Vivotek IP7161 Manuel utilisateur
Quick Installation Guide
English ᖅϛ Рҏᇭ Español Português
ᙏϛ Français Deutsch Italiano Türkçe Polski Русский Česky Svenska
1
English
Contact your distributor when such
cases happen.
Keep the Network Camera away
from water. If the Network Camera
is wet, power off immediately.
Refer to your user’s manual for the
operating temperature.
Power off the Network Camera
as soon as it is found smoking or
smelt unusual.
Do not place the Network Camera
around the heat sources, such as
television or oven.
Keep the Network Camera away
from direct sunlight.
Do not place the Network Camera
in high humid environments.
Contact your distributor when such
cases happen.
Warning Before Install
2
Do not place the Network Camera
on unsteady surfaces.
Do not touch the Network Camera
when it’s lightening.
Do not disassemble the Network
Camera.
Do not drop the Network Camera.
Do not insert any object into the
Network Camera, such as needles.
3
English
Camera stand CS-mount lens
IP7161
Warranty card
Power adapter
Quick installation guide Software CD
1Package Contents
L-type hex key wrench
4
Power cord socket
Ethernet 10/100
RJ45 socket
Indented reset
button
General I/O
terminal block
Audio out
External/Internal MIC switch
Microphone in
Front panel
Back panel
Lens
Focus controller
Zoom controller
2Physical Description
Built-in microphone
Light sensor
Status LED
SD/SDHC card slot
Lens
5
English
For further setup, please refer to the lens’ instruction manual inside the
lens package.
1. Mount the lens by turning it clockwise onto the camera mount until it stops. If
necessary, turn the lens counterclockwise slowly until it gets the best attitude.
2. Connect the lens cable plug to the camera connector.
3Mounting the Lens to the Camera
1
2
General Connection (without PoE)
1. If you have external devices such as sensors and alarms, make connections from
general I/O terminal block.
2. Connect the camera to a switch via Ethernet cable.
3. Connect the supplied power cable from the camera to a power outlet.
POWER COLLISION
LINK
RECEIV E
PARTITION
12345
1
2
3
4Network Deployment
Ethernet switch
1: Power +12V
2: Digital output
3: Digital input
4: Ground
5: AC 24V
6: AC 24V
7: RS485+
8: RS485-
6
Power over Ethernet (PoE)
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the camera and a non-
PoE switch.
POWER COLLISION
LINK
RECEIV E
PARTITIO N
12345
When using a PoE-enabled switch
The camera is PoE-compliant, allowing transmission of power and data via single
Ethernet cable. See the following illustration to connect the camera to a PoE-
enabled switch via Ethernet cable.
POWER COLLISION
LINK
RECEIV E
PARTITI ON
12345
PoE switch
non-PoE switch
PoE power injector
(optional)
7
English
Network Camera
Model No: IP7161
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
MAC:0002D1730202
RoHS
0002D1730202
00-02-D1-73-02-02 192.168.5.151 IP7161
Installation
Wizard 2
IW2
5Assigning IP Address
1. Install the "Installation Wizard 2" under the Software Utility directory from software
CD.
2. The program will conduct analyses on your network environment. After your
network is analyzed, please click on the "Next" button to continue the program.
3. The program will search the VIVOTEK Video Receivers, Video Servers or Network
Cameras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that
matches the one labeled on the bottom of your device to connect the Internet
Explorer to the Network Camera.
8
For further setup, please refer to user’s manual on the software CD.
Ready to Use
6
1. Access to the Network Camera from the Internet.
2. Retrieve live video through web browsers or recording software.
3. Unscrew the zoom controller to adjust the zoom factor. Upon completion, tighten
the zoom controller.
4. Unscrew the focus controller to adjust the focus range. Upon completion, tighten
the focus controller.
N
W
T
3
4
9
English
Fine-tune the Camera Focus
7
Please follow the steps below to ne-tune the camera focus:
1. Use the supplied L-type hex key wrench to loosen the ring screw; the adjusting
ring will become rotatable.
2. Rotate the adjusting ring to ne-tune the distance between the sensor and the
lens; the IR-cut lter and image sensor will move forwards or backwards as the
illustration shows below.
3. When nished, tighten the ring screw to x the adjusting ring.
CS
C
1
2
for C-mount lensfor CS-mount lens
IR-cut lter and image sensor
