prong are provided for your safety. Ifthe provided
plug doesnot fit into your outlet consult an electrician for replacement of the obsolete outlet.
10. Protectthe power cord from being walked on or pinched particularly at plugs,convenience
receptacles, andthe points where they exit from the apparatus.
13. Referall servicingto qualified service personnel. Servicing is required when the apparatus
has beendamaged in any way, suchas power-supply cord or plug is damaged, liquid has been
spilled or objects havefallen into the apparatus,the apparatushas been exposed to rain or
moisture, doesnot operate normally,or has been dropped.
14. Apparatusshall not be exposed to dripping or splashing and that no objects filled with liquids,
such asvases shall be placed on the apparatus.
15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatusto rain or
moisture.
16. Installation should be done only by qualified personnel and conform to all local codes.
20. CAUTION: These servicing instructions are for use by qualified service personnel only.To
reduce therisk of electric shock do not perform any servicing other than that contained in the
operating instructionsunless youare qualified to do so.
Website:www.voscom.comWebsite:www.voscom.com
Product Overview En_2
11
HD-SDI
The VOS-1HD-ADT/R provides forthe digital
transmission of1-Channel uncompressed 1.485Gbps
HD-SDI (SMPTE292) or 270 Mbps SD-SDI
(SMPTE 259M) 1080P HDvideo over fiber, support
2 duplex analog audio and 1 duplex RS232 /RS485 data, also support one loopback output for local
display, and dual outputs for two displays in the remote end.
Model Number
Transmitter Receiver Fiber Mode Wavelengths Optical
Power
Budget
Maximum
Transmission
Distance
Multi-Mode 1310nm/1550nmVOS-1HD-ADMRVOS-1HD-ADMT
•The OpticalPower Budgetdata fitMulit-mode(62.5/125 m),Single-Mode(9/125 m).
•When using50/125 m multimode fiber, subtract3 dBfrom the optical power budget.
Note:
16dB 300m
Single-Mode
VOS-1HD-ADSRVOS-1HD-ADST 12dB 20km
Models and Optical Power Budget:
•Extends uncompressed HD-SDI orSD-SDI video over fiber
•Supports SMPTE 292M, SMPTE 259M or DVB-ASI compliant
•Supports embedded digital audio stream
•Multimode Fiber Support for Distances up to 300m
•Single-Mode Fiber Support for Distances up to 20 km
•Real-TimeVideo Transmission forExceptional Qualityand Resolution
Features:
1310nm/1550nm
Audio
22
System Diagram:
Data
11
1 Fiber opticCable
VOS-1HD-ADT
Transmitter VOS-1HD-ADR
Receiver
Loop output
Display
1 x Duplex Data Display
HD-SDI Source
with PTZ Mount HD-SDI Input
HD-SDI Output
HD-SDI Output
PTZ Controller
1 x Duplex Data
Display
2 DuplexAudio 2 DuplexAudio
Panel & Cable Connection En_3
Transmitter Panel:
3
1
1
2
3
SDI-IN HD-SDI Connector: HD-SDI/SD-SDI videoinput.
SDI-OUT HD-SDIConnector: HD-SDI/SD-SDIvideo Loopback output for loacal display.
5-PIN Terminal BlockData Connector: 1-Channel Duplex Rs232/R485 Data Input/Output.
4No Function, No IP Ethernet support for this model.
55-PIN Terminal BlockAudio Connector: 2-Channel Duplex Analog Audio Input/Output.
7Fiber Optic Connector: support FC/PC or ST/PC optical connector.
8Stand-alone Power supply Connector: DC5V 2A Input
TRANSMITTER FRONT PANEL
OPT
SDI-IN
SDI-OUT
POW
SYS
VTXD
LOCK
RXD
A B G C D
ETHERNET
A1 B1 G A2 B2
A3 B3 G A4 B4
1 2 457
TRANSMITTER REAR PANEL
DC5V
8
Website:www.voscom.comWebsite:www.voscom.com
6
6No Function,No Contact Closure support for this model.
None
None
Panel & Cable Connection En_4
Receiver Panel:
3
1
1
2
3
SDI-OUT1 HD-SDIConnector: Thefirst channel HD-SDI/SD-SDI videooutput.
SDI-OUT2 HD-SDIConnector: Thesecond channel HD-SDI/SD-SDI videooutput.
5-PIN Terminal BlockData Connector: 1-Channel Duplex Rs232/R485 DataInput/Output.
4No Function,No IP Ethernet support for this model.
8Stand-alone Power supply Connector: DC5V 2A Input
OPT
SDI-OUT1
SDI-OUT2
POW
SYS
VTXD
LOCK
RXD
A B G C D
ETHERNET
1247
RECEIVER REAR PANEL
DC5V
8
Website:www.voscom.comWebsite:www.voscom.com
A1 B1 G A2 B2
A3 B3 G A4 B4
5
6
55-PIN Terminal BlockAudio Connector: 2-Channel Duplex Analog Audio Input/Output.
7Fiber Optic Connector: support FC/PC orST/PC optical connector.
6No Function,No Contact Closure support for this model.
RECEIVER FRONT PANEL
None
None
Panel & Cable Connection En_5
5 Pin Terminal Block
A
B
G
C
D
Conect Ground(GND)
PIN
Conect DataRs485+(A)
Conect DataRs232 RXD
Receiver (Data): 1-Channel Duplex Rs232/Rs485 Data (Input/Output)
Transmitter (Data): 1-Channel Duplex Rs232/Rs485 Data (Input/Output)
Data Connection:
Input/Output
Input/Output
Input/Output
A B G C D
Conect DataRs485-(B)
Input/Output
Conect DataRs232 TXD
Input/Output
5 Pin Terminal Block
A
B
G
C
D
Conect Ground(GND)
PIN
Conect DataRs485+(A)
Conect DataRs232 RXD
Input/Output
Input/Output
Input/Output
A B G C D
Conect DataRs485-(B)
Input/Output
Conect DataRs232 TXD
Input/Output
Website:www.voscom.comWebsite:www.voscom.com
Panel & Cable Connection En_6
5-Pin Terminal Block PIN
Transmitter (Audio): 2-Channel Duplex Audio (Input/Output)
Audio Connection:
A3 B3 G A4 B4
A3
B3
G
A4
B4
1st-Channel AudioInput
Conect all GND tothis PIN
Input/Output
2nd-Channel AudioInput
Receiver (Audio): 2-Channel Duplex Audio (Input/Output)
Website:www.voscom.comWebsite:www.voscom.com
Input
1st-Channel AudioOutput
2nd-Channel AudioOutput
Input
Output
Output
5-Pin Terminal Block PIN
A3 B3 G A4 B4
A3
B3
G
A4
B4
1st-Channel AudioInput
Conect all GND tothis PIN
Input/Output
2nd-Channel AudioInput
Input
1st-Channel AudioOutput
2nd-Channel AudioOutput
Input
Output
Output
Panel & Cable Connection En_7
SDI-IN
SDI-OUT
Ethernet
DC5V 2A
HD-SDI TRANSMMITTER
OPT
Power Supply
DC5V 2A
HD-SDI RECEIVER
OPT
Power Supply
DATA
Audio IN/OUT
SDI-OUT1
SDI-OUT2
Ethernet
DATA
Audio IN/OUT
HD/SD-SDI Source
with PTZ Mount
Display
HD/SD-SDI VideoInput
Local Loopback Output
1-Channel Duplex RS-232/RS-485 Data
Control Device
1-Channel Duplex RS-232/RS-485 Data
Display
Display
The FirstChannel HD-SDI Output
The SecondChannel HD-SDI Output
No Function
No Function
2-Channel DuplexAudio
2-Channel DuplexAudio
Stand-alone Installation En_8
The transmitter/ receiver can bemounted into arack orcan
be usedas a stand-alone module. Asa stand-alone module,the unit can be placed on adesktop
or canbe mounted toa wall.
VOS-1HD-ADT VOS-1HD-ADR
NOTE: Before mounting the transmitter/ receiver, please
ensure that there is adequate space at both ends forviewing the front-panel LEDsand for
making the various rear-panelcable connections.
VOS-1HD-ADT VOS-1HD-ADR
Stand-alone Mounting Size: 200mm x 135mm x 38mm
Website:www.voscom.comWebsite:www.voscom.com
Rack-mount Installation En_9
Installation Instructions
Typical Configurations:
1:Install the video card into a standard 19inch rack, usinguser-supplied rack-mounting
hardware. Becareful to not damage exposed objects on the back of the card cage unit.
2:If asecondary earth ground connection is needed,a grounded wire with a ground lug can be
attached to the rackusing the protruding screw provided on the right side of the chassis.
3:If desired, blank panels may beinstalled to cover unused slots. A single blank panel coversa
single slot opening.
4:Each fiber optic plug-in module is equipped with a POWER LED indicator that illuminates
when power is applied to the rack unit.
5:Fiber optic plug-in modules(video cards) can be installed into anyof the available 14slots
of thecard cage. Most modules require onlya single slot width, but others, such as the 8-Ch
video Series, require two slot widths.
VOS-CH04-HD16:
19 inch 4U,16 video card slots, suit for VGA, DVI, HD-SDI, 3G-SDIvideo cards.
Support two slide-in power supply AC100V~AC240V, one for redundancy.
The transmitter/ receiver canbe installed into ourrack mount
chassis, VOS-CH04-HD16 which can be mounted into an industry-standard 19-inchequipment
rack.
VOS-1HD-ADT VOS-1HD-ADR
Website:www.voscom.comWebsite:www.voscom.com
