Vivotek IP7330 Manuel utilisateur
Quick Installation Guide
This guide describes the basic functions of IP7330.
All detailed informationis described in the user's manual.
IP7330
IP S u r veillan c e
English Español Português
FrançaisDeutschItalianoTürkçe PolskiРусскийČesky Svenska
Outdoor Day/Night Weather-proof
This guide describes the basic
f
unctions o
f
IP7330.
Alldtil d i f ti i d ib d i th ' l
IP
7
330
EN-1
English
Warning Before Install
Contact your distributor when
such cases happen.
Refer to your user’s manual for the
operating temperature.
Power off the Network Camera as
soon as it is found smoking or smelt
unusual.
Do not touch the Network Camera
when it’s lightening.
Do not place the Network Camera on
unsteady surfaces.
Do not drop the Network Camera.
Do not insert any object into the
Network Camera, such as needles.
EN-2
Package Contents
1
Software CD
IP7330
RJ45 female/female coupler
Quick installation guide /
Warranty card
Camera stand
Power adapter
Silica gel
Silica gel
Liquid tight connectors (3 holes, for
backup use)
ST7501
Central Management Software
EN-3
English
Physical Description
2
Connectors
Ethernet 10/100 RJ45 plug
Power cord socket (black)
General I/O terminal block
Front panel
IR LED
Lens
Reset button
Status LED
Light sensor
Back panel
EN-4
Hardware Installation
3
1. Loose the liquid tight connectors, and then remove the rubber.
2. Loose the back cover.
3. Tear down the aluminum foil vacuum bag and take out the silica gel. Attach the
supplied silica gel to the inner side of the Network Camera. (Please replace the silica
gel with a new one if you open the back cover after installation.)
4. Make sure all cable lines are securely connected.
5. Tighten the back cover, rubber and liquid tight connectors.
6. Secure the Network Camera to the wall/ceiling by the supplied camera stand.
1
2
3
Silica gel
6
5Ceiling mount
Wall mount
Note
If you want to use your own cable lines, please loose two supplied screws and take out
the power board. Then be careful to make connections as the illustration below.
Upper side
Bottom side
Power cord
Terminal block (from left to right)
1: AV24V (red)
2: AC24V (red)
3: DI (white)
4: GND (black)
Ethernet cable
Screws
EN-5
English
Network Deployment
4
POWE
RC
OLLIS
ION
LINK
R
E
C
E
IVE
PARTITION
12345
1. If you have external devices such as
sensors and alarms, make connections
from general I/O terminal block.
2. Use the supplied RJ45 female/female
coupler to connect the Network Camera
to a switch.
Use Category 5 Cross Cable when
Network Camera is directly connected to
PC.
3. Connect the power cable from the
Network Camera to a power outlet.
AV24V: 24V+
AC24V: 24V-
D I : Digital Input
GND : Ground
AV24V
AC24V
DI
GND
General Connection (without PoE)
EN-6
Power over Ethernet (PoE)
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and
a non-PoE switch.
When using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data
via single Ethernet cable. See the following illustration to connect the Network
Camera to a PoE-enabled switch via Ethernet cable.
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
non-PoE switch
PoE power injector
(optional)
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
PoE switch
EN-7
English
1. Install the "Installation Wizard 2" under the Software Utility directory from software
CD.
2. The program will conduct analyses on your network environment. After your network
is analyzed, please click on the "Next" button to continue the program.
3. The program will search the VIVOTEK Video Receivers, Video Servers or Network
Cameras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches
the one labeled on the bottom of your device to connect the Internet Explorer to the
Network Camera.
Installation
Wizard 2
IW
2
Assigning IP Address
5
Network Camera
Model No: IP7330
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
MAC:0002D1733012
0002D1733012
EN-8
For further setup, please refer to user’s manual on the software CD.
Ready to Use
6
1. Access to the Network Camera from the Internet.
2. Retrieve live video through web browsers or recording software.
Quick Installation Guide
This guide describes the basic functions of IP7330.
All detailed information is described in the user's manual.
IP7330
IP Surveillance
English ᖅϛ Рҏᇭ Español Português
ᙏϛ Français Deutsch Italiano Türkçe Polski Русский Česky Svenska
Outdoor Day/Night Weather-proof
This guide describes the basic
f
unctions o
f
IP7330.
Alldtildif ti i d ib d i th ' l
IP
7
330
