Vogt WorkTec VH10 Manuel d'exploitation

VOGT Hammer

VOGT TurboSpade

VOGT Soil Aerator

VOGT Air Injector

with Spare parts list

Translation of the original

operating Manual

Index

1 About this operating manual��5

1.1 General..................................................................................................................5

1.2 Signs and symbols used......................................................................................6

1.3 Structure of warnings..........................................................................................6

2 Components and tools��8

2.1 System components and tools...........................................................................8

2.2 VOGT Hammer / TurboSpade ............................................................................9

2.3 VOGT Soil Aerator / Air Injector........................................................................11

2.4 Identifying your device......................................................................................12

3 General safety instructions ��13

3.1 Basic principles ..................................................................................................13

3.2 Intended use ......................................................................................................13

3.3 Foreseeable misuse...........................................................................................13

3.4 Safety instructions .............................................................................................14

3.5 Additional safety instructions for the VBL / VAI .............................................16

3.6 Residual risks......................................................................................................17

3.7 Competencies of personnel .............................................................................19

3.8 Safety stickers ....................................................................................................20

4 Transportation��21

5 Getting ready for operation��22

5.1 Inserting and removing tools ...........................................................................22

5.2 Fixing the VAI pneumatic control to the VTS ..................................................23

5.3 Supplying compressed air to the VH and VTS................................................24

5.4 Supplying compressed air to the VBL and VAI ...............................................27

6 Safe use��28

7 Care��33

8 Help in the event of faults��34

8.1 What to do in the event of faults or malfunctions.........................................34

8.2 Fixing faults.........................................................................................................34

9 Decommissioning and disposal ��36

10 Technical data��37

11 Attachment��42

11.1 Service adress ....................................................................................................42

11.2 Raw materials and supplies..............................................................................42

11.3 Manufacturer warranty.....................................................................................43

11.4 Declaration of conformity.................................................................................45

12 Spare parts��46

12.1 Spare parts list Precision in-line oiler Z 300 ...................................................46

12.2 Spare parts list Handles....................................................................................47

12.3 Spare parts list Sticks ........................................................................................48

12.4 Spare parts list Rammer ...................................................................................49

12.5 Spare parts Operating manual / Transport case ...........................................50

12.6 Spare parts list VOGT Soil Aerator...................................................................50

12.7 Spare parts list VOGT Air Injector ....................................................................51

12.8 Spare parts list Injection unit ...........................................................................52

13 Assembly Instructions ��53

13.1 Attaching the scraper to the M 5000 / M 5000.18 scraper holder...............53

13.2 Attaching the double/cross blade holder and scraper to the

M 5000 / M 5000.18 scraper holder ................................................................54

13.3 Assembling the B 55 cross blade.....................................................................54

13.4 Attaching the parquet wedge and Frankenklinge blades to the

M 5000 / M 5000.18 scraper holder ................................................................55

US edition 2021/10 VH / VTS / VBL / VAI Translation of the original operating manual Subject to change without notice

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

13.5 Devlection device to the M 5000 / M 5000.18 scraper holder .....................55

13.6 Attaching scrapers to the M 5000 / M 5000.18 scraper holder,

assembly from below........................................................................................56

13.7 Assembling the cone holder in the conical receiver......................................56

14 Tools and accessories ��57

15 Customer service��58

About this operating manual

Subject to change without notice VH / VTS / VBL / VAI Translation of the original operating manual US edition 2021/10

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

1 About this operating manual

You will need to read this operating manual before you use the device for

the rst time or if you have been tasked with performing other kinds of

work on it.

Pay particular attention to Chapter 3, “General safety instructions.”

1�1 General

This operating manual is designed to make it easier for you to familiarize

yourself with the device and use it for the purposes for which it is intend-

ed.

The manual contains important information and instructions for operating

the device safely and correctly.

The operating manual must

be read and followed by anyone tasked with working with the com-

pressed air device.

be stored in such a way that it can be accessed by all users at any time.

It is a good idea to keep the manual inside the transport case of the

compressed air device.

be handed over together with all other necessary documentation if the

compressed air device is being passed on to third parties.

Your compliance will help to:

avoid hazards.

reduce repair costs and downtime.

increase the reliability and service life of the device.

The accident prevention and environmental protection regulations applica-

ble in the country and at the location where the device is being used must

also be complied with in addition to this operating manual.

Applicability of the

manual

This operating manual applies to the following compressed air devices:

VOGT Hammer VH10 / VH 25 / VH 25 Delta / VH 30 / VH 30 Delta /

VH 50 / VH 50 Delta / VH 60 / VH 60 Delta / VH 50.18 / VH 50.18 Delta /

VH 60.18 / VH 60.18 Delta

VOGT TurboSpade VTS 50 / VTS 60

VOGT Soil Aerator

VOGT Air Injector

About this operating manual

US edition 2021/10 VH / VTS / VBL / VAI Translation of the original operating manual Subject to change without notice

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

1�2 Signs and symbols used

Instructions for action are divided into:

Steps to take

Tips for optimum use

Each piece of information is marked with a symbol:

Symbol Meaning

Steps to take: These steps are numbered consecutively

and must be performed one after the other in the order

indicated.

NOTE Tip: additional information intended to optimize product

use.

1�3 Structure of warnings

Signal word Used for�� Potential consequences if

the warning is ignored:

DANGER Injury

(impending danger)

Death or extremely severe

injuries

WARNING Injury

(potentially

hazardous situation)

Death or extremely severe

injuries

CAUTION Injury Slight or minor injuries

NOTICE Damage to property Damage to the device

and in the surrounding area

Warnings are structured as follows:

Warning with signal word corresponding to the severity level

Nature of hazard (description of the hazard)

Consequences of hazard (description of the impact of the hazard)

Countermeasures (action to prevent the hazard)

Nature of hazard

Consequences of hazard

¾Countermeasures

Components and tools

Subject to change without notice VH / VTS / VBL / VAI Translation of the original operating manual US edition 2021/10

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

2 Components and tools

2�1 System components and tools

Although each VOGT compressed air device is designed for specic types

of task, all devices have the same general structure. Each compressed air

device is made up of the following components:

an handle

a stick

a rammer with or without vibration damper

a sound and dirt absorber (Standard for certain types)

a tool

VOGT Hammer

VOGT TurboSpade

Handle

Sticks

Rammers

Rammers sound and dirt

absorber

sound and dirt

absorber Tools

Tools

optional

Components and tools

US edition 2021/10 VH / VTS / VBL / VAI Translation of the original operating manual Subject to change without notice

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

The image only shows a few of the components available. You can nd an

overview of all the available device types and device lengths and the full

range of tools in our product catalog or at www.vogt-tec.de. We are also

happy to advise you in person.

The VOGT compressed air devices are also sold in sets so that you can nd

suitable solutions for your project quickly and easily. All sets come with

extensive accessories in addition to a compressed air device and suitable

tools. The sets have everything you need to start work straight away.Sets

are available for applications including:

Renovating buildings

Industrial cleaning

Civil engineering, sewer construction, and pipe laying

Gardening and landscaping

2�2 VOGT Hammer / TurboSpade

YouTube explainer video: VOGT Hammer / VOGT

TurboSpade

VOGT Hammer

The VOGT Hammer is a compressed air hammer in the shape of a lance.

As well as having the robustness required for everyday use, the VOGT

Hammer is also highly adaptable and comes in a wide range of versions.

For instance, the VOGT Hammer is available with two dierent handles.

The standard handle is especially versatile, while the Delta handle makes it

easier to apply force in the direction of the stick.

Three dierent rammers are also available for the VOGT Hammer, which

dier in terms of blow frequency, blow force, and weight.

VH 10 / VH 10 Delta: This compact device with a very high blow fre-

quency and a 14 mm chisel holder is primarily designed for working or

removing thin and brittle materials. It is tted with a vibration damper

to reduce the vibration load during work.

VH 30 / VH 30 Delta: This lightweight device with a high blow frequency

and a 14 mm chisel holder is primarily designed for working or re-

moving brittle materials on walls, ceilings, and oors. It is tted with a

vibration damping system to reduce the vibration load during work.

VH 25 / VH 25 Delta: This device is the same as a VH 30 / VH 30 Delta

but without the vibration damping system.

VH 60.18 / VH 60.18 Delta: This powerful device with a low blow fre-

quency but a high blow force and a sturdy 18 mm chisel holder is

primarily designed for working or removing tough materials on oors,

roofs, soil, and, in certain situations, walls as well. It is tted with a

Components and tools

Subject to change without notice VH / VTS / VBL / VAI Translation of the original operating manual US edition 2021/10

Contact:

+49(0)92 78-774 33-0

+49(0)92 78-774 33-11

www.vogt-tec.com

vibration damper to reduce the vibration load and a sound and dirt

absorber to reduce noise during work.

VH 50.18 / VH 50.18 Delta: This device is the same as a VH 60.18 / VH

60.18 Delta but without the vibration damping system.

VH 60 / VH 60 Delta: This device is the same as a VH 60.18 / VH 60.18

Delta but with a 14 mm chisel holder instead. It is tted with a vibra-

tion damper to reduce the vibration load and a sound and dirt absorb-

er to reduce noise during work.

VH 50 / VH 50 Delta: This device is the same as a VH 60 / VH 60 Delta

but without the vibration damping system.

All versions of the VOGT Hammer can be supplied in dierent device

lengths, allowing the device to be adapted even more closely to suit its

area of application and the user.

Control elements

1. Trigger lever

The trigger lever is used to start up the VOGT Hammer. The rammer is

supplied with compressed air while the trigger lever is pressed down.

VOGT TurboSpade

With a low blow frequency but a high blow force and a sturdy 18 mm chis-

el holder, the VOGT TurboSpade is ideal for vertical work. The wide range

of tools available makes the VOGT TurboSpade suitable for tasks such as

digging, breaking up, compacting, and ramming.

Its T-shaped operation unit makes it particularly easy on the back when

working. The vibration damper on the VOGT TurboSpade VTS 60 serves to

reduce the vibration load. An alternative option is the VOGT TurboSpade

VTS 50, which comes without a vibration damper. All device types are tted

with a sound and dirt absorber to reduce noise.

All versions of the VOGT TurboSpade can be supplied in dierent device

lengths, allowing the device to be adapted even more closely to suit its

area of application and the user.

Control elements

1. Trigger lever

The trigger lever is used to start up the VOGT TurboSpade. The rammer is

supplied with compressed air while the trigger lever is pressed down.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Vogt Outils

Vogt

Vogt VH 25 Manuel d'exploitation

Manuels Outils populaires d'autres marques

Martor

Martor SECUNORM 175 Manuel utilisateur

ERKCO

ERKCO 1000 Manuel utilisateur

jbc

jbc N4473 Manuel utilisateur

FEINMETALL

FEINMETALL FZWZ-SET-001 Manuel utilisateur

Worx Professional

Worx Professional Sonicrafter WU676 Manuel utilisateur

Gage Bilt

Gage Bilt GB713SH Manuel utilisateur

Hilti

Hilti DX 9-ENP Manuel utilisateur

norbar

norbar NORTRONIC 34399 Manuel utilisateur

BGS technic

BGS technic 8578 Manuel utilisateur

Makita

Makita DHR241 Manuel utilisateur

Motor Guard

Motor Guard JMB-1250 Manuel utilisateur

Power Adhesives

Power Adhesives 805-12 Manuel utilisateur

Clemco

Clemco 24189 Manuel utilisateur

VVG

VVG VNG 903 Series Manuel utilisateur

Hilti

Hilti FX 3-A Manuel utilisateur

Grizzly

Grizzly H6472 Manuel utilisateur

axing

axing BWZ 5-02 Manuel utilisateur

Dh-Robotics

Dh-Robotics RGI-100 Comment utiliser
